GV-IP Camera
Firmware Manual
Before attempting to connect or operate this product,
ICH265HISIV114-A
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-BL5311 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-BL5311

Summary of Contents for GeoVision GV-BL5311

  • Page 1 GV-IP Camera Firmware Manual Before attempting to connect or operate this product, ICH265HISIV114-A please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Safety Notice The GV-IPCAM uses a Lithium battery as the power supply for its internal real-time clock (RTC). The battery should not be replaced unless required! If the battery does need replacing, please observe the following: ...

  • Page 4: Table Of Contents

    Contents Caution.................i   Safety Notice ...............i   Options ................vi   Creating GV-IP Camera’s Login Credentials....vii   Note for Adjusting Focus and Zoom......viii   Note for Installing Camera Outdoor........ix   Note for Closing the Bullet Camera Cover ......x  ...
  • Page 5   2.3 Installation ................29   2.4 Connecting the Camera............36 Chapter 3 Bullet Camera (Part III)........39     3.1 Packing List ................40   3.2 Overview ................41   3.3 Installation ................42   3.3.1 Adjusting the Angles ..........46   3.3.2 Adjusting Lens ............48  ...
  • Page 6   5.5 Loading Factory Default............79   5.5.1 Using the Web Interface..........79   5.5.2 Directly on the Camera ..........80 Chapter 6 Target Bullet Camera (Part II).......81     6.1 Packing List ................82   6.2 Overview ................83   6.3 Installation ................84   6.3.1 Adjusting the Angles ..........89  ...
  • Page 7   8.3 Adjusting Image Clarity............106 Chapter 9 The Web Interface ........108   Chapter 10 Upgrading System Firmware ....111  ...

  • Page 8: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description The I/O cable is a multi-connector providing I/O, DC 12V power, and audio connectivity for the I/O Cable camera. Length: 106.8 cm (3.5 ft) The GV-Mount Accessories provide a comprehensive lineup of accessories for GV-Mount...

  • Page 9: Creating Gv-Ip Camera's Login Credentials

    Creating GV-IP Camera’s Login Credentials The default Administrator and Guest accounts are no longer supported by GV-IPCam H.265 series firmware V1.14 or later. When purchasing a new camera or performing factory resetting, you need to set up a login username and password for the camera. Download and install GV-IP Device Utility from the company website.

  • Page 10: Note For Adjusting Focus And Zoom

    Note for Adjusting Focus and Zoom When adjusting the Focus and Zoom Screws on Bullet Camera, do not over tighten the Focus and Zoom screws. The screws only need to be as tight as your finger can do it. It is not necessary to use any tools to get them tighter.

  • Page 11: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the cameras outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.

  • Page 12: Note For Closing The Bullet Camera Cover

    Note for Closing the Bullet Camera Cover To ensure that the camera performs its full capacity against water and dust, tightly close and lock the camera cover as indicated below. Note for Silica Gel Bags The silica gel bag loses its effectiveness when the dry camera is opened.

  • Page 13: Note For Waterproofing Failures

    Note for Waterproofing Failures To avoid waterproofing failures, do not open the screw on the camera body.   The screw on Ultra Bullet The screw on Target Bullet Camera Camera   The screw on GV-EBL2101 / The screw on GV-BL3700 / 2111 / 3101 / 5101 5700...

  • Page 14: Chapter 1 Bullet Camera (Part I)

    Chapter 1 Bullet Camera (Part I) The Bullet Cameras are specifically designed for outdoors and are weatherproof (IP66 or IP67). They are equipped with IR LEDs for infrared illumination in night vision applications. The models described in this chapter use auto iris, which allows for automatic control of exposure. The WDR Pro models enhance the image by processing contrasting intensity of light.
  • Page 15 Model No. Specifications Description GV-BL120D 1.3 MP, H.264, Low Lux GV-BL130D 1.3 MP, H.264 GV-BL220D 2 MP, H.264 GV-BL320D 3 MP, H.264 Auto Iris, f: 3 ~ 9 mm, F/1.2, 1/2.7’’ Varifocal 1.3 MP, H.264, Super GV-BL1500 lens ø 14 mm Lens Low Lux Mount GV-BL2400...

  • Page 16: Packing List

    Bullet Camera (Part I) 1.1 Packing List  Bullet Camera  Self Tapping Screw x 3  Plastic Screw Anchor x 3  Torx Wrench x 2  Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screw x 2, Plastic Screw Spacer x 2 and Hexagon Screw x 2) ...

  • Page 17: Overview

    1.2 Overview Figure 1-1 Name Description Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10). Zoom Screw Holds the zoom lens in place. Focus Screw Holds the focus lens in place Resets all configurations to factory default. Default Button For details, see 1.4 Loading Factory Default.

