WELCOME TO THE LI24 QUICK START
The LI24 Quick Start is meant to show some of the more common setup solutions to getting the LI24 up
and running quickly. If you run into an issue that is not addressed here or wish to install or set up with a
non-standard configuration, please address the LI24 Manual or refer to the Flowline website at
flowline.com.
WE DO YOUR LEVEL BEST
Thank you for purchasing Loop-Powered Meter (LI24). The LI24 Series is a multipurpose, easy to use digital
process meter ideal for level, flow rate, temperature, or pressure transmitter applications. It accepts current
signal (e.g. 4-20 mA) and has four (4) front panel buttons that can be programmed for specific operation.
ORDERING INFORMATION
Model
PD6608-LNN-FL
PD6608-L3N-FL
PD6608-L2N-FL
PD6608-L5N-FL
Manufactured by Precision Digital Corporation, 233 South St, Hopkinton MA 01748
Model
LM91-1001
Single NEMA Box, non-windowed, 1/8 DIN, PC
LM91-2001
Dual NEMA Box, non-windowed, 1/8 DIN, PC
LM92-1002
Single NEMA Box, Windowed, 1/8 DIN, PC
LM92-2002
Dual NEMA Box, Windowed, 1/8 DIN, PC
LM92-3002
Triple NEMA Box, Windowed, 1/8 DIN, PC
|
2
Reorder
Number
LI24-1001
Loop Powered, Hazardous Area, Bar graph, No Options
LI24-1011
Loop Powered, Hazardous Area, Bar graph, 4-20mA Analog Output
LI24-1201
Loop Powered, Hazardous Area, Bar graph, Two Solid State Relays
Loop Powered, Hazardous Area, Bar graph, Two Solid State Relays and 4-
LI24-1211
20mA Analog Output
Accessories
Options Installed
LIN6606QS_FL_A 02/19
