Projector
Operating Instructions
Before operating the unit, please read this manual and supplied Quick Reference Manual
thoroughly and retain it for future reference.
VPL-EW578/EW575/EW455/EW435
VPL-EX575/EX570/EX455/EX450/EX435/EX430
Not all models are available in all countries and area. Please check
with your local Sony Authorized Dealer.
© 2016 Sony Corporation
4-689-816-12 (1)

Advertisement

Table of Contents
loading

Related Manuals for Sony VPL-EW575

Summary of Contents for Sony VPL-EW575

  • Page 1 Before operating the unit, please read this manual and supplied Quick Reference Manual thoroughly and retain it for future reference. VPL-EW578/EW575/EW455/EW435 VPL-EX575/EX570/EX455/EX450/EX435/EX430 Not all models are available in all countries and area. Please check with your local Sony Authorized Dealer. © 2016 Sony Corporation...

  • Page 2: Table Of Contents

    Table of Contents The Function Menu ......29 Overview The Operation Menu ......30 Location and Function of Controls ..4 The Connection/Power Menu ...31 Main Unit ........4 The Installation Menu ......34 Terminal ........5 The Information Menu .....35 Remote Commander and Control Panel Keys .........
  • Page 3 Projecting an Image ....48 Index ..........97 Connection Settings ....49 Using the Controller ....50 One-Click projecting function ..50 Option format ......51 Use Projector Station for Network Presentation without installing it to the computer......52 Error code list of Projector Station for Projector Station for Network Presentation ......53 Playing Video and Audio...

  • Page 4: Location And Function Of Controls

    B Overview Location and Function of Controls Main Unit j Ventilation holes (exhaust) Caution Do not place anything near the ventilation holes as this may cause internal heat buildup. Do not place your hand near the ventilation holes and the circumference as this may cause injury.

  • Page 5: Terminal

    Terminal VPL-EW578 VPL-EW575/EW455/EW435/EX575/EX455/EX435 VPL-EX570/EX450/EX430 Input (pages 9, 11) a INPUT A c INPUT C Video: RGB/YP input terminal Video: HDMI input terminal (HDMI) (RGB/YP Audio: HDMI input terminal (HDMI) Audio: Audio input terminal (AUDIO) d INPUT D b INPUT B...
  • Page 6 e INPUT E l USB terminal (Type A) ( (pages 15, 56) HDBaseT terminal/LAN terminal (page 36) m USB terminal (Type B) ( Use a straight CAT5e or CAT6 shielded (page 54) LAN cable (not supplied). n Microphone input ( f S VIDEO (S VIDEO IN) Video: S video input terminal (S VIDEO Note...

  • Page 7: Remote Commander And Control Panel Keys

    Remote Commander and Control Panel Keys Remote Commander d Adjusting the image (page 17) ASPECT key (page 25) KEYSTONE key (page 19) PATTERN key (page 21) INPUT ECO MODE APA (Auto Pixel Alignment) key (page 21) MENU RESET Note Use this key when inputting a computer ENTER signal via the RGB input terminal RETURN...
  • Page 8 Notes User *1: Use this key when inputting a Lamp Mode High computer signal. But it may not be Constant Brightness used depending on the resolution of Auto Power Saving the input signal. With No Input With Static Signal Lamp Dimming *2: VPL-EW578/EW575/EW455/ Standard Standby Mode...

  • Page 9: Connecting The Projector

    B Preparation Connecting the Projector Notes • Make sure all the equipment is powered off when connecting the projector. • Use the proper cables for each connection. • Insert the cable plugs firmly; Loose connections may reduce performance of picture signals or cause a malfunction.
  • Page 10 EX575/EX455/EX435. • Use HDMI-compatible equipment which has the HDMI Logo. • Use a high speed HDMI cable(s) on which the cable type logo is specified. (Sony products are recommended.) • The HDMI terminal of this projector is not compatible with DSD (Direct Stream Digital) Signal or CEC (Consumer Electronics Control) Signal.

  • Page 11: Connecting A Video Equipment

    USB terminal (Type A) ( For connecting a USB wireless LAN module IFU-WLM3 (not supplied) (“Presentation Function via Network” (page 47)). Wireless router, access point USB wireless LAN module IFU-WLM3 (not supplied) Computer Notes • Undesignated USB wireless LAN modules do not work. •...
  • Page 12 VIDEO IN For connecting video equipment with a video output terminal. Audio cable (Phono plug × 2 – stereo mini plug) (not supplied) Audio output terminal Video output Video equipment terminal Video cable (not supplied) Note The audio input terminal is available only on VPL-EW578/EW575/EW455/EW435/EX575/ EX455/EX435.

