ConneCtinG the Drive
Refer to the illustration below when following the instructions on the next page.
(Model PDHDxxxUSE-72 shown)
AC Adapter
To AC outlet
Power Supply
USB 2.0/1.1 Port
Power Port
USB Cable
9
On-O Switch
eSATA Port
To computer or
USB hub
