TROUBLESHOOTING PROCEDURES FOR BREEZE I AND BREEZE II
Issue Cause
After installation, 1. The power source is not turned ON.
the unit doesn't
work.
2. The power line and the cable locking connector
is not connecting properly.
3. The switch board and control board wirings are
disconnected.
4. The wires on control board are loose.
5. The switch board or control board is defective.
Light works, 1. The motor is defective, possible seized.
but motor is not
2. The thermally protected system detects if the
turning.
motor is too hot to operate and shuts the motor
down.
3. Damaged capacitor.
4. The motor wire is not connected.
The unit is 1. The motor is not secure in place.
vibrating.
2. Damaged blower wheel.
3. The hood is not secured in place.
The motor is 1. Defective bulb.
working, but the
2. The light bulb is loose.
lights are not.
3. The wires on the control board are loose.
The hood is 1. The hood might be hanging to high from the
not venting out cook top.
properly.
2. The wind from the opened windows or opened
doors in the surrounding area are affecting the
ventilation of the hood.
3. Blockage in the duct opening or duct work.
4. The direction of duct opening is against the wind. 4. Adjust the duct opening direction.
5. Using the wrong size of ducting.
Metal fi lter is
1. Metal fi lter is loose.
Metal fi lter is 1. Metal fi lter is loose.
vibrating.
vibrating.
2. Handle does not freely move
2. Handle does not freely move
What to do
1. Make sure the circuit breaker and the unit's
power is ON.
2. Check the power connection with the unit is
connected properly.
3. Make sure the wirings between the switch
board and control board are connected
properly.
4. Make sure the wires on the control board are
connected properly.
5. Change the switch board or control board.
1. Change the motor.
2. The motor will function properly after the
thermally protected system cool down.
3. Change the capacitor.
4. Make sure the motor wire is plugged into the
molex connector.
1. Tighten the motor in place.
2. Change the blower.
3. Check the installation of the hood.
1. Change the bulb.
2. Tighten the light bulb.
3. Make sure the wires on control board are
connected properly.
1. Adjust the distance between the cook top and
the bottom of the hood within 24" and 32"
range.
2. Close all the windows and doors to eliminate
the outside wind fl ow.
3. Remove all the blocking from the duct work or
duct opening.
5. Change the ducting to correct size.
1. Make sure spring handle still works.
1. Make sure spring on handle still works.
2. Replace metal fi lter
2. Replace metal fi lter