  • Page 13: Connecting A Hdbaset Tm Equipment

    EX575/EX455/EX435. • Use HDMI-compatible equipment which has the HDMI Logo. • Use a high speed HDMI cable(s) on which the cable type logo is specified. (Sony products are recommended.) • The HDMI terminal of this projector is not compatible with DSD (Direct Stream Digital) Signal or CEC (Consumer Electronics Control) Signal.
  • Page 14 -Shielded type (covering connectors) -Straight wire connection -Single wire • When installing the cables, use a cable tester, cable analyzer, or similar device to check if the cables meet the CAT5e or higher requirement. If there is a transit connector between this unit and the HDBaseT transmitter, include it when measuring.

  • Page 15: Connecting A Microphone

    Connecting a microphone Microphone ( For connecting a microphone. Microphone (not supplied) Notes • The microphone input is available only on VPL-EW578/EW575/EW455/EW435/EX575/EX455/ EX435. • Only dynamic microphones are supported. Connecting a USB memory device USB terminal (Type A) ( For connecting a USB memory device (“Using USB Media Viewer” (page 56)). USB memory device (not supplied) Connecting an External Monitor and Audio Equipment...

  • Page 16: Projecting/Adjusting An Image

    B Projecting/Adjusting an Image Projecting an Image The size of a projected image depends on the distance between the projector and screen. Install the projector so that the projected image fits the screen size. For details on projection distances “Projection Distance” (page 76) and projected image sizes, see *The display image is VPL-EW578.

  • Page 17: Adjusting The Focus, Size, And Position Of The Projected Image

    Adjust the focus, size and position of the projected image (page 17). Adjusting the Focus, Size, and Position of the Projected Image Focus Size (Zoom) Position Focus ring Foot adjust button Zoom ring Front feet (adjustable) Projecting an Image...
  • Page 18 Adjusting the tilt of the projector with the front feet (adjustable) By changing the tilt of the projector with the foot adjust buttons/front feet (adjustable), you can adjust the position of the projected image. How to adjust the angle 1 Press and hold the foot adjust buttons. 2 Lift up the front of the projector to adjust the angle.
  • Page 19 Correcting trapezoidal distortion of the projected image (Keystone feature) Normally the Keystone feature automatically adjusts the projected image. The Keystone feature may not work automatically if the screen is tilted. In this case, set Keystone manually. 1 Press the KEYSTONE key on the remote commander or select V Keystone in the Installation menu.
  • Page 20 Fitting the projected image to the screen (Digital Shrink adjustment) If the projected image exceeds the size of the screen, you can shrink and adjust the position of it. 1 Select “Rid. digitale” in the Installation menu. 2 Set the shrinking rate. Press the V/v/B/b key to adjust the value.
  • Page 21 Displaying a pattern You can display a pattern for adjusting the projected image or a grid pattern with the PATTERN key on the remote commander. Press the PATTERN key again to restore the previous image. You can use a grid pattern as a guide to write text or to draw lines and shapes on the whiteboard or blackboard without using a computer.

  • Page 22: Turning Off The Power

    Turning Off the Power Press the ?/1 key on the unit or the remote commander. The projector starts shutdown and turns off. If you press the ?/1 key within 10 seconds again, shutdown is cancelled. Note Do not turn off the projector soon after the lamp lights. It may cause a malfunction of the lamp (does not light ,etc.).

  • Page 23: Using A Menu

    B Adjustments and Settings Using a Menu Using a MENU Note The menu displays used for the explanation below may be different depending on the model you are using. operations in step 3 and then press the Press the MENU key to display the ENTER key to register the setting.

  • Page 24: The Picture Menu

    The Picture Menu The Picture is used to adjust the picture for each input signal. Items Item descriptions Picture Mode Vivid: Projects the image with a bright, explicit, and vivid picture. Dynamic: Emphasizes the contrast to produce a dynamic and vivid picture. Standard: Provides an image which is natural and well balanced.

