Pulsar PSBOC501235 Quick Start Manual

13,8v/3,5a/oc caged, switched mode, buffer power supply unit

Advertisement

Quick Links

PSBOC501235
v.1.0
PSBOC 13,8V/3,5A/OC
Caged, switched mode, buffer power supply unit
EN
Edition: 1st (10th Mar 2012)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSBOC501235 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pulsar PSBOC501235

  • Page 1 PSBOC501235 v.1.0 PSBOC 13,8V/3,5A/OC Caged, switched mode, buffer power supply unit Edition: 1st (10th Mar 2012)
  • Page 2: Table Of Contents

    PSBOC501235 Features: • • 13,8VDC/3,5A uninterrupted supply FAC technical output indicating AC power loss • • wide range of supply voltage 176÷264VAC FPS technical output indicating PSU failure • • high efficiency 76% FLB technical output indicating battery low •...
  • Page 3: Block Diagram

    PSBOC501235 1.2 Block diagram. (fig.1). Fig.1. Block diagram of the PSU. 1.3 Description of PSU components and connectors. Table 1. Elements of the PSU (see fig. 2). Element no. Description LED indicating presence of AC power LED indicating presence of DC power LED indicating correct battery voltage FAC- AC absence technical output –...
  • Page 4: Specifications

    PSBOC501235 Fig. 2. The view of the PSU. 1.4 Specifications: - electrical specifications (tab.2) - mechanical specifications (tab.3) - operation safety (tab.4) - operating specifications (tab.5) Electrical specifications (tab. 2). Mains supply 176 ÷ 264V AC Current consumption 0,6A@230VAC max.
  • Page 5: Installation

    PSBOC501235 Temperature characteristics. Chart 1. Acceptable output current from the PSU depending on ambient temperature. Mechanical specifications (tab. 3). Enclosure dimensions 159 x 97 x 42+23 [mm] (LxWxH) [mm] (+/- 2) Net/gross weight 0,48kg / 0,53kg Connectors power supply, technical outputs: Φ0,63÷2,5 I/O PCB : Φ0,41÷1,63...
  • Page 6: Installation Procedure

    PSBOC501235 2.2. Installation procedure. 1. Before installation of the power supply unit, make sure that 230VAC power if cut off. 2. Mount the unit in the intended location. 3. Connect the 230VAC power cables. Connect the PE cable (yellow-green) to an appropriate PSU terminal (marked with - earth symbol).
  • Page 7: Operating Status Indication

    PSBOC501235 3. Operating status indication. 3.1 LED indication The PSU is equipped with 3 LEDs on the PCB board: - red LED (Fig.2, element 1) normal status (AC power): permanently illuminated. AC power absence is indicated by the AC diode going out.
  • Page 8: Maintenance

    WEEE separately. GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, starting from the initial product date of purchase placed on the receipt.
