Pulsar HPSB 5524D Manual

27,6v/5a/2x40ah buffer switch power supply unit.
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
HPSB 5524D
HPSB 27,6V/5A/2x40Ah
Buffer switch power supply unit.
Edition: 2 from 24.10.2016
Supercedes the edition: 1 from 18.03.2016
v.1.0
EN**

Advertisement

loading
Need help?

Need help?

Do you have a question about the HPSB 5524D and is the answer not in the manual?

Questions and answers

Related Manuals for Pulsar HPSB 5524D

Summary of Contents for Pulsar HPSB 5524D

  • Page 1 HPSB 5524D v.1.0 HPSB 27,6V/5A/2x40Ah Buffer switch power supply unit. EN** Edition: 2 from 24.10.2016 Supercedes the edition: 1 from 18.03.2016...

  • Page 2: Green Power

    GREEN POWER www.pulsar.pl HPSB5524D Features:   DC 27,6V/5A uninterruptible power supply* battery output full protection against short-circuit  and reverse polarity connection fitting battery: 2x40Ah/12V   wide range of mains supply: 176÷264V LED indication   protections: high efficiency 83% ...
  • Page 3 GREEN POWER www.pulsar.pl HPSB5524D 1.2 Block diagram (fig.1) Fig.1. The block diagram of the PSU. 1.3 Description of PSU components and connectors. Table 1. Elements of the PSU. Element no. Description [Fig. 2] PSU module Connectors PSU: L-N power supply connector 230V AC,...
  • Page 4 GREEN POWER www.pulsar.pl HPSB5524D Fig.2. The view of the PSU. 1.4 Specifications: - electrical parameters (tab.2) - mechanical parameters (tab.3) - operation safety (tab.4) - operating parameters (tab.5) Table 2. Electrical parameters PSU type A (EPS - External Power Source) 176÷264V AC 50Hz...
  • Page 5 GREEN POWER www.pulsar.pl HPSB5524D Table 3. Mechanical parameters Enclosure dimensions 420 x 373 x 181+14 [mm] (WxHxD) Fixation se figure 2 Fitting battery 2x40Ah/12V (SLA) max. 415x170x170mm (WxHxD) max Net/gross weight 6,9/ 7,4 kg Enclosure Steel plate DC01, thickness: 1,0mm, colour: RAL 9003...

  • Page 6: Green Led

    GREEN POWER www.pulsar.pl HPSB5524D 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max.
  • Page 7 GREEN POWER www.pulsar.pl HPSB5524D 4. Operation and use. 4.1 Overload or short circuit of the PSU output (SCP on) In case of overload, the output voltage is automatically shut off, and so is the LED indicator. The restoration of the voltage takes place immediately after the failure (overload) is over.

  • Page 8: Weee Label

    CAUTION! The power supply unit is adapted for cooperation with the sealed lead-acid batteries (SLA). After the operation period they must not be thrown but recycled according to the applicable law. Pulsar Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 E-mail: biuro@pulsar.pl, sales@pulsar.pl http:// www.pulsar.pl, www.zasilacze.pl...