  • Page 25: The Screen Menu

    The Screen Menu The Screen menu is used to adjust the size, position and aspect ratio of the projected image for each input signal. Items Item descriptions Aspect Changes the aspect ratio of the projected image (page 27). VPL-EW578/EW575/ 4:3: Displays the image to fit the maximum projected image size EW455/EW435: When with an aspect ratio fixed to 4:3.
  • Page 26 Items Item descriptions Adjust Signal Adjusts the image of computer signal. Use this item if the edge of the image is cut and reception is bad. *2 *3 Automatically adjusts the projected image to an optimum quality when you press the ENTER key (page 7). Phase Adjusts the dot phase of the display pixel and the input signal.
  • Page 27 Aspect VPL-EW578/EW575/EW455/EW435 *1: If you select “Normal,” the image is projected in the same resolution as the input signal without changing the aspect Input signal Recommended setting value and ratio of the original image. projected image *1 *2 *3 Full1 *2: If you select “Full2,”...
  • Page 28 VPL-EX575/EX570/EX455/EX450/ *1: If you select “Normal,” the image is EX435/EX430 projected in the same resolution as the input signal without changing the aspect ratio of the original image. Input signal Recommended setting value and projected image Full1 *2: If you select “4:3,” the image is projected to fit the projected image size, regardless of the aspect ratio of the image.

  • Page 29: The Function Menu

    The Function Menu The Function menu is used for setting various functions of the projector. Items Item descriptions Volume The higher the value, the louder an audio volume and the lower the value, the lower the audio volume. Mic Volume Adjust the volume of the microphone.

  • Page 30: The Operation Menu

    Note *1: You will not be able to use the projector if you forget your password. If you call qualified Sony personnel because you have forgotten the password, you will be asked to verify the projector’s serial number and your identity. (This process may differ in other countries/regions.) Once your identity has been confirmed, we will provide you with the password.

  • Page 31: The Connection/Power Menu

    The Connection/Power Menu The Connection/Power menu is used for setting for the connections and power. Items Item descriptions LAN Settings IP Address Auto (DHCP): The IP address is assigned automatically from the Setup DHCP server such as a router. Manual: To specify the IP Address manually. WLAN Settings WLAN On/Off: Set the wireless output of the USB wireless LAN module (not...
  • Page 32 Items Item descriptions Input-A Signal Sel. Auto/Computer/Video GBR/Component: When set to “Auto,” selects the type of video signal input automatically when “Input-A” is selected. *9 *10 Lamp Mode High/Standard/Low/Auto : When set to “High,” the image becomes brighter, and power consumption becomes higher. When set to “Low,”...
  • Page 33 To change the settings for “Access Pt.,” go to the Web page. For details, see “Setting the WLAN Network of the projector” (page 39). If “Access Pt.” is set, it is more convenient that you set “Display Setting” in “Network Presentation”...

  • Page 34: The Installation Menu

    The Installation Menu The Installation menu is used for installing the projector. Items Item descriptions Image Flip HV/H/V/Off: Flips the projected image horizontally or vertically according to the installation method. Installation Attitude Right Side Up/Upside Down/Link to Image Flip: Change the cooling setting to suit to the installation attitude.

  • Page 35: The Information Menu

    The Information Menu The Information menu is used to check projector status, such as total usage time of the lamp. Items Item descriptions Model Name Displays the model name. Serial No. Displays the serial number. fH/fV Displays the horizontal/vertical frequency of the current input signal. Signal Type Displays the type of the current input signal.

  • Page 36: Using Network Features

    For download or detailed method of using Projector Station for Network Control, please access the following URL. http://pro.sony.com/bbsc/ssr/cat-projectors/resource.downloads Contact your local Sony dealer for detailed information of Projector Station for Network Control. Displaying the Control Window of the Projector with a Web Browser Connect the LAN cable (page 10).

  • Page 37: Confirming The Information Regarding The Projector

    Page Switching buttons Note If you forget your password, consult with Setting the access limitation qualified Sony personnel. You can limit a user for accessing any The password will be reset with your permission. particular page.

  • Page 38: Operating The Projector From A Computer

    Lamp Reminder (Lamp1): Set the Operating the Projector from timing of the email report for lamp a Computer replacement. To reset Lamp Reminder, execute “Lamp Timer You can control the projector from the Reset” on the projector (page 29). computer on the Control page. Maintenance Reminder: Set the timing of the email report for maintenance.

