Control Stick Tension Adjustment - JETI model DC-14 II User Manual

2. Loosen both machine screws securing the control stick
assembly.
3. Adjust (rotate) to desired position.
4. Securely tighten both machine screws securing the control stick
assembly.
5. Reconnect transmitter battery pack and reinstall radio back
cover and cover screws.

4.3.3 Control Stick Tension Adjustment

The stick gimbal tension is fully adjustable for each axis. This allows
you to fully customize your radio's control feel. Simply adjust each
gimbal's spring to your desired tension.
1. Switch off the transmitter and remove the 8 screws that secure
the radio back cover. Next, remove the radio back cover.
Be sure to disconnect the transmitter battery pack
connector.
2. Use indicated machine adjustment screws to change the
desired spring tension. By turning the screw countercloc
kwise, you will loosen spring tension. As a result the moving
resistance of the control stick will decrease.
computer radio control system
2
4
3
4
2
By turning the screw clockwise, you will tighten spring tension. As
a result the moving resistance of the control stick will increase.
3. Reconnect transmitter battery pack and reinstall radio back
cover and cover screws.
27
EN
2
2
