Fuel Conversion/Gas Connections

LP Vapor Installation (typical)

A
NG BTU = ft
Megajoules = m
A. BTU and Pressure Decal
B. Check Distance with Gas Provider
C. Primary Fuel Pressure Regulator Per LP Provider
D. Manual Shutoff Valve
E. Secondary Fuel Pressure Regulator
F. Flexible Fuel Line
G. Sediment Trap
H. Accessory Valve with Manometer Port
Size fuel tank large enough to provide required BTUs for generator and ALL
I.
connected appliance loads. Be sure to correct for weather evaporation.
22
B
F
G H
3
/h X 2500
3
/h X 93.15
Figure 5-7. LP Vapor Installation (typical)
B
D
E
