  • Page 1 JRVCS105 RV CONTROL AND MONITORING SYSTEM Installation and Operation Manual...

  • Page 2: Table Of Contents

    JRVCS105 TABLE OF CONTENTS   Table of Contents ........................................................... 2   Introduction ............................................................ 4   Thank You! ..........................................................4   Features ..........................................................4   Precautions ..........................................................4   Packing List ................................................... 錯誤! 尚未定義書籤。   Installation ............................................................5   Tools and Supplies ........................................................5  ...
  • Page 3 JRVCS105   Software Update .......................................................... 24   Reset: Floor Plan ......................................................... 26   System Calibration ........................................................27...

  • Page 4: Introduction

    JRVCS105 INTRODUCTION Packing List Thank You! Thank you for choosing iN-Command. We hope you will find the instructions in this owner’s manual clear and easy to follow. If you take a few minutes to look through it, you’ll learn how to use all the features of your new JRVCS105 for maximum enjoyment.

  • Page 5: Tools And Supplies

    JRVCS105 INSTALLATION It’s a good idea to read all of the instructions before beginning the installation. We recommend having your Jensen JRVCS105 installed by a reputable RV dealership Tools and Supplies CUTOUT FOR DISPLAY COMMANDER (DC) You will need these tools and supplies to install your JRVCS105: ...

  • Page 6: Wiring Terminal List

    JRVCS105 WIRING TERMINAL LIST The wiring diagram depicts all the wiring connections required for proper operation of the unit. The TX (transmit) and RX (receive) wires from the BCM to DC are reversed at each device (the BCM transmits and the DC receives, and vice versa). BODY CONTROL MODULE (BCM) CONNECTIONS PIN NO.

  • Page 7: Bcm And Dc Wiring Diagram

    JRVCS105 BCM AND DC WIRING DIAGRAM...

  • Page 8: Setup Menu List

    JRVCS105 SETUP MENU LIST ITEM SELECTION Tanks, light groups, and motor functions can be added or removed. Black Water Tank 2 No, Yes Motor functions may include slides, awnings, jacks, or any motor that may be controlled Gray Water Tank 2 No, Yes with a momentary switch.

  • Page 9: Safety Lockout

    JRVCS105 SAFETY LOCKOUT IN-Command is equipped with a Safety Lockout feature to ensure certain system functions are unavailable during transit. When the Brake or Right Turn Signal on the tow vehicle is activated, IN-Command will lock down all motorized functions. A red button, with Travel Lock in white text, will appear on the DC and mobile devices will display “Travel Lock On”...

  • Page 10: Troubleshooting

    Replace the 1505 relay with one from an unused circuit by gently pulling it off the board, or install an new one. If an issue is unable to be resolved using the above methods, contact ASA Electronics Technical Support at 1-877-845-8750 or email them at info@asaelectronics.com...

  • Page 11: Display Commander Buttons

    JRVCS105 OVERRIDE SWITCH The Body Control Module has an override switch and knob. The knob below the switch corresponds to a motor function made by the Display Commander and Handheld Devices App. The switch and knob actuate all the motor functions on the RV. To use the override switches, locate the switch on the BCM.

  • Page 12: Specifications

    JRVCS105 SPECIFICATIONS FCC Notes Display Commander (DC) Operating Voltage ............12VDC WARNING! Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 13: Passcode Protection

    JRVCS105 PASSCODE PROTECTION     A passcode is required to access the system. On first using the system, you are required to Confirm the new passcode. enter and confirm a new passcode.            ...

  • Page 14: Menu

    JRVCS105 MENU: Long press the intended text, e.g., “Motor 1”. From the Menu screen you can:  Edit IN-Command function text  Reposition functions  Enable/disable functions   See the status of IN-Command  Connect devices with Bluetooth  Change the passcode ...

