Summary of Contents for Pulsar HPSB 5512C
- Page 1 HPSB 5512C v.1.0 HPSB 13,8V/5A/17Ah Buffer, switch mode power supply unit. Edition: 1 from 01.07.2014 Supersedes edition: ----------------...
- Page 2 GREEN POWER www.pulsar.pl HPSB5512C Features: • • LED indication DC 13,8V/5A uninterruptible power supply • • protections: fitting battery: 17Ah/12V • • SCP short-circuit protection wide range of mains supply: 176÷264V • • OVP overvoltage protection high efficiency 80% •...
- Page 3 GREEN POWER www.pulsar.pl HPSB5512C BATTERY 7Ah: 1. Buffer power supply unit HPSB 13,8V/8x0,5A/7Ah. - HPSB5512C + LB8 8x0,5A (AWZ580 or AWZ578) + 7Ah 2. Buffer power supply unit HPSB 13,8V/12V/5x1A/7Ah. - HPSB5512C + RN500 (13,8V/12V) + LB8 5x1A (AWZ580 or AWZ579) + 7Ah 3.
- Page 4 GREEN POWER www.pulsar.pl HPSB5512C Fig.2. The view of the PSU. 1.4 Technical parameters: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operation parameters (tab.6) Electrical parameters (tab. 3) PSU type A (EPS - External Power Source) Mains supply 176÷264V AC...
- Page 5 GREEN POWER www.pulsar.pl HPSB5512C Mechanical parameters (tab. 4) Enclosure dimensions 280 x 292 x 80 x8 [mm] (WxHxD) Fixation See figure 2 Fitting battery 17Ah/12V (SLA) max. 180x120x75mm (WxHxD) max Net/gross weight 2.1 / 2.3 kg Enclosure Steel plate DC01, thickness: 0,7mm, colour: RAL 9003...
- Page 6 GREEN POWER www.pulsar.pl HPSB5512C 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max.
- Page 7 GREEN POWER www.pulsar.pl HPSB5512C 4. Operation and use. 4.1 Overload or short circuit of the PSU output (SCP on) In case of overload, the output voltage is automatically shut off, and so is the LED indicator. The restoration of the voltage takes place immediately after the failure (overload) is over.
- Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a - two-years warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects,...