  • Page 39: Setting The Lan Network Of The Projector

    Requires the use of POP Authentication before sending email (POP before SMTP): Check this check box to arrange for POP authentication to be performed before sending e-mail. Incoming Mail Server (POP3): Enter the address of the incoming-mail server (POP3) to be used for POP authentication.
  • Page 40 To use the wireless LAN network, a USB Channel Setting: Select the channel of wireless LAN module IFU-WLM3 (not the access point if “WLAN Network” supplied) is necessary. is set to “Access Point” (page 40). Encryption Type: Select the security method of the access point from the Click the [WLAN Setting] to open the followings if “WLAN Network”...
  • Page 41 (b) Input the settings for Client Key: Input the password for security method of the access point according Mode. to the selected encryption type as When the USB wireless LAN module is below; activated as a client, set the items for the client (set the items for the access point Encyption Password...

  • Page 42: Setting The Custom Labels For The Input Terminals Of The Projector

    Setting the Custom Labels for the Input Terminals of the Projector Change the label names for the input terminals that will be displayed on the projected screen on the Set up page. The entered label names will not be applied unless you click on [Apply].
  • Page 43 Click on [Advanced Menu] to display changed. Only four alphanumeric characters can be input. The factory the buttons for more settings. default setting is “SONY.” It is recommended that the community name be changed from the factory setting to avoid unnecessary access to the projector from other computers.
  • Page 44 -Port No.: default setting is “SONY.” It is Input the server port of ADCP. The recommended that the community name factory default setting is “53595.” be changed from the factory setting to -Timeout: avoid unnecessary access to the Input the time (seconds) until ADCP projector from other computers.
  • Page 45 -Password: (f) Set the IP Control Sync. Input the authentication password for PJ function* Link. For the factory default password, refer to the PJ Link specifications. (e) Set the system service. System service setting area IP Control IP Control Sync. Sync.
  • Page 46 (g) Reset the network settings. Reset button Reset Reset: Reset all Web browser settings to their factory defaults. Using Network Features...

  • Page 47: Presentation Function Via Network

    Presentation Function via Network requires installation of Projector Station for Network Presentation (supplied CD-ROM). For information on updates of Projector Station for Network Presentation, visit Sony’s web site: https://www.servicesplus.sel.sony.com/ System requirements for using the application are as follows. Windows XP: Home/Professional...

  • Page 48: Projecting An Image

    Start Projector Station for Network AP Mode: Select this mode if “Display Setting” in “Network Presentation” is Presentation. set to “AP Mode” on the projector’s For Windows: menu. In this mode, the computer Select [Start]-[All Programs]-[Projector connects to the USB wireless LAN Station for Network Presentation] on the module of the projector that operates as computer.

  • Page 49: Connection Settings

    b) For AP Mode Notes Refer to the network information on the • When a projector is connected to a network projected screen of the projector that you via a wireless connection, if the “SSID” is want the computer connect to, and input changed from the factory default, it may not the SSID and the Connection CODE.

  • Page 50: Using The Controller

    Item Item descriptions Items Functions Wireless Input the wireless password Projection Not projecting an image. Password of the SSID. If open system method Project in full screen. authentication is used, input Project in the left half of of the wireless password is the screen.

  • Page 51: Option Format

    Connection CODE: On projector that you want the computer to connect to. For Windows Wireless Assign the wireless C:\Program Files (x86)\Sony\Projector password password for the SSID. If the Station for Network Presentation\Network security method is open Presentation.exe -connect 192.168.1.187:on:1 system authentication, input “open.”...

  • Page 52: Use Projector Station For Network Presentation Without Installing It To The Computer

    Connection CODE: Off Double click “Projector Station for Network Presentation” in the folder in For Windows which the application is installed. C:\Program Files (x86)\Sony\Projector Notes Station for Network Presentation\Network • You can use this application only on the OS Presentation.exe -wifi VPL012ABC: that supports this application.

  • Page 53: Error Code List Of Projector Station For Projector Station For Network Presentation

    Error code list of Projector Station for Projector Station for Network Presentation Error code Meaning/Measure Page NPR-E1701 Failed while opening the WLAN device of the computer. Check that the WLAN function of the computer operates normally. NPR-E1702 Failed while scanning the access point. Check that the WLAN function of the computer operates normally.