  • Page 18: Installation

    Bullet Camera (Part I) 1.3 Installation These instructions describe the basic installation of the Bullet Camera. Slide the cable clamp to the camera base. Cable Clamp Figure 1-2 Install the Bullet Camera to the wall. Figure 1-3 Remove the protection sticker from the camera’s cover. Connect the power, network and other wires to the Bullet Camera.
  • Page 19 Access the live view. For details, see 8.2 Accessing the Live View. Adjust angles of the camera body based on the live view. Three shafts can be adjusted. See 1.3.2 Adjusting the Angles. Loosen the camera’s cover, adjust the focus of the camera and optionally insert a micro SD card (SD/SDHC, version 2.0, Class 10) into the SD card slot.

  • Page 20: Connecting The Camera

    Bullet Camera (Part I) 1.3.1 Connecting the Camera Wire Definition for Auto Iris Models The 7-Pin Data Cable provides connections for power, ground, 1 sensor input, 1 alarm output, audio input and audio output. The wires are illustrated and defined below: Digital In (Red) DC 12V+ / AC 24V + (Brown) Digital Out (Orange)
  • Page 21 Power Connection Use one of the following methods to supply power to the camera.  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.  Plug the power adaptor to the terminal block as shown below.
  • Page 22 Bullet Camera (Part I) I/O Device Connection The camera supports one digital input and one digital output of dry contact. Function Digital Output Digital Input Figure 1-7 For details on how to enable an installed I/O device, see 4.2 I/O Settings, GV-IPCam Firmware Manual.
  • Page 23 GV-Relay V2 Bullet Camera Ground (Yellow) Digital Out (Orange)

  • Page 24: Adjusting The Angles

    Bullet Camera (Part I) 1.3.2 Adjusting the Angles The Bullet Camera is designed to be adjustable in three shafts for easy and flexible installation. First Shaft You can adjust the camera body by 360 degrees to the right or the left. Unscrew the panning lock screw with the torx wrench.
  • Page 25 Second Shaft You can adjust the camera body up and down by 90, 112.5, 135, 157.5 or 180 degrees by using the gears inside the camera body and the camera base. Unscrew the tilting lock screw with the torx wrench. Tilting Lock Screw Torx Wrench Figure 1-11...
  • Page 26 Bullet Camera (Part I) Adjust the angle of camera body to 90°, 112.5°, 135°, 157.5° or 180°. Then move the camera base to the left to combine the gears. 180 ° 157.5° 135 ° 112.5° 90° Figure 1-13 Fasten the tilting lock screw. Third Shaft You can adjust the camera base by 360°.
  • Page 27 Adjust the angle of camera base, and fasten the base fixing screw. 0~360° Figure 1-15...

  • Page 28: Adjusting Lens And Inserting A Memory Card

    Bullet Camera (Part I) 1.3.3 Adjusting Lens and Inserting a Memory Card To adjust the camera’s zoom and focus or to insert a micro SD card (SD/SDHC, version 2.0 only, Class 10), follow the steps below. Loosen the camera’s cover. Camera’...
  • Page 29 To adjust for image clarity, follow the steps below.  For models with zoom and focus screws, pull out the camera and remove the silica gel bag to access its focus and zoom screws. Use GV-IP Device Utility to help you. For details, see 8.3 Adjusting Image Clarity.
  • Page 30 Bullet Camera (Part I) Insert a micro SD card into the memory card slot. Memory Card Slot Figure 1-20 Push the camera back and fasten the fixing screw. Insert a new silica gel bag to the camera module and fasten the camera’s cover.

  • Page 31: Installing The Sun-Shield Cover

    1.3.4 Installing the Sun-Shield Cover After setting up the Bullet Camera, now you can install the sun-shield cover to the camera. Fasten the hexagon screws either on top or below the camera. Hexagon Screws Figure 1-23 Put the sun-shield cover on top of hexagon screws. Make sure to aim the rear hexagon screw at the edge of the sun-shield cover’s aperture for optimal sun-shield performance.

  • Page 32: Loading Factory Default

    Bullet Camera (Part I) 1.4 Loading Factory Default You can restore factory default settings through the Web interface or directly on the camera. 1.4.1 Using the Web Interface On the left menu of Web interface, select Management and select Tools. The Additional Tools dialog box appears. Click the Load Default button in the System Settings section.

  • Page 33: Directly On The Camera

    1.4.2 Directly on the Camera Keep the power and network cables connected to the camera. Loosen the camera’s cover. Press and hold the default button for 8 seconds. Default Button Figure 1-27 Release the default button. When the process of loading default settings is completed, the camera reboots automatically.

