Pulsar PSBE 10A12 Manual

Buffer, switching power supply unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PSU-B-13.8V/S-10A/1/EL-TR-65Ah/MC
PSBE 10A12
v.1.0
Buffer, switching power supply unit.
EN
th
Edition: 2 from 27
October 2010
th
Supercedes edition: 1 from 14
May 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSBE 10A12 and is the answer not in the manual?

Questions and answers

Related Manuals for Pulsar PSBE 10A12

Summary of Contents for Pulsar PSBE 10A12

  • Page 1 PSU-B-13.8V/S-10A/1/EL-TR-65Ah/MC PSBE 10A12 v.1.0 Buffer, switching power supply unit. Edition: 2 from 27 October 2010 Supercedes edition: 1 from 14 May 2010...

  • Page 2: Table Of Contents

    The power-supply has got a metal casing (RAL 9003 colour) with a space for 65Ah/12V battery. The casing features a micro-switch indicating door (front) opening and separating from the wall. Information about additional equipment for PSBE 10A12 power-supply (options of maximal configuration): - 2 x converter DC/DC 2.5A/5V (ADC 255) + 2 x LB5/AW fuse block (AWZ 536) + accumulator 40Ah...

  • Page 3: Block Diagram

    1.2. Block diagram (fig.1). Fig.1. Block diagram of the power-supply unit.
  • Page 4 1.3. Description of elements and connection links of the power-supply unit (tab.1, tab.2, fig.2, fig.3). Table 1. Element no. Description [Fig. 2] F1 fuse in the battery circuit START pushbutton (power-supply activation from the battery) J, jumper - configuration of UVP battery protection function protection function (disconnection) of the battery off •...
  • Page 5 Fig.2. View of the PCB board of the power-supply unit. Table 2. Element no. Description of outputs of the power-supply unit [Fig. 3] Separation transformer Power-supply unit board (tab. 1) TAMPER micro-switch (contacts) of the anti-sabotage protection (NC) F2 fuse in the power supply circuit (230VAC) L-N 230VAC power supply connection , PE protection connection Battery connectors +BAT = red, - BAT = black...
  • Page 6 Fig.3 View of the power-supply unit.

  • Page 7: Technical Parameters

    1.4. Technical parameters: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operation parameters (tab.6) Electrical parameters (tab. 3). Supply voltage 230V AC (-15%/+10%) Supply frequency 50Hz PSU power P 138W Current consumption 1.1A Output voltage 11.0V ÷...

  • Page 8: Installation

    Operation safety (tab.5). Protection class PN-EN 60950-1:2004 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Electrical strength of insulation: - between input (network) circuit and output circuits of power-supply (I/P- O/P) 3000V AC min. - between input circuit and PE protection circuit (I/P-FG) 1500V AC min.

  • Page 9: The Power Supply Operation Indication

    4. Connect the conductors of the loads to the +AUX-, +AUX1-, +AUX2-, +AUX3- terminals of the terminal box on the power-supply unit. 5. If necessary, connect the conductors from the equipment to the technical outputs: - BS AC status indication (alarm panel, controller, signalling unit, LED diode, etc.) - AW technical output of failure - TAMPER signalization of power-supply unit opening or separating from foundation 6.

  • Page 10: Service And Operation

    TAMPER - output indicates opening the power-supply unit: output as volt-free contacts which indicate • power-supply unit door status and fastening to the ground: NC unit opened and/or wrongly fastened (e.g. unit unconnected with the ground): NO. 4. Service and operation. 4.1 Overload of short-circuit to the power-supply output.
  • Page 11 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (manufacturer) grants a two-year quality warranty for the equipment, starting from the date of purchase placed on the purchase order.