  • Page 15: Scroll List Editing

    JRVCS105 Scroll List Editing Tanks     Push the “Pages” button twice. Black water tanks, and Gray water tanks can be added to the system.                         Lights Press and hold the “≡”...

  • Page 16: Slides

    JRVCS105 Slides Slides can be added to the system.             Awnings   Awnings can be added to the system.      ...

  • Page 17: Passcode

    JRVCS105 Passcode Push the “Pages” button twice. To change Passcode you will need to enter the current passcode.             Press “ ” to enter passcode setup.  ...

  • Page 18: Set Passcode Timer

    JRVCS105 Set Passcode Timer Press the “Set Timer” button to select the idle time to activate the passcode protection. Confirm new passcode.                                   Clear Passcode Change Passcode Press the “Clear...
  • Page 19 JRVCS105 MOBILE DEVICES: IN-Command is able to pair to Android and iOS devices using the iN-Command App. Visit the Google Play and Apple App stores on your mobile device to download and use the iN-Command App. Seven mobile devices are able to be paired IN-Command at one time, but only 1 iOS and 3 Android devices are able to be actively paired at the same time;...

  • Page 20: Paring A Mobile Device To Dc

    JRVCS105 Pairing a Mobile Device to DC On the DC: 1.1 Push the “Pages” button 2 times. 1.3 Or press “Discover” for the DC to become “visible” to other devices for 300 seconds. Press “Allow”.            ...
  • Page 21 JRVCS105 On the Mobile Device: 2.1 Press “Bluetooth” on the “Setup” page to find the DC 2.2 The Mobile APP will scan for the DC device. 2.3 The DC will be displayed in the Unpaired Devices list device. in the format “JENSENDCXXXXXX”. Press the DC  ...

  • Page 22: Checking Active Bluetooth Session

    JRVCS105 Setting the Floor Plan on the Mobile Device 3.1 On the DC, a request message will appear. Press “Pair” to start the BT pairing and concurrently accept the pairing on the Mobile device. 1.1 After Pairing the mobile Device, go to the settings menu on that device and select “Reset”.
  • Page 23 JRVCS105 CHECKING FOR AN ACTIVE BLUETOOTH SESSION Push the “Pages” button 2 times and select the connections, or “ “, menu. This page shows the current Actively Paired handheld devices.                     To disconnect a handheld device, press “Disconnect”, or simply shut down the device’s app.
  • Page 24 JRVCS105 SOFTWARE UPDATE* Software updates include floorplan redesigns and app version updates. The Settings menu will appear. Press the “Update” button next to the Version, or “Select” next to Floor Plan. Insert USB drive with software update into the USB port located underneath the bottom right corner of the DC.
  • Page 25 JRVCS105 5.2      Ensure the updated program displays correctly   After the update is completed, press the “Home” button, and then return the Settings Page     *If a software update is needed, go to http://www.asaelectronics.com//in-command ** The Engineering Passcode is used by the manufacturer for programming and troubleshooting purposes.
  • Page 26 JRVCS105 Reset: Floor Plan Select one of the two options to restore to a previous state. Current settings will be lost. To reset the floor plan, removing customizations, press the “Pages” button twice. - Floor Plan: restore to previous floor plan setting. - Factory: restore to default setting.
  • Page 27 JRVCS105 SYSTEM CALIBRATION* Push the “Pages” button 2 times and select the Settings Menu. Enter the Engineer   Enter admin passcode to proceed.** Passcode.**               Select the device that needs to be calibrated.  Scroll to the bottom of the page and select “Admin”.  ...
  • Page 28     ** The Administration Passcode is used by the manufacturer for programming and   troubleshooting purposes. Should there be a calibration issue, call ASA Electronics   Technical Support at 1-877-845-8750 or email them at info@asaelectronics.com       ...
  • Page 29 JRVCS105 ASA Electronics Corporation www.asaelectronics.com www.jensenrvdirect.com ©2015 ASA Electronics Corporation...