  • Page 34: Chapter 2 Bullet Camera (Part Ii)

    Bullet Camera (Part II) Chapter 2 Bullet Camera (Part II) The Bullet Cameras are specifically designed for outdoors. They are weatherproof (IP67) and equipped with IR LEDs for infrared illumination in night vision applications. The models described in this chapter use P-Iris, which allows for precise control of exposure, producing images with better clarity and contrast.
  • Page 35 Model No. Specifications Description 1.3 MP, H.264, GV-BL1501 Super Low Lux P-Iris, f: 3 ~ 9 mm, F/1.2, 1/2.7’’ 2 MP, H.264, GV-BL2501 ø 14 mm Lens Super Low Lux Mount 3 MP, H.264, GV-BL3401 WDR Pro P-Iris, f: 2.8 ~ 12 mm, F/1.7, 1/2.7”, GV-BL2702-3V ø...
  • Page 36 Bullet Camera (Part II) Model No. Specifications Description P-Iris, f: 4.5 ~ 9 mm, F/1.2, 1/2.7’’ 5 MP, H.264, 2X GV-BL5311 Optical Zoom ø 14 mm Lens Mount P-Iris, f: 2.8 ~ 12 4 MP, H.265, Motorized mm, F/1.7, 1/2.7”,...

  • Page 37: Packing List

    2.1 Packing List For GV-BL1501 / 2501 / 3401 / 1511 / 2511 / 3411 / 5311 / 2511-E / 5311-E, refer to the following packing list:  Bullet Camera  Self Tapping Screw x 3  Plastic Screw Anchor x 3 ...
  • Page 38 Bullet Camera (Part II) For GV-BL2702 / 4702 / 4713 / 5713, refer to the following packing list:  H.265 Bullet Camera  Stand Kit (Conduit Converter, PG21 Conduit Connector, RJ-45 Connector, M3 Screw x 2, Cable Tie)  Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screws x 2, Plastic Screw Spacers x 2, Hexagon Screws x 2) ...

  • Page 39: Overview

    2.2 Overview Twist off the camera cover to access the following: Figure 2-1 GV-BL4713 / 5713 For GV-BL4713 / 5713, twist off the camera cover and loosen the three screws on the front lid of the sun-shield cover to access the following: Figure 2-2...
  • Page 40 Bullet Camera (Part II) Name Description Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10). Zoom Screw Holds the zoom lens in place. Focus Screw Holds the focus lens in place Resets all configurations to factory default. Default Button For details, see 1.4 Loading Factory Default.
  • Page 41 To access the following interface, remove the camera base using the supplied torx wrench. Figure 2-4 Name Description LAN / PoE Connects to a 10/100 Ethernet or PoE. Audio In Connects a microphone for audio input. Audio Out Connects a speaker for audio output. Connects to I/O devices.

  • Page 42: Installation

    Bullet Camera (Part II) 2.3 Installation Follow the steps below to install the Bullet Camera. Paste the supplied sticker to the ceiling/wall. For wall installations, make sure the arrow on the sticker points toward the ceiling. Mount template Figure 2-5 Drill the shaded area, and insert the screw anchor into the three holes.
  • Page 43 Loosen the indicated screws and remove the back plate. Figure 2-7 Align and secure the back plate to the wall/ceiling with the supplied self-tapping screws. Figure 2-8...
  • Page 44 Bullet Camera (Part II) To optionally install a pipe, use one of the two methods illustrated below depending on the type of the back plate that comes with your camera: A. If your plate comes with two knobs (as in Figure 2-9) Install the supplied conduit converter to the back plate.
  • Page 45 Install the Ethernet cable. A. Twist off and remove the cable seal and the conduit connector. Conduit Connector Cable Seal Figure 2-11 B. Thread an Ethernet cable (with no RJ-45 connector on one end) from the back panel through the cable seal and then through the conduit converter (optionally installed at Step 6A).
  • Page 46 Bullet Camera (Part II) C. Re-install the cable seal. Make sure it is installed tightly to waterproof the camera. Thread wires into the camera. A. Disintegrate the removed conduit connector. You should have 4 parts: Figure 2-13 B. Remove the terminal block from the supplied power adapter. C.
  • Page 47 For part 2, there are 8 holes each labeled with its diameter. Remove the plugs and push the wires to the corresponding hole listed below: Plug Figure 2-14 2.6 mm: Audio 2 mm: DC12V / AC24V 1.8 mm: DIDO Figure 2-15 IMPORTANT: ...
  • Page 48 Bullet Camera (Part II) Install the base to the back plate on the wall. Connect the wires to the camera. A. Install the terminal blocks to the power adapter and I/O devices. See Power Connection and I/O Device Connections in 2.4 Connecting the Camera.

