- Page 1 59232XANR 2MP Starlight Network PTZ Camera Quick Installation Guide V1.0.1 Dahua Technology USA Inc.
-
Page 2: Foreword
General This manual offers reference material and general information about the basic operation, maintenance, and troubleshooting for a Dahua Camera. Read, follow, and retain the following safety instructions. Heed all warning on the unit and in the operating instructions before operating the unit. - Page 3 Please contact the customer service for the latest program and supplementary documentation. Video loss is inherent to all digital surveillance and recording devices; therefore Dahua cannot be held liable for any damage that results from missing video information. To minimize the occurrence of lost digital information, Dahua recommends multiple, redundant recording systems, and adoption of backup procedure for all data.
- Page 4 Legal Notices Copyright This user guide is ©2020, Dahua Technology USA Inc. This user guide is the intellectual property of Dahua Technology USA Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered...
-
Page 5: Important Safeguards And Warnings
Important Safeguards and Warnings This chapter describes the contents covering proper handling of the device, hazard prevention, and prevention of property damage. Read these contents carefully before using the device, comply with them when using, and keep it well for future reference. Installation and Maintenance Professionals Requirements All installation and maintenance professionals must have adequate qualifications or ... - Page 6 have the same characteristics as the original parts. Unauthorized parts may cause fire, electrical shock, or other hazards. Dahua is not liable for any damage or harm caused by unauthorized modifications or repairs. Perform safety checks after completion of service or repairs to the unit.
- Page 7 Contact the manufacturer or a qualified service representative to service the camera or to replace a component, including the desiccant. Dahua recommends the use of a thunder-proof device in concert with the unit. Do not touch the CCD or the CMOS optic sensor. Use a blower to clean dust or dirt on the ...
-
Page 8: Cybersecurity Recommendations
Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity Change Passwords and Use Strong Passwords The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible. - Page 9 Change ONVIF Password Older IP camera firmware does not automatically change the ONVIF password when the system credentials are changed. Update the camera’s firmware to the latest revision or manually change the ONVIF password. Forward Only Ports You Need ...
- Page 10 Connect IP Cameras to the PoE Ports on the Back of an NVR Cameras connected to the PoE ports on the back of an NVR are isolated from the outside world and cannot be accessed directly. Isolate NVR and IP Camera Network ...
-
Page 11: Table Of Contents
Table of Contents Foreword ............................... I Important Safeguards and Warnings....................IV Cybersecurity Recommendations ....................VII Table of Contents ..........................X 1 Overview ............................1 Parts List ..........................1 User-supplied Tools and Hardware ................... 1 Dimension ..........................2 2 Installing the Camera ........................3 Preparing for Installation ...................... -
Page 12: Overview
Overview The 2 MP Starlight IR PTZ Dome camera features a 1/2.8-in. STARVIS™ CMOS imager with a 32x optical zoom lens, and provides an all in one solution for capturing long-distance video surveillance for outdoor applications. The camera uses the Smart H.265+ video compression standard to improve encoding efficiency while preserving high-quality video. -
Page 13: Dimension
Dimension... -
Page 14: Installing The Camera
Note: Dahua recommends attaching a “drip loop” (flex or hard conduit) during installation to ensure condensation does not form in the mount or the conduit. -
Page 15: Wiring
Wiring The dome camera includes the following wiring bundles: Wire Color Connection Power 24 VAC Yellow/Green Earth Ground Black 24 VAC Video/Control Black RJ-45 Ethernet Alarm Alarm IN 1 Brown Alarm IN 2 Yellow/Green Alarm GND Blue Alarm OUT 1 Green Alarm COM 1 Audio... -
Page 16: Alarm Output - Level Application
2.4.2 Alarm Output – Level Application Use this alarm output configuration if the output triggers an external device by increasing the voltage. The alarm must increase the external pull-up resistance to trigger (high level) the device. The maximum external pull-up level is 5 V and the maximum port current is 5 mA. Once the output increases the pull-up resistance, the alarm decreases the output voltage to the normal state (low level) at less than 0.8 V. -
Page 17: Locally Storing Data
Certain cameras include a SDHC card slot for onboard storage that support a 128 GB Micro SD card. Dahua recommends using a SanDisk Extreme Micro SD card (or an equivalent substitute) as these cards have been fully tested without issue and the SanDisk Extreme line is better suited for constant recording. -
Page 18: Mounting The Camera
A readily accessible 2-pole disconnect device with a contact separation of at least 3 mm must be incorporated. Note: Dahua recommends attaching a “drip loop” (flex or hard conduit) during installation to ensure condensation does not form in the mount or the conduit. -
Page 19: Preparing The Camera
2.7.1 Preparing the Camera The Network PTZ camera comes with the PFB300S Wall Mount and the PFA110 Mount Adapter, the installer must supply the following hardware: Four (4) bolts, washers or other fastening hardware to secure the wall mount to the ... -
Page 20: Insert A Microsd Card
2.7.3 Insert a MicroSD Card The Micro SD card slot is located on the actual camera module. Loosen the four (4) screws from the rear panel on the back of the dome. Remove the panel. Unscrew the three (3) screws from the top of the camera module housing. Remove the camera module housing. -
Page 21: Mounting The Camera To A Wall
Mounting the Camera to a Wall Place the PFB300S Wall Mount against the wall and mark the location of the center hole and the four perimeter mounting holes. Pre-drill the four perimeter holes as marked on the wall for the expansion bolts, using a drill bit that is no wider than the expansion bolt. - Page 22 Pull the composite cable from the dome through the adapter block and pull it out of the other end of the wall mount bracket. Line up the hook at the top of the dome enclosure with the inside hole of the adapter block and then push it to the end.
-
Page 23: Network Configuration
Network Configuration Initialize the device configure the IP setting with the Dahua ConfigTool or via the device’s web interface. Device initialization is available on select models, and it is required at first use and after device is being reset. -
Page 24: Modifying The Ip Address
Set and confirm the password of the devices, and then enter a valid email address. Click Next. Select the options according to your needs and then click OK. Click Finish. Modifying the IP Address Modify the IP address of one or multiple devices at one time. This section provides ... -
Page 25: Configuring Alarms
Launch Internet Explorer and type the modified camera IP address in the address bar. Internet Explorer opens the Login page. Type the Username and Password for the camera. (The default Username and Password is “admin”). Then, click Login. Install the controls according to the system prompt. Once the controls are installed IE displays the Web Interface main page. -
Page 26: Configuring Local Sd Card Recording
Access the Web Interface for the device and click the Setup tab. Expand the Event menu, then choose the Alarm page. Set the alarm input and output parameters in the Relay Activation page. Set the parameters for the alarm inputs. Check the Enable box to activate the chosen alarm input (Alarm 1 or Alarm 2). - Page 27 Select the event from the Event Type pull-down menu (No SD Card, Capacity Warning, SD Card Error). Check the Enable box to activate the alarm for this event. Check the Relay-out box to enable a relay alarm. Then, specify the time in seconds to delay the alarm relay output (10 s to 300 s).
- Page 28 Dahua Technology USA 23 Hubble Irvine, CA 92618 Tel: (949) 679-7777 Fax: (949) 679-5760 Support: 877-606-1590 Sales: sales.usa@dahuatech.com Support: support.usa@dahuatech.com © 2020 Dahua Technology USA. All rights reserved. Design and specifications are subject to change without notice.
