- Page 1 MX-1100 Quick Reference Guide 2020 June 05 Revision: 1.0.0.10...
- Page 2 Precautions To reduce the risk of injury or equipment damage, observe the following precautions when you install the Cognex product: Route cables and wires away from high-current wiring or high-voltage power sources to reduce the risk of damage or malfunction from the following causes: over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply.
- Page 3 MX-1100 Layout Layout Scanner head (rotatable by 45°) Indicator LEDs Side trigger buttons Power button Touch screen Home button Speaker vents Recessed area for mobile camera Slider to lock battery cover Battery cover Lanyard hook End cap of pistol grip* Trigger button on the pistol grip* *Pistol grip is optional...
- Page 4 MX-1100 Accessories Accessory Battery for reader (3120 mAh) DMA-MTBATTERY-01 Battery for pistol grip accessory (3070 mAh) DMA-HHBATTERY-01 Pistol grip DMA-GRIP-01 Note: The grip features its own trigger button and an additional battery which can be charged via the charging station. DMA-HOLSTER-01 Belt holster DMA-HOLSTER-02...
- Page 5 Accessory USB Type-C battery charger kits 1. DMA-MXUSB-01 USB Type-C Battery Cover 2. DMA-MXUSB-02 3. DMA-MXUSB-03 (DMA-MXUSB-00) + USB Type-C 3Amp Car Charger (DMA-MXUSB-CHARGER) USB Type-C Battery Cover (DMA-MXUSB-00) + Handstrap (DMA-MXSTRAP-00) USB Type-C Battery Cover (DMA-MXUSB-00) + USB Type-C 3Amp Car Charger (DMA-MXUSB-CHARGER) + Handstrap (DMA-MXSTRAP- Passive car holder...
- Page 6 Accessory DMA-COVERKIT-S6 Top Cover DMA-COVERKIT-S7 DMA-COVERKIT-S8 DMA-COVERKIT-S9 DMA-COVERKIT-I5 DMA-COVERKIT-I6 DMA-COVERKIT-S4 DMA-COVERKIT-S5 DMA-COVERKIT-J3 DMA-COVERKIT-J327 DMA-COVERKIT-J330 DMA-COVERKIT-A3 DMA-COVERKIT-X4 DMA-COVERKIT-N42 DMA-COVERKIT-s10e DMA-COVERKIT-iX...
-
Page 7: Dimensional Drawings
Dimensional Drawings... -
Page 8: Field Of View And Reading Distances
Field of View and Reading Distances Working Distance Horizontal Values Vertical Values = 15 mm = 6.4 mm = 4.09 mm = 210 mm = 148.31 mm = 94.67 mm = 420 mm = 301.14 mm = 192.22 mm... - Page 9 Distances in mm / 1D min code Distances in mm / 2D min code 25-105 5 MIL 15-70 5 MIL 25-158 7.5 MIL 15-105 7.5 MIL 25-210 10 MIL 15-140 10 MIL 25-420 20 MIL 15-275 20 MIL Note: Due to tolerances, ranges can vary by +/- 5 mm for small codes to +/- a couple of centimeters for large codes.
-
Page 10: Assembling The Reader
Plug the pistol grip cable into the grip connector. Insert the reader battery. Assemble the reader with the pistol grip and tighten the screws. Note: For details, see the MX-1100 Reference Manual. For a list of supported mobile devices, please contact Cognex. -
Page 11: Installation
Windows Start menu, select the following to access the manual: All Programs > Cognex > DataMan Software v6.1.8 > Documentation. Note: If a standard component is missing or damaged, immediately contact your Cognex Authorized Service Provider (ASP) or Cognex Technical Support. CAUTION: All cable connectors are keyed to fit the connectors on the reader. -
Page 12: Imager Specifications
MX-1100 Specifications Specification MX-1100 Imager 510 g (675 g with pistol grip) Weight Operating Temperature 0ºC— +40ºC (+32ºF — +104ºF) 0ºC — +35ºC (+32ºF — +95ºF) Charging Temperature Maximum Humidity < 95% (non-condensing) Environmental IP65 1-D : UPC/EAN/JAN, Codabar, Interleaved 2 of 5, Code 39, Code 128, Code 93, Codes Pharmacode, GS1 DataBar, PDF417, Micro PDF417 2-D : Data Matrix, QR Code, and MicroQR Code, DotCode and postal code... -
Page 13: Charging Station Specifications
Charging Station Specifications Specification Charging Station Weight 380 g Operating Temperature 0ºC — +40ºC (+32ºF — +104ºF) Storage Temperature -40ºC — +60ºC (-40ºF — +140ºF) Maximum Humidity 95% (non-condensing) 24 V, 24 W maximum LPS or NEC Class 2 power supply Power Supply Requirements 0.5A (inductive) and 1A (non-inductive) -
Page 14: Compliance Statements
FCC Part 15, Subpart B Class A Canada ICES-003, Class A European Community Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. Safety and Regulatory European Compliance This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. - Page 15 Korea MX-1000: Regulatory Model 1AA7 (inductive), R00078 (non-inductive) For European Union Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE). This product has required the extraction and use of natural resources for its production.
- Page 16 KN24 Registration number: MSIP-REM-CGX-DMA-MT-BASE For European Union Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE). This product has required the extraction and use of natural resources for its production.
- Page 17 In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems for product disposal. Those systems will reuse or recycle most of the materials of the product you are disposing in a sound way. The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal.
- Page 18 中 国 大 陆 RoHS (Information for China RoHS Compliance) 根 据 中 国 大 陆 《 电 子 信 息 产 品 污 染 控 制 管 理 办 法 》 ( 也 称 为 中 国 大 陆 RoHS)， 以...
- Page 19 Copyright © 2020 Cognex Corporation. All Rights Reserved.