  • Page 49: Connecting The Camera

    2.4 Connecting the Camera Power Connection Use one of the following methods to supply power to the camera. Note that GV-BL2511-E / 5311-E do not support PoE.  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.
  • Page 50 Bullet Camera (Part II) I/O Device Connection The camera supports one digital input and one digital output of dry contact. Function Digital Output Digital Input Figure 2-18 For details on how to enable an installed I/O device, see 4.2 I/O Settings, GV-IPCam Firmware Manual.
  • Page 51 Wire Definition 2-pin Terminal Block DC 12V Pink RCA Audio Input Green RCA Audio Output Digital Output Digital I/O Black Yellow Digital Input Note: To connect a power adapter to the I/O cable, take off the 2-pin terminal block on the adapter and connect the wires to the one on the I/O cable.

  • Page 52: Chapter 3 Bullet Camera (Part Iii)

    Bullet Camera (Part III) Chapter 3 Bullet Camera (Part III) The Bullet Cameras are specifically designed for outdoors. They are weatherproof (IP67) and equipped with IR LEDs for infrared illumination in night vision applications. They support H.265 video codec to achieve better video compression while maintaining high quality picture.

  • Page 53: Packing List

    3.1 Packing List  H.265 Bullet Camera   Sun-shield Cover Screw for Sun­shield Cover x 2   Screw for Supporting Rack Screw Anchor x 3   Silica Gel Bag x 2 Washer x 2   RJ-45 Connector x 2 Hex Wrench ...

  • Page 54: Overview

    Bullet Camera (Part III) 3.2 Overview Figure 3-1 Name Description Receives a micro SD card (SD/SDHC/SDXC/ Memory Card UHS-I, Class 10). Slot * UHS-II card type is not supported. Resets all configurations to factory default. For Default Button details, see 3.5 Loading Factory Default. Focus Screw Holds the focus lens in place Zoom Screw...

  • Page 55: Installation

    3.3 Installation You can install the camera to the ceiling or wall. Follow the steps below. Unscrew the camera body, remove the sun-shield mount, and loosen the camera cover from the camera. Sun-Shield Mount Screws Camera Cover Figure 3-2 Insert a micro SD card (SD/SDHC/SDXC/UHS-I, Class 10) into the card slot.
  • Page 56 Bullet Camera (Part III) Secure the camera cover, fasten the sun-shield mount, and screw the camera body. Sun-Shield Mount Figure 3-4 Slide the sun-shield cover onto the top of the camera. Adjust the position of the cover before fully securing the cover with the washer and the screw.
  • Page 57 Thread the Ethernet cable into the conduit connector. Remove the plug from the conduit connector. Figure 3-6 Disintegrate the removed conduit connector. Thread the Ethernet cable through the 3 parts. Figure 3-7 Assemble the conduit connector. Figure 3-8 Note: If you can’t plug the self-prepared RJ-45 connector into the jack of the conduit, it is suggested to use the supplied RJ-45 connector.
  • Page 58 Bullet Camera (Part III) Install the camera to the wall or ceiling using the screw anchors and screws for supporting rack. Figure 3-9 IMPORTANT: To avoid waterproofing failures, the top of the camera must be facing upward for wall mount. Connect the wires and cable connector to the camera.

  • Page 59: Adjusting The Angles

    3.3.1 Adjusting the Angles The GV-BL3700 / 5700 is designed to be adjustable in two shafts for easy and flexible installation. First Shaft You can adjust the camera base by 360°. Unscrew the base fixing screw with the hex wrench. Figure 3-10 Adjust the angle of camera base, and fasten the base fixing screw with the hex wrench.
  • Page 60 Bullet Camera (Part III) Second Shaft You can adjust the camera body to the desired angle by tilting the camera module. Unscrew the tilting lock screw with the hex wrench. Figure 3-12 Adjust the angle of camera body to the desired angle. Figure 3-13 Fasten the tilting lock screw.

  • Page 61: Adjusting Lens

    3.3.2 Adjusting Lens To adjust the camera’s zoom and focus, follow the steps below.  Loosen the camera’s cover. See Figure 3-2.  To adjust for image clarity by adjusting the focus and zoom screws. For details, see 8.3 Adjusting Image Clarity. Focus Screw Zoom Screw Figure 3-14...

