www.pulsar.pl
Table 2. PSU elements (see fig. 3).
Element no.
[1]
Insolation transformer
[2]
PSU board (tab.1, fig.2)
[3]
TAMPER; micro-switch (contacts) of tamper resistance (NC)
[4]
F
[5]
L-N 230V/AC power connector,
[6]
Battery connectors: positive: +BAT = red, negative: - BAT = black
[7]
Grip of tamper resistance
Fig. 2. The view of the PSU's pcb.
fuse in the supply circuit (230 V AC)
MAIN
PSBEN10A12C
Description
PE connector
6