  • Page 54: Playing Video And Audio Using Usb Connection

    B Playing Video and Audio using USB Connection Playing Video and Audio using USB Connection You can also play video and audio simply by connecting the projector and computer with a USB A-B cable (not supplied). Playing video and audio using USB connection requires to start USB Display. System requirements for using the application are as follows.
  • Page 55 For Mac: Items Functions Start projecting audio/ video. Pause projecting audio/ video. Stop projecting audio/ video (the screen turns black). Display information about USB Display. Playing Video and Audio using USB Connection...

  • Page 56: Usb Media Viewer

    B USB Media Viewer Using USB Media Viewer You can browse image files stored in a USB memory device inserted in the USB terminal of the projector, without using a computer. Supported storage media and file format: • Supported storage media: USB flash memory •...

  • Page 57: Thumbnail Mode

    Thumbnail Mode The image files in the folder are displayed as a thumbnail list. Option menu Press the V/v/B/b key on the remote commander to select an image, then press the ENTER key. The option menu appears in the lower part of the screen. Option Menu You can select the display order of thumbnails and display method of image files.

  • Page 58: Display Mode

    Display Mode In display mode, you can view a selected image in full screen view. Option menu Press the ENTER key on the remote commander. The option menu appears in the lower part of the screen. Option Menu Items Item descriptions Hide the option menu.
  • Page 59 Option Menu Items Item descriptions Hide the option menu. Return to the thumbnail mode (page 57). Display the previous image. Display the next image. Press the V/v key to change the slideshow time interval. After 3 seconds, display the next image. After 5 seconds, display the next image.

  • Page 60: Indicators

    B Others Indicators You can check the projector status or abnormality by checking the lighting/flashing status of the ON/STANDBY indicator and WARNING indicator on the front. If the indicators flash in red, address the problem in accordance with “Warning indicators and remedies” (page 61). ON/STANDBY WARNING indicator...
  • Page 61 If the indicators flash in a manner other than described above, unplug the AC power cord and make sure the ON/STANDBY indicator turns off, then plug the AC power cord into the wall outlet and turn on the projector. If the problem still persists, consult with qualified Sony personnel. Indicators...

  • Page 62: Messages List

    Messages List When any of the messages listed below appears on the projected image, address the problem in accordance with the table below. Messages Meaning/Remedy Page High temp.! Lamp off in Check the items below. 4, 34, 1 min. • Check if nothing is blocking the ventilation holes. •...

  • Page 63: Troubleshooting

    Troubleshooting Before asking to have the projector repaired, try to diagnose the problem, following the instructions below. Symptoms Remedy Page The power is not turned Check if the AC power cord is firmly connected. – When the “Control Key Lock” is set to “On,” you cannot turn on the projector using the ?/1 key on the projector.
  • Page 64 Symptoms Remedy Page The image is dark/too The settings for “Brightness,” “Contrast,” and “Lamp Mode” 24, 32 bright. affect brightness of the image. Check if the value is appropriate. The image will be dark when the lamp is burnt out. Check 35, 66 “Lamp Timer,”...
  • Page 65 Symptoms Remedy Page The image is not Change the input terminal to project the image properly. – projected properly when the projector is connected via the HDBaseT terminal and the cables are inserted or removed from other terminals. (VPL-EW578 only) The sound of the fan can If “Standby Mode”...

  • Page 66: Replacing The Lamp

    Grab Notes • If the lamp breaks, contact qualified Sony personnel. Do not replace the lamp yourself. • When removing the lamp, be sure to pull it out straight, by holding the designated location. If you touch a part of the lamp other than the designated location, you may be burned or injured.
  • Page 67 Dispose according The power will not turn on if the lamp is to applicable local, state/ not secured properly. province and federal laws. Close the lamp cover and tighten the For additional information, 1 screw. see www.sony.com/mercury Replacing the Lamp...

  • Page 68: Cleaning The Air Filter

    If the dust cannot be removed from the air filter even after cleaning, replace the air filter with a new one. For details on a new air filter, consult with qualified Sony personnel. Caution If you continue to use the projector even Reattach the air filter cover to the unit.