  • Page 62: Connecting The Camera

    Bullet Camera (Part III) 3.4 Connecting the Camera 3.4.1 Wire Definition The 4-Pin terminal block supports 1 digital input and 1 digital output of dry contact. For details on how to enable an installed I/O device, see 4.2 I/O Settings, GV-IPCam Firmware Manual. The 5-Pin terminal block provides power input, 1 audio input and 1 audio output.
  • Page 63 Wire Name Definition DI - Digital In - 4-pin DI + Digital in + terminal DO - Digital Out - block Digital Out + 12 V DC 5-pin DC 12V + terminal L-IN Audio in block *Support passive microphones only A GND Audio Ground L-OUT...

  • Page 64: Power Connection

    Bullet Camera (Part III) 3.4.2. Power Connection Use one of the following methods to supply power to the camera.  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. ...
  • Page 65 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 66: Loading Factory Default

    Bullet Camera (Part III) 3.5 Loading Factory Default 3.5.1. Using the Web Interface U You can restore factory default settings through the Web interface. For details, refer to 1.4.1 Using the Web Interface. 3.5.2. Directly on the Camera Press and hold the default button for about 5 seconds to restore the factory default.

  • Page 67: Chapter 4 Ultra Bullet Camera

    Chapter 4 Ultra Bullet Camera The Ultra Bullet Camera is a series of light-weighted cameras designed for outdoor environments. The camera adheres to the IP67 standard and has full protection against dust and jets of water. The Ultra Bullet Cameras are available in motorized varifocal lens and fixed lens at 1.3, 2 and 3 megapixels.
  • Page 68 Ultra Bullet Camera Model No. Specifications Description Fixed Iris, f: 2.8 mm, GV-UBL1301-0F F/2.0, 1/3’’ M12 Lens Mount 1.3 MP, Low Lux, H.264 Fixed Iris, f: 4 mm, GV-UBL1301-1F F/1.5, 1/3’’ M12 Lens Mount Fixed Iris, f: 4 / 8 mm, GV-UBL1301-2F 1.3 MP, Low F/1.6, 1/3’’...

  • Page 69: Packing List

    4.1 Packing List  Ultra Bullet Camera (with Waterproof or Non-Waterproof LAN connector)  Camera Stand  Black Rubber  Self Tapping Screw x 3  Plastic Screw Anchor x 3  Torx Wrench  Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screw x 2, Plastic Screw Spacer x 2 and Hexagon Screw x 2) ...

  • Page 70: Overview

    Ultra Bullet Camera 4.2 Overview Panel Figure 4-1 Name Description Power & I/O Connects to the data cable. For details, see Connector 4.3.2 Connecting the Camera. Resets all configurations to factory default. For Default Button details, see 4.4 Loading Factory Default. LAN / PoE Connects to a 10/100 Ethernet or PoE.
  • Page 71 LAN Connector The Ultra Bullet Camera provides two connector types. Select an option based on your installation environment.  Option 1 (Waterproof) To waterproof the cable, install the supplied cable connector. See 4.3.1 Waterproofing the Cable.  Option 2 (Smaller and non-waterproof)

  • Page 72: Installation

    Ultra Bullet Camera 4.3 Installation You can install the camera to the ceiling or wall. Follow the steps below. Optionally insert a micro SD card to the camera. A. Unscrew and open the back panel with the supplied torx wrench. Figure 4-2 B.
  • Page 73 B. Put the sun-shield cover on the top of the camera. For optimal sun-shield performance, make sure the rear hexagon screw is at the end of the opening. Sun-Shield Cover Figure 4-4 IMPORTANT: The GeoVision logo on the sun-shield cover should be closer to the front of the camera.
  • Page 74 Ultra Bullet Camera C. Fasten the Philips head screws with the plastic screw spacers to mount the sun-shield cover onto the camera.  Ceiling Mount: Fasten one Philips head screw to the top of the camera.  Wall Mount: Fasten two Philips head screws to the top of the camera.
  • Page 75 B. Wall Mount: Secure the black rubber and the camera stand to one of the screw holes on the bottom. Figure 4-7 Use the screw anchors and self-tapping screws to secure the camera to the wall. Figure 4-8...
  • Page 76 Ultra Bullet Camera Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 4.3.1 Waterproofing the Cable and 4.3.2 Connecting the Camera. Access the live view. For details, see 8.2 Accessing the Live View. Adjust angles of the camera body based on the live view.

