JL Audio 8W7 Owner's Manual

Congratulations on your purchase of a JL Audio subwoofer component. Your JL Audio subwoofer is a

precision loudspeaker which has been engineered to produce the highest quality sub-bass performance in

your vehicle. Authorized JL Audio dealers have extensive technical information for many different

applications of your new speaker. They also have the knowledge, skills and tools to build a high-quality

enclosure that will maximize the performance of your speaker. We highly recommend that you have

your enclosure built by an authorized JL Audio dealer.

Inside you will find specifications and two recommended enclosures for your speaker; one is a sealed

enclosure, the other is a ported design. Both types of enclosures will give you excellent sound quality and

low-frequency extension. The sealed enclosure is a better choice if space is extremely tight, but the ported

enclosure will produce 3dB more output at the same power if you have the extra space to work with.

If you decide to build one of these enclosures yourself, you must have the construction of the box

inspected and approved by your authorized JL Audio dealer in order for the 1 year limited warranty to

be valid. Please read the warranty information carefully.

8W7

Subwoofer

o w n e r ' s m a n u a l

Need help?

Do you have a question about the 8W7 and is the answer not in the manual?

Page 1 If you decide to build one of these enclosures yourself, you must have the construction of the box inspected and approved by your authorized JL Audio dealer in order for the 1 year limited warranty to be valid. Please read the warranty information carefully.
Page 2 4 0 0 0 Amplifier Recommendation: 250/1 JL AUDIO 250/1: Recommended for single 8W7-3 These settings are intended as a “baseline” for tuning your system. Depending on your vehicle and your preferences, some variation in the crossover and bass control settings Dual Mono Speaker may be necessary for optimum performance.
Page 3 Driver Specifications Grille Clearance: 2.3125 in. (25 mm) from the bottom of the mounting flange to the Mounting Hardware: Twelve #8 x 1.00" long clear, zinc-plated steel Phillips pan-head lowest inside surface of the grille. sheet metal screws (included) or twelve #8-32 long steel Phillips pan-head machine screws with #8-32 T-Nuts, each at least 1/2-inch (12.5 mm) longer than the thickness of the Displacement: 0.06 cu.
Page 4 Automotive Subwoofer Components JL AUDIO warrants this speaker to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase, contingent upon installation being performed or approved by an authorized JL AUDIO dealer, in writing, on the original sales receipt. If the preceding condition is not met, the warranty term is limited to ninety (90) days from the original purchase date.
