WOOD PELLET GRILL & SMOKER
IMPORTANT, READ CAREFULLY, RETAIN FOR FUTURE
REFERENCE. MANUAL MUST BE READ BEFORE OPERATING!
GRIL & FUMOIR À GRANULES DE BOIS
IMPORTANT, PRENEZ CONNAISSANCE DE CE DOCUMENT ET
CONSERVEZ-LE POUR RÉFÉRENCE ULTÉRIEURE. VOUS DEVEZ
LIRE CE GUIDE AVANT D'UTILISER LE BARBECUE!
For outdoor and household use only. Not for commercial use.
Réservé à l'usage extérieur et résidentiel uniquement. Non destiné à un usage commercial.
WARNING: Please read the entire manual
before installation and use of this electric,
pellet fuel-burning appliance. Failure to
follow these instructions could result
in property damage, bodily injury or
even death. Contact local building or fire
officials about restrictions and installation
inspection requirements in your area.
AVERTISSEMENT : Veuillez lire l'intégralité
du
manuel
avant
l'installation
et
l'utilisation de cet appareil électronique à
granules. Le non-respect de ces instructions
peut entraîner des dommages aux
biens, des blessures ou même la mort.
Communiquez avec les autorités locales
en matière d'incendie et de bâtiment
concernant les restrictions et les exigences
d'installation dans votre région.
MODEL / MODÈLE : PB0500SP, PB0820SP, PB1000SP, PB1100SP
PART / PIÈCE : 10532, 10534, 10535, 10537, 10564, 10565, 10566, 10567
OWNERS MANUAL
LE MANUEL DU PROPRIÉTAIRE
5005166
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pit Boss SPORTSMAN PB1000SP
Summary of Contents for Pit Boss SPORTSMAN PB1000SP
- Page 1 MODEL / MODÈLE : PB0500SP, PB0820SP, PB1000SP, PB1100SP PART / PIÈCE : 10532, 10534, 10535, 10537, 10564, 10565, 10566, 10567 5005166 OWNERS MANUAL LE MANUEL DU PROPRIÉTAIRE WOOD PELLET GRILL & SMOKER IMPORTANT, READ CAREFULLY, RETAIN FOR FUTURE REFERENCE. MANUAL MUST BE READ BEFORE OPERATING! GRIL &...
-
Page 2: Grill Environment
With all outdoor appliances, outside weather conditions play a big part in the performance of your grill and the cooking time needed to perfect your meals. All Pit Boss® units should keep a minimum clearance of 305mm (12 inches) from combustible constructions and this clearance must be maintained while the grill is operational. -
Page 3: Grill Temperature Ranges
GRILL TEMPERATURE RANGES Temperature readouts on the control board may not exactly match the thermometer. All temperatures listed below are approximate and are affected by the following factors: outside ambient temperature, the amount and direction of wind, the quality of pellet fuel being used, the lid being opened, and the quantity of food being cooked. HIGH TEMPERATURE (205-260°C / 401-500°F) •... -
Page 4: Understanding The Control Board
The plug-in connection port(s) on the front of the Control Board are for a Meat Probe(s). When a meat probe is connected, the temperature is displayed on the LCD Screen. When not in use, disconnect the meat probe from the connection port. Compatible with Pit Boss® branded meat probes only. Additional meat probe(s) sold separately. -
Page 5: Understanding The "P" Setting
UNDERSTANDING THE "P" SETTING When the recessed "P" SET button is pushed, the “P” setting displayed on the LCD AUGER CYCLE (seconds) screen will flash and change to the next value (upward). Once P7 is reached, it will "P" SET restart at P0. -
Page 6: Automatic Start-Up Procedure
AUTOMATIC START-UP PROCEDURE Plug the power cord into a grounded power source. Open the main barrel lid. Check the fire pot to ensure there is no obstruction for proper ignition. Open the hopper lid. Ensure there are no foreign objects in the hopper or auger feed system. -
Page 7: Care And Maintenance
CARE AND MAINTENANCE Any Pit Boss® unit will give you many years of flavorful service with minimum cleaning. An important step is allowing the grill and cooking grids to self-clean by running the grill at a high temperature for 5 to 10 minutes after each use. Follow these cleaning and maintenance tips to service your grill: 1. -
Page 8: Using Wood Pellet Fuel
Grease Bucket / Tray After Each Grill Session Scrub Pad & Soapy Water Auger Feed System When Pellet Bag is Empty Allow Auger to Push Out Sawdust, Leaving Hopper Empty Hopper Electric Components Once A Year Dust Out Interior, Wipe Fan Blades with Soapy Water Air Intake Vent Every 5-6 Grill Sessions Dust, Scrub Pad &... -
Page 9: Troubleshooting
Boss® grill is operating poorly, or on a less frequent basis, the following troubleshooting tips may be helpful. For FAQ, please visit www.pitboss-grills.com . You may also contact your local Pit Boss® authorized dealer or contact Customer Service for assistance. - Page 10 Press the Power Button to turn the unit off, and allow grill to cool. Follow Care and "ErH" Error Code The Unit Has Overheated, Possibly Maintenance instructions. After maintenance, remove pellets, and confirm positioning of Due To Grease Fire Or all component parts.
-
Page 11: Electrical Wire Diagram
ELECTRICAL WIRE DIAGRAM The Digital Control Board system is an intricate and valuable piece of technology. For protection from power surges and electrical shorts, consult the wire diagram below to ensure your power source is sufficient for the operation of the unit. PB –... - Page 12 Diagram # Item # Description PBIOOOXL-W008-ROO Auger box Housing 74250 Auger Box Housing/Barrel Gasket 74076 Auger bushing PBIOOOXL-031-ROO Auger Flighting (shaft) (22.7" long) 70102 Auger motor 74072 Auger motor shaft bolt 74073 Auger motor shaft lock nut PBIOOOSC-W009-ROO Back panel PBIOOOT-A002-ROO Barrel (note: front and back skirt welded to barrel) 30965...
- Page 13 PBIOOOXL-030-ROO Handle - barrel lid - 17.75" Handle - for serving tray – 2 per grill 74224 74222 Handle (side) -trav holder 31495 Hopper access panel 20058 Hopper and feed assembly - with all electrical components 20059 Hopper Box - Shell Only 74091 Hopper cleanout bolt 74093...