  • Page 77: Waterproofing The Cable

    4.3.1 Waterproofing the Cable Waterproof the option 1 LAN / PoE cable (see 4.2 Overview) using the supplied cable connector. The cable connector can be dissembled into 5 parts: Figure 4-9 Cut off the RJ-45 connector on one end of the Ethernet cable. Figure 4-10 Connect the Ethernet cable to the LAN / PoE connector (No.
  • Page 78 Ultra Bullet Camera Move all the components toward the LAN / PoE connector, fit item 4 to item 2, secure item 3 to the LAN / PoE connector (Item A) and finally secure item 5 to item 2 tightly. Figure 4-12 IMPORTANT: Item 5 must be secured tightly to waterproof the LAN / PoE connector.

  • Page 79: Connecting The Camera

    4.3.2 Connecting the Camera Wire Definition The camera’s 4-pin data cable provides connections for power, ground, 1 sensor input and 1 alarm output. The wires are defined below: Figure 4-13 Wire Color Definition DC 5V Green Digital In Blue Digital Out Black Ground...
  • Page 80 Ultra Bullet Camera Power Connection Connect the camera to power using one of the following methods:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. ...
  • Page 81 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 82: Loading Factory Default

    Ultra Bullet Camera 4.4 Loading Factory Default 4.4.1 Using the Web Interface You can restore factory default settings through the Web interface. For details, refer to 1.4.1 Using the Web Interface. 4.4.2 Directly on the Camera Press and hold the default button for about 8 seconds to store the factory default.

  • Page 83: Chapter 5 Target Bullet Camera (Part I)

    Chapter 5 Target Bullet Camera (Part I) The Target Bullet Camera is a series of light-weighted cameras designed for outdoor environments. The camera adheres to the IP67 standard and has full protection against dust and jets of water. The camera offers an entry­level surveillance solution with all the essential features and excellent image quality.

  • Page 84: Packing List

    Target Bullet Camera (Part I) 5.1 Packing List  Target Bullet Camera  Sun-Shield Cover  Silica Gel Tape x 2  Supporting Rack  Screw for supporting rack x 3  Screw Anchor x 3  Screw for sun-shield cover ...

  • Page 85: Overview

    5.2 Overview Figure 5-1 Name Description Power Connects to the data cable. For details, see Connector 5.4 Connecting the Camera. Resets the camera to factory default. For Default Button details, see 5.5 Loading Factory Default.

  • Page 86: Installation

    Slide the sun-shield cover onto the top of the camera. Figure 5-3 Note: The GeoVision logo on the sun-shield cover should be closer to the front of the camera. Line up the screw hole on the camera with the opening on the sun- shield cover.
  • Page 87 Ceiling Mount: Secure the supporting rack to the opening on the sun-shield cover Figure 5-5 Wall Mount: Insert and tighten the supplied screw and washer on the sun- shield cover. Secure the supporting rack to the bottom. Figure 5-6...
  • Page 88 Target Bullet Camera (Part I) Thread the Ethernet cable into the conduit connector. For details, see step 6, 3.3 Installation. Figure 5-7 Note: The size of RJ-45 connector must be within 14 mm to plug into the jack of the conduit. Unfit size of RJ45 Connector...
  • Page 89 Install the camera to the wall or ceiling using the screw anchors and self-tapping screws. You can also stand the camera on a plain surface. Figure 5-8 Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 5.4 Connecting the Camera.

  • Page 90: Connecting The Camera

    Target Bullet Camera (Part I) 5.4 Connecting the Camera 5.4.1 Wire Definition The data cable provides connections for power, ground and network access. The wires are defined below: Figure 5-9 Wire Color Definition DC 12V Black Ground Black (thick) PoE, Ethernet...

  • Page 91: Power Connection

    5.4.2 Power Connection There are two ways to supply power to the camera:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.  Plug the power adapter to the 12V terminal block as shown below. The power adapter is an optional device.

  • Page 92: Loading Factory Default

    Target Bullet Camera (Part I) 5.5 Loading Factory Default 5.5.1 Using the Web Interface On the left menu of Web interface, select Management and select Tools. The Additional Tools dialog box appears. Click the Load Default button of Restore to factory default settings or Restore to factory default settings (Except network) in the System Settings section.

  • Page 93: Directly On The Camera

    5.5.2 Directly on the Camera Press and hold the default button for about 8 seconds to restore the factory default. For details see 1.4.2 Directly on the Camera. Default button Figure 5-13...

  • Page 94: Chapter 6 Target Bullet Camera (Part Ii)

    Target Bullet Camera (Part II) Chapter 6 Target Bullet Camera (Part II) The Target Bullet Camera is a light-weighted camera designed for outdoor environments. It adheres to the IP67 standard and has full protection against dust and jets of water. The camera also allows automatic and precise control of exposure using its P-iris, producing images with better clarity and contrast.

