2.3 Micro-SD Card Insertion & Termination
The device which is connected at end of line, whether it is a dome camera or keyboard controller,
must have the cable for communication terminated by setting the appropriate DIP switch. Without
proper termination, there is potential for control signal errors. Total length of the cable for
communication should not exceed 4000 ft (1.2 km).
User can install and change Micro-SD card as shown in the following picture.
1. Open the cover.
3. To detach PTZ module from
external housing, please turn
it counterclockwise.
4. Install or change Micro-SD card.
SW1
Terminated
Not terminated
13
2. Remove the screw.
1
ON
OFF