  • Page 69: Specifications

    Specifications Items Descriptions Projection system 3 LCD system Display device Effective display VPL-EW578/EW575: 0.75 inch (19.0 mm), size 3 plate panels, Aspect ratio 16:10 VPL-EW455/EW435: 0.59 inch (15.0 mm), 3 plate panels, Aspect ratio 16:10 VPL-EX575/EX570/EX455/EX450/EX435/EX430: 0.63 inch (16.0 mm), 3 plate panels, Aspect ratio 4:3 Effective picture VPL-EW578/EW575/EW455/EW435: 3,072,000 pixels elements...
  • Page 70 Items Descriptions INPUT OUTPUT INPUT A RGB/YP input terminal: Mini D-sub 15-pin (Computer/video) female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative, 75 ohms terminated, RGB/P : 0.7 Vp-p ± 2 dB, 75 ohms terminated, Sync signal: TTL level high impedance, positive/negative Audio input terminal (VPL-EW578/EW575/EW455/ EW435/EX575/EX455/EX435 only): Stereo mini jack,...
  • Page 71 VPL-EW578: 100 V to 240 V AC, 3.5 A - 1.5 A, requirements 50/60 Hz VPL-EW575/EW455/EX575/EX455/EX435: 100 V to 240 V AC, 3.4 A - 1.5 A, 50/60 Hz VPL-EW435: 100 V to 240 V AC, 3.2 A - 1.4 A, 50/60 Hz VPL-EX570/EX450/EX430: 100 V to 240 V AC, 3.1 A -...
  • Page 72 220 V to 240 V AC: 26.7 W (LAN) 19.1 W (optional WLAN module) 27.6 W (all terminals and networks connected) (when “Standby Mode” is set to “Standard”) VPL-EW575/EW455/EW435/EX575/EX570/EX455/ EX450/EX435/EX430: 100 V to 120 V AC: 5.5 W (LAN) 6.0 W (optional WLAN module) 6.2 W (all terminals and networks connected)
  • Page 73 *2: Information on accessories in this manual is current as of November 2016. *3: Not all optional accessories are available in all countries and area. Please check with your local Sony Authorized Dealer. *4: VPL-EW578 only. Design and specifications of the unit, including the optional accessories, are subject to change without notice.
  • Page 74 Pin assignment GND (R) Vertical sync signal HDMI terminal (HDMI, female) GND (G) DDC/SCL GND (B) RS-232C terminal (D-Sub 9-pin, male) T.M.D.S. T.M.D.S. Data2+ Clock Shield T.M.D.S. T.M.D.S. Data2 Shield Clock – T.M.D.S. N.C. Data2 – T.M.D.S. RESERVED Data1+ (N.C.) RXDA T.M.D.S.
  • Page 75 Input terminal Acceptable Input Signals fH[kHz]/ Resolution RGB/ fV[Hz] HDMI RGB Computer signal Input terminal 1280 × 800 49.7/60 fH[kHz]/ Resolution RGB/ fV[Hz] HDMI RGB Digital TV signal 640 × 350 31.5/70 Input terminal 37.9/85 Signal fV[Hz] RGB/ HDMI 640 × 400 31.5/70 37.9/85 480i...

  • Page 76: Projection Distance

    Projection Distance The projection distance is the distance between the front of the lens and the surface of the projected image. The following describes the projection distance and height from the center of the lens to edge of screen by each projected screen size. Height H is the height from the bottom of the projected image (top for ceiling mount) to A (determined by drawing a perpendicular line from the center of the lens to projected image surface).
  • Page 77 Projection distance table (VPL-EW578/EW575) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.72 × 1.08 1.92-3.09 -0.20 (-8) -0.20 (-8)
  • Page 78 Projection distance table (VPL-EW455/EW435) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.72 × 1.08 2.35-3.06 -0.11 (-4) -0.11 (-4)
  • Page 79 Projection distance table (VPL-EX575/EX570) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.63 × 1.22 2.29-3.68 -0.20 (-8) -0.20 (-8)
  • Page 80 Projection distance table (VPL-EX455/EX450) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.63 × 1.22 2.24-2.92 -0.20 (-8) -0.20 (-8)
  • Page 81 Projection distance table (VPL-EX435/EX430) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.63 × 1.22 2.41-2.88 -0.20 (-8) -0.20 (-8)
  • Page 82 Ceiling Installation Height H from center of lens to edge of screen Center of lens Top side Projected image Projection distance L * The number will be minus when the top of the projected image is higher than A. Projection Distance...
  • Page 83 Projection distance table (VPL-EW578/EW575) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.72 × 1.08 1.92-3.09 -0.20 (-8) -0.20 (-8)
  • Page 84 Projection distance table (VPL-EW455/EW435) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.72 × 1.08 2.35-3.06 -0.11 (-4) -0.11 (-4)
  • Page 85 Projection distance table (VPL-EX575/EX570) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.63 × 1.22 2.29-3.68 -0.20 (-8) -0.20 (-8)
  • Page 86 Projection distance table (VPL-EX455/EX450) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.63 × 1.22 2.24-2.92 -0.20 (-8) -0.20 (-8)
  • Page 87 Projection distance table (VPL-EX435/EX430) Unit: m (inches) Height H from center of lens to edge of Projected image size screen Projection Distance L Minimum Projection Maximum Projection Diagonal Width × Height Distance L Distance L 80 inch (2.03m) 1.63 × 1.22 2.41-2.88 -0.20 (-8) -0.20 (-8)