  • Page 95: Packing List

    6.1 Packing List  Target Bullet Camera   Sun-shield Cover Silica Gel Bag x 2   Screw for Supporting Rack Screw Anchor x 3   Screw for Sun-shield Cover Washer x 2   Terminal Block Screw for Mounting Kit x 3 ...

  • Page 96: Overview

    Target Bullet Camera (Part II) 6.2 Overview Figure 6-1 Name Description Zoom Screw Holds the zoom lens in place. Focus Screw Holds the focus lens in place Resets all configurations to factory default. For Default Button details, see 6.5 Loading Factory Default.

  • Page 97: Installation

    6.3 Installation You can install the camera to the ceiling or wall. Follow the steps below. Replace the Silica Gel Bag. Remove the camera cover from the camera. Figure 6-2 Loosen the camera’s screws and the hexagon pillars as indicated below. Figure 6-3...
  • Page 98 Target Bullet Camera (Part II) Take out the camera from the camera body Figure 6-4 Cut the 2 silica gel bags apart with scissors, and place the new silica gel bags at the lower half of the camera body. Figure 6-5 Secure the 2 hexagon pillars to the upper and lower holes of camera module as indicated below.
  • Page 99 Figure 6-7 Note: The GeoVision logo on the sun-shield cover should be closer to the front of the camera. There are two holes for the screws at the back of the camera. You only need to fasten one screw to secure the sun shield...
  • Page 100 Target Bullet Camera (Part II) Thread the Ethernet cable into the camera. For details, see step 6, 3.3 Installation. Figure 6-8 Note: The size of RJ-45 connector must be within 14 mm to plug into the jack of the conduit.
  • Page 101 Install the camera to the wall or ceiling using the screw anchors and screws for supporting rack. Figure 6-9 IMPORTANT: To avoid waterproofing failures, the top of the camera must be facing upward for wall mount. Connect the wires and cable connector to the camera. See 6.4 Connecting the Camera.

  • Page 102: Adjusting The Angles

    Target Bullet Camera (Part II) 6.3.1 Adjusting the Angles The Target Bullet Camera is designed to be adjustable in two shafts for easy and flexible installation. You can adjust the camera base by 360° and the camera body to the desired angle by tilting the camera module.

  • Page 103: Adjusting Lens

    6.3.2 Adjusting Lens To adjust the camera’s zoom and focus, follow the steps below. Loosen the camera’s cover. See Figure 6-2. To adjust for image clarity by adjusting the focus and zoom screws. For details, see 8.3 Adjusting Image Clarity. Zoom Screw Focus Screw Figure 6-11...

  • Page 104: Connecting The Camera

    Target Bullet Camera (Part II) 6.4 Connecting the Camera 6.4.1 Wire Definition The data cable provides connections for power, ground and network access. The wires are defined below: Figure 6-12 Wire Color Definition DC 12V Black Ground Black (thick) PoE, Ethernet...

  • Page 105: Power Connection

    6.4.2 Power Connection For details, see 5.4.2 Power Connection. Note: The Power Adaptor is not supplied in the packing list. The Power adapter can be purchased upon request.

  • Page 106: Loading Factory Default

    Target Bullet Camera (Part II) 6.5 Loading Factory Default 6.5.1 Using the Web Interface You can restore factory default settings through the Web interface. For details, see 5.5.1 Using the Web Interface. 6.5.2 Directly on the Camera Press and hold the default button for about 8 seconds to load the factory default.

  • Page 107: Chapter 7 Target Bullet Camera (Part Iii)

    Chapter 7 Target Bullet Camera (Part III) The Target Bullet Camera is a light-weighted camera designed for outdoor environments. It adheres to the IP67 standard and has full protection against dust and jets of water. The camera comes with a built-in micro SD card slot for local storage.

  • Page 108: Packing List

    Target Bullet Camera (Part III) Fixed Iris, f: 2.8 mm, F/2.0, 1/2.7”, ø 12 mm GV-EBL4702-3F Lens Mount Motorized P-Iris, f: 2.7 ~ 12 mm, 4 MP, H.265, GV-EBL4711 varifocal F/1.6, 1/2.7”, ø 14 mm Super Low lens Lens Mount Lux, WDR Pro 7.1 Packing List ...

  • Page 109: Overview

    7.2 Overview Figure 7-1 Name Description Resets all configurations to factory default. For Default Button details, see 7.5 Loading Factory Default. Inserts a micro SD card Memory Card (SD/SDHC/SDXC/UHS-I) to store recording Slot data. Note UHS-II card type is not supported. Note: GV-EBL2702 Series does not support SDXC cards.

