- Page 1 HPSB 5524C v.1.0 HPSB 27,6V/5A/2x17Ah Buffer, switch mode power supply unit. Edition: 8 from 24.10.2016 Supersedes edition: 7 from 11.08.2014...
- Page 2 PSU, with high energy efficiency. The PSU is housed in a metal enclosure (colour RAL 9003) which can accommodate two 17Ah/12V batteries. A micro switch indicates door opening (front cover). OPTIONAL POWER SUPPLY CONFIGURATIONS: (visualisation available at: www.pulsar.pl) 1. Buffer power supply unit HPSB 27,6V/5x1A/2x17Ah. - HPSB5524C + LB8 5x1A (AWZ579 or AWZ580) + 2x17Ah 2.
- Page 3 GREEN POWER www.pulsar.pl HPSB5524C 6. Buffer power supply unit HPSB 27,6V/2x24V/10x0,5A/2x17Ah. - HPSB5524C + 2 x RN25024(27,6V/24V) + 2xLB8 10x0,5A (AWZ578 or AWZ580) + 2x17Ah 7. Buffer power supply unit HPSB 27,6V/2x24V/16x0,3A/2x17Ah. - HPSB5524C + 2 x RN25024(27,6V/24V) + 2xLB8 16x0,3A (AWZ577 or AWZ580) + 2x17Ah 8.
- Page 4 GREEN POWER www.pulsar.pl HPSB5524C Fig.2. The view of the PSU.
- Page 5 GREEN POWER www.pulsar.pl HPSB5524C 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3). PSU type A (EPS - External Power Source) 176÷264V AC Mains supply Current up to 1.4A@230VAC...
- Page 6 GREEN POWER www.pulsar.pl HPSB5524C Operating parameters (tab.6). -10ºC...+40ºC (see: chart 1) Operating temperature Storage temperature -20ºC...+60ºC Relative humidity 20%...90%, without condensation Vibrations during operation unacceptable Impulse waves during operation unacceptable Direct insulation unacceptable Vibrations and impulse waves during transport According to PN-83/T-42106 Chart 1.
- Page 7 GREEN POWER www.pulsar.pl HPSB5524C The shock protection circuit shall be performed with a particular care, i.e. the yellow and green wire coat of the power cable shall stick to one side of the terminal - marked with ‘ ‘ symbol on the PSU enclosure. Operation of the PSU without the properly made and fully operational shock protection circuit is UNACCEPTABLE! It can cause a device failure or an electric shock.
- Page 8 CAUTION! The power supply unit is adapted for cooperation with the sealed lead-acid batteries (SLA). After the operation period they must not be thrown but recycled according to the applicable law. Pulsar Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 E-mail: biuro@pulsar.pl, sales@pulsar.pl http:// www.pulsar.pl, www.zasilacze.pl...
