Uplift Desk FRM704 Quick Start Manual

Basic Comfort Flush
Keypad
SKU: FRM704

Package Contents

Keypad
Desk shown upside down
(2) #10x5/8'' Wood Screws

Step 1 - Attach Keypad to Desktop

There are keypad attachment holes pre-drilled into UPLIFT desktops. The pre-drilled holes
are located on both the left and right sides so you can choose which side of the desktop
you'd like to attach the keypad. Note: Typically the desk is upside down when assembling
and attaching the keypad, so if this is the case the keypad will be on the opposite side
once the desk is flipped upright.
If your desktop doesn't have pre-drilled keypad holes, refer to the
Drilling Instructions at the bottom of the page.
A. Align the keypad mounting holes with the pre-drilled holes in the desktop.
B. Being careful not to overtighten the screws to avoid stripping (especially if using a
drill to insert the screws), attach the keypad to the desktop with two #10x5/8" wood
screws provided with your desk and labeled H14.
(provided with desk and labeled H14)
Optional Desktop
