GLASS DOOR REFRIGERATOR
Installation and Operation Manual
Please read this manual completely before attempting to install or operate this equipment!
IMPORTANT SAFETY INSTRUCTIONS
CAUTION!
PLEASE KEEP POWER SWITCH ON
BEFORE OPERATING THE UNIT
ATTENTION!
GARDEZ EN BOUTON ALLUME
AVANT D'OPERER L'UNITE
R5109-162
Advertisement
Table of Contents
Related Manuals for Kool-It KBSR-1G
Summary of Contents for Kool-It KBSR-1G
- Page 1 CAUTION! PLEASE KEEP POWER SWITCH ON BEFORE OPERATING THE UNIT GLASS DOOR REFRIGERATOR ATTENTION! Installation and Operation Manual GARDEZ EN BOUTON ALLUME AVANT D’OPERER L’UNITE Please read this manual completely before attempting to install or operate this equipment! IMPORTANT SAFETY INSTRUCTIONS R5109-162...
-
Page 2: Table Of Contents
7. TROUBLE SHOOTING GUIDE SPECIFICATIONS Glass Door Refrigerators MODEL COMP. H.P REFRIGERANT AMPS WEIGHT 2.0A KBSR-1G R-290 271LBS 5.6A KBSR-2G R-290 370LBS SERIAL NUMBER The serial number is located on the rating label which is on the left interior wall. -
Page 3: Installation
INSTALLATION 1. GOOD AIR CIRCULATION - Be sure to avoid any object which will restrict exhausted air flow. - Be sure that there is ample space so that air can flow through the rear of the unit. - The back of the unit should be located no less than 5 inches from the wall. 2. -
Page 4: Cleaning
CLEANING 1. CLEANING THE INTERIOR AND EXTERIOR - The interior and exterior of the unit can be cleaned using warm water with soap. - Do not use an abrasive cleaner because it will scratch the surface. 2. CLEANING THE CONDENSER FINS - To maintain proper refrigeration performance, the Condenser coil must be free of dust, dirt, and grease. -
Page 5: Basic Operation
Please refer to the ENERGY STAR related information in www.energystar.gov for more details. BASIC OPERATION KBSR-1G, KBSR-2G REFRIGERATOR 1. Plug in and turn on the power switch located on the bottom of the top grill. - Page 6 DISPLAY PANEL DOOR OPENING INSIDE TEMP. TEMP. CONTROL BUTTON 1. UP / DOWN BUTTON (Temperature control button) - By pushing the up/down button, you can set the inside temperature. 2. DOOR OPENING INDICATOR - If door is opened, door opening indicator will be turned on. - If the door is left open for 3 minutes an alarm will sound continuously.
- Page 7 TROUBLE SHOOTING GUIDE SYMPTOMS CAUSES SOLUTIONS Refrigerator/Freezer is The Temp. is set too low (high) Push the button to a warmer to maintain food freshness. (colder) position. freezing (thawing) food. Check the power cord to The unit does not There is a power make sure the unit is plugged connection failure problem.
- Page 8 MEMO 888888888888888...
- Page 9 MEMO...
- Page 10 5659 ROYALMOUNT AVE 12000 BISCAYNE BLVD. STE 108 MONTREAL,QC H4P2P9 MIAMI,FL 33181 786-600-4687 514-737-9701 844-218-8477 888-275-4538...
