Pulsar HPSB 5524C Manual

Buffer, switch mode power supply unit

Advertisement

Quick Links

HPSB 5524C
v.1.0
HPSB 27,6V/5A/2x17Ah
Buffer, switch mode power supply unit.
EN*
Edition: 2 from 18.09.2012
Supersedes edition: 1 from 21.11.2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HPSB 5524C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pulsar HPSB 5524C

  • Page 1 HPSB 5524C v.1.0 HPSB 27,6V/5A/2x17Ah Buffer, switch mode power supply unit. Edition: 2 from 18.09.2012 Supersedes edition: 1 from 21.11.2011...
  • Page 2 PSU, with high energy efficiency. The PSU is housed in a metal enclosure (colour RAL 9003) which can accommodate two 17Ah/12V batteries. A micro switch indicates door opening (front cover). OPTIONAL POWER SUPPLY CONFIGURATIONS: (visualisation available at: www.pulsar.pl) 1. Buffer power supply unit HPSB 27,6V/5x1A/2x17Ah. - HPSB5524C + LB8 5x1A (AWZ579 or AWZ580) + 2x17Ah 2.
  • Page 3 7. Buffer power supply unit HPSB 27,6V/2x24V/16x0,3A/2x17Ah. - HPSB5524C + 2 x RN25024(27,6V/24V) + 2xLB8 16x0,3A (AWZ577 or AWZ580) + 2x17 Ah 8. Buffer power supply unit HPSB 27,6V/3x5V÷18V/3x2A÷1,3A/2x17Ah. - HPSB5524C + 3xDCDC20 (3x5V÷18V) + 2x17Ah 9. Buffer power supply unit HPSB 27,6V/3x5V÷18V/3x2A÷1,3A/12x0,5A/2x17Ah. - HPSB5524C + 3xDCDC20 (3x5V÷18V) + 3xLB4 12x0,5A (AWZ574 or AWZ576) + 2x17Ah 1.2 Block diagram (fig.1) Fig.1.
  • Page 4 Fig.2. The view of the PSU.
  • Page 5 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3). Mains supply 176÷264V AC Current up to 1.4A@230VAC Power frequency 50÷60Hz Supply power 155W max. Efficiency Output voltage 27,6V DC –...
  • Page 6 Operating parameters (tab.6). Operating temperature -10ºC...+40ºC (see: chart 1) Storage temperature -20ºC...+60ºC Relative humidity 20%...90%, without condensation Vibrations during operation unacceptable Impulse waves during operation unacceptable Direct insulation unacceptable Vibrations and impulse waves during transport According to PN-83/T-42106 Chart 1. Acceptable output current from the PSU depending on ambient temperature. 2.
  • Page 7 The shock protection circuit shall be performed with a particular care, i.e. the yellow and green wire coat of the power cable shall stick to one side of the terminal - marked with ‘ ‘ symbol on the PSU enclosure. Operation of the PSU without the properly made and fully operational shock protection circuit is UNACCEPTABLE! It can cause a device failure or an electric shock.
  • Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, starting from the initial product date of purchase placed on the receipt. 2. If a purchase proof is missing, a three-year warranty period is counted from the device’s production date.