  • Page 88: Dimensions

    Dimensions Top (VPL-EW578/EW575) 365 (14 85 (3 Center of Lens Unit: mm (inches) Dimensions...
  • Page 89 Top (VPL-EX575/EX570) 365 (14 85 (3 Center of Lens Unit: mm (inches) Top (VPL-EW455/EW435/EX455/EX450/EX435/EX430) 365 (14 85 (3 Center of Lens Unit: mm (inches) Dimensions...
  • Page 90 Front Center of Lens Unit: mm (inches) Bottom (VPL-EW578/EW575) 233 (9 38 (1 225.3 (8 Center of Lens 14 ( 14 ( Holes for ceiling mount (M4, Depth 8 ( 31.8 31.8 45.3 57.4 97.5 (3 Unit: mm (inches) Dimensions...
  • Page 91 Bottom (VPL-EX575/EX570) 38 (1 233 (9 225.3 (8 Center of Lens 14 ( 14 ( Holes for ceiling mount (M4, Depth 8 ( 31.8 31.8 57.4 45.3 97.5 (3 Unit: mm (inches) Dimensions...
  • Page 92 Bottom (VPL-EW455/EW435/EX455/EX450/EX435/EX430) 38 (1 233 (9 225.3 (8 Center of Lens 14 ( 14 ( Holes for ceiling mount (M4, Depth 8 ( 31.8 31.8 57.4 45.3 97.5 (3 Unit: mm (inches) Dimensions...

  • Page 93: End User License Agreement

    SOFTWARE prohibit any of the restrictions in this “applets” incorporated into the SOFTWARE) is EULA with respect to such EXCLUDED owned by SONY or one or more of the THIRD- SOFTWARE, such restrictions will not apply to such PARTY SUPPLIERS.
  • Page 94 REQUIREMENTS OR THAT THEY WILL BE services available through the SOFTWARE may be UPDATED, (B) THAT THE OPERATION OF ANY provided by third parties over which SONY has no OF THE SOFTWARE WILL BE CORRECT OR control. USE OF THE CONTENT SERVICE ERROR-FREE OR THAT ANY DEFECTS WILL REQUIRES AN INTERNET CONNECTION.
  • Page 95 OR CONSEQUENTIAL DAMAGES, SO THE Information may be processed, stored or transferred ABOVE EXCLUSION OR LIMITATION MAY to SONY, its affiliates or agents which are located in NOT APPLY TO YOU. countries outside of your country of residence. Data protection and information privacy laws in certain...
  • Page 96 SOFTWARE, if SONY believes in its sole discretion that you are violating or intend to violate this EULA. These remedies are in addition to any other remedies SONY may have at law, in equity or under contract. TERMINATION...
  • Page 97 Index H (Horizontal) ......... 26 HDBaseT connector ........6 High Altitude Mode ........ 34 Hue ............24 AC IN ............6 Acceptable input signal ......75 Adjust Signal ...........26 Image Flip ..........34 Air filter ...........68 Indicators ..........60 Air filter cover/Ventilation holes Information menu ........
  • Page 98 About Trademarks Remote commander ........7 • Adobe and Adobe Acrobat are trademarks Remote Control Receiver ......4 or registered trademarks of Adobe Replacing the lamp ......... 66 Systems Incorporated in the United States Reset ............24 and/or other countries. RS-232C ............
  • Page 99 Sony Corporation...
