Lp Gas (Vapor) Installation (Typical) - Generac Power Systems 10 kW Owner's Manual

Fuel Conversion / Gas Connections

LP Gas (Vapor) Installation (Typical)

3
LPG BTU/h = ft /h X 2500
A Fuel data decal
B Minimum distance from rear obstruction—see
C Manual fuel shutoff valve (pressure port optional)
Must be located no more than 6 ft (1.83 m) away from fuel inlet.
D Pipe fittings (field supplied)
E Flexible fuel line
F Verify minimum distance requirements for regulator vent according to local gas codes. Regu-
lator should be a minimum of 5 ft (1.5 m) from generator. Local codes and regulator manufac-
turer may have further clearance requirements.
G Clamp
H Secondary fuel pressure regulator
J Manual shutoff valve
K Primary fuel pressure regulator
L Fuel tank—sized large enough to provide required MJ/BTU for generator operating at FULL
load and ALL connected appliance loads. Be sure to correct for weather evaporation.
26
A
D
E
G
C
B
Figure 5-7. LP Gas (Vapor) Installation (typical)
L
H
F
Distance Requirements
Installation Guidelines for 60 Hz Air-Cooled Generators
K
J
008966
3
Megajoules/h = m /h X 93.15
