AMPLIFIER SECTION

Bass amplifier short term output power
Treble amplifier short term output power
(Long term output power is limited by driver protection circuitry)
Amplifier system THD at nominal output
System Signal to Noise ratio, A-weighted
Bass
Treble
Mains voltage
Power consumption
ISS active
Idle
Full output (short term)
SIGNAL PROCESSING SECTION
Analog signal input connector XLR female, balanced 10 kOhm
Maximum analog input signal
Analog input sensitivity (100 dB SPL at 1 m)
Analog input gain selection, rotary control
Digital signal input connector XLR female 110 Ohm
Digital signal output / Thru connector XLR male 110 Ohm
Digital audio input
Word length
Sample rate
Digital input sensitivity (100 dB SPL at 1 m )
Digital input gain sensitivity, rotary control
Control network
Type
Connection
Crossover frequency
GLM software frequency response adjustment*
TM
Parametric notch filters
Shelving filters
System room response calibration
* The notch and shelving filters adjustments, AutoCal
Genelec Document D0133R003 Copyright Genelec Oy 9.2017. All data subject to change without prior notice.
and GLM manual system calibration features are part of the Genelec Loudspeaker Manager (GLM
TM TM
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email genelec@genelec.com
8340A
150 W
150 W
<0.01%
> 109 dB
> 110 dB
100-240 VAC 50/60 Hz
< 1 W
12 W
180 W
8340A
pin 1 gnd
pin 2 non-inverting,
pin 3 inverting
+25.0 dBu
-6 dBu
Adjustable from +6 to -6 dBu
AES/EBU Single Wire
AES/EBU Single Wire
16 - 24 bits
32 - 192 kHz
-30 dBFS
Adjustable from +6 to -6 dBu
Proprietary GLM™ network
2 RJ45, CAT5 cables
2.6 kHz
2 LF and 2 HF
Genelec GLM AutoCal™ AutoCal
Stand-alone*
