- Page 1 HPSB 5048C v.1.0 HPSB 54V/5A/4x17Ah Buffer switch power supply unit. EN** Edition: 2 from 24.10.2016 Supercedes the edition: 1 from 18.03.2016...
-
Page 2: Table Of Contents
4x17Ah/12V battery. A micro switch indicates door opening (front cover). The power supply housing has space for additional modules (fuse blocks, voltage regulators and DC/DC converters). Optional power supply configurations are available at the website: www.pulsar.pl Refer to chart 1... -
Page 3: Block Diagram
GREEN POWER www.pulsar.pl HPSB5048C 1.2 Block diagram (fig.1) Fig.1. The block diagram of the PSU. 1.3 Description of PSU components and connectors. Table 1. Elements of the PSU. Element no. Description [Fig. 2] PSU module Connectors PSU: L-N power supply connector 230V AC,... -
Page 4: Specifications
GREEN POWER www.pulsar.pl HPSB5048C Fig.2. The view of the PSU. 1.4 Specifications: - electrical parameters (tab.2) - mechanical parameters (tab.3) - operation safety (tab.4) - operating parameters (tab.5) Table 2. Electrical parameters PSU type A (EPS - External Power Source) 176÷264V AC 50Hz... - Page 5 GREEN POWER www.pulsar.pl HPSB5048C LED indication: - AC diode indicating AC power status - red, normal status – on, failure: off - DC diode indicating DC power status at - green, normal status – on, failure: off the PSU output Table 3.
-
Page 6: Installation
GREEN POWER www.pulsar.pl HPSB5048C 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max. - Page 7 GREEN POWER www.pulsar.pl HPSB5048C 4. Operation and use. 4.1 Overload or short circuit of the PSU output (SCP on) In case of overload, the output voltage is automatically shut off, and so is the LED indicator. The restoration of the voltage takes place immediately after the failure (overload) is over.
- Page 8 CAUTION! The power supply unit is adapted for cooperation with the sealed lead-acid batteries (SLA). After the operation period they must not be thrown but recycled according to the applicable law. Pulsar Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 E-mail: biuro@pulsar.pl, sales@pulsar.pl http:// www.pulsar.pl, www.zasilacze.pl...