  • Page 110: Installation

    Target Bullet Camera (Part III) 7.3 Installation To install the camera to the ceiling or wall, you need to open the camera body, insert the memory card, replace silica gel bag, install the sun-shield cover, waterproof the cable, and adjust the camera angles. For details see 6.3 Installation and 6.3.1 Adjusting the Angles.

  • Page 111: Connecting The Camera

    7.4 Connecting the Camera 7.4.1 Wire Definition The data cable provides connections for power, ground and network access. For details, refer to 6.4.1 Wire Definition. 7.4.2 Power Connection For details, see 5.4.2 Power Connection. Note: The Power Adaptor is not supplied in the packing list. Power adapter can be purchased upon request.

  • Page 112: Loading Factory Default

    Target Bullet Camera (Part III) 7.5 Loading Factory Default 7.5.1 Using the Web Interface You can restore factory default settings through the Web interface. For details, see 5.5.1 Using the Web Interface. 7.5.2 Directly on the Camera Press and hold the default button for about 8 seconds to load the factory default.

  • Page 113: Chapter 8 Accessing The Camera

    Chapter 8 Accessing the Camera 8.1 System Requirement To access the GV-IP Camera through the Web browser, ensure your PC connects to the network properly and meets this system requirement:  Microsoft Internet Explorer 8.0 or later Note: For the users of Internet Explorer 8, additional settings are required.

  • Page 114: Accessing The Live View

    Accessing the Camera 8.2 Accessing the Live View When the camera is connected to a network with a DHCP server, it will be automatically assigned with a dynamic IP address. See 8.2.1 Checking the Dynamic IP Address to look up this IP address. However, if you do not have a DHCP server on your network, access the camera by its default IP address 192.168.0.10 and see 8.2.2 Configuring the IP Address for more detail.

  • Page 115: Checking The Dynamic Ip Address

    8.2.1 Checking the Dynamic IP Address Follow the steps below to look up the IP address and access the Web interface. Note: The computer you use to configure the IP address must be under the same LAN with your camera. The default Administrator and Guest accounts are no longer supported by GV-IPCam H.265 series firmware V1.14 or later.
  • Page 116 Accessing the Camera The login page appears. Figure 8-2 Type the default ID and password admin and click Apply to log in.

  • Page 117: Configuring The Ip Address

    Click Apply. The camera is now accessible by entering the assigned IP address on the Web browser. To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a one- time installation of GeoVision’s ActiveX component onto your computer.
  • Page 118 Accessing the Camera IMPORTANT: If Dynamic IP Address or PPPoE is enabled, you need to know which IP address the camera will get from DHCP server or ISP to log in. If your camera is installed in the LAN, use the GV-IP Device Utility to look up its current dynamic IP address.
  • Page 119 8.3 Adjusting Image Clarity You can adjust the image clarity using the GV-IP Device Utility. Make sure that you have connected your GV-IPCAM to the network and install the GV-IP Device Utility program under the same LAN. Note: This feature only applies to the cameras that allow manual focus adjustment.
  • Page 120 Accessing the Camera Note: For locations of adjustment screws and rings in each model, see Locations of Adjustment Screws, section, Getting Started Chapter, GV-IPCAM Firmware Manual. Do not over tighten the screws. The screws only need to be as tight as your fingers can get them to be. Do not bother using any tool to get them tighter.
  • Page 121 Chapter 9 The Web Interface 12 13 Figure 9-1...
  • Page 122 The Web Interface No. Name Function Play Plays live video. Stop Stops playing video. Broadcasts to the surveillance site from a remote PC. Note this function is not available for Ultra Bullet Camera and Target Series. For Cube Camera and Advanced Cube Camera, click the Microphone Push to talk button (from the pop-up menu) for the camera to switch between audio transmission and...
  • Page 123 No. Name Function Enables the PTZ Control Panel or the Visual PTZ. PTZ Control Note this function is supported by PTZ Camera Panel and PT Camera, and only partially supported by GV-IP Cameras with motorized varifocal lens. Enables the I/O Control Panel and Visual Automation.
  • Page 124 Chapter 10 Upgrading System Firmware GeoVision periodically releases updated firmware on the website. The new firmware can be simply loaded into the GV-IPCAM by using the Web interface or IP Device Utility. Before you start  If you use the IP Device Utility for firmware upgrade, the computer used to upgrade firmware must be under the same network of the camera.
  • Page 125 In the Live View window, click the Show System Menu button and select Remote Config. This dialog box appears. Figure 10-1 Click the Browse button to locate the firmware file (.img) saved at your local computer. Click the Upgrade button to start the upgrade.

This manual is also suitable for:
