ASA Electronics iN-Command NCS40T Installation And Operation Manual

Trailer control and monitoring system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
™
NCS40T
Trailer Control and Monitoring system
Installation and Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iN-Command NCS40T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASA Electronics iN-Command NCS40T

Summary of Contents for ASA Electronics iN-Command NCS40T

  • Page 1 ™ NCS40T Trailer Control and Monitoring system Installation and Operation Manual...
  • Page 3 NCS40T IMPORTANT: READ ALL INSTRUCTIONS AND WARNINGS CAREFULLY BEFORE DOWNLOADING, INSTALLING OR USING THE IN∙COMMAND® CONTROL SYSTEM AND THE RELATED MOBILE APPLICATION WARNING FAILURE TO FOLLOW ALL INSTRUCTIONS AND WARNINGS BEFORE USING THE IN∙COMMAND CONTROL SYSTEMS MOBILE APPLICATION/APP OR IMPROPER USE COULD RESULT IN SERIOUS PERSONAL INJURY, INCLUDING DEATH AND/OR PROPERTY DAMAGE.
  • Page 4 NCS40T WARNING: THE IN∙COMMAND CONTROL SYSTEM AND MOBILE APPLICATION OPERATE THROUGH THE WIRELESS TRANSMISSION OF SIGNALS USING BLUETOOTH LOW ENERGY AND/OR CELLULAR TRANSMISSIONS. IN SOME ENVIRONMENTS, FREQUENCY INTERFERENCE, IMPROPER OPERATION, FAULTY INSTALLATION AND/OR YOUR MOBILE DEVICE AND SETTINGS MAY RESULT IN WEAKER SIGNALS OR INABILITY TO RECEIVE AND/OR TRANSMIT SIGNALS. WARNING: SOMEONE COULD MALICIOUSLY PAIR A MOBILE DEVICE WITH THE IN-COMMAND SYSTEM AND OPERATE THE TRAILER IF IN RANGE OF THE TRAILER.

  • Page 5: Table Of Contents

    NCS40T • Table Of Contents Introduction ................6 Thank You! .................6 Feature Description ............6 Precautions ................6 Packing List ................6 Installation and Mounting instruction ........7 Tools and Supplies .............7 Connecting to the Battery ...........7 Selecting the Mounting Location ........7 Mounting the NCS40T ............7 Mounting the BT Antenna ...........7 Wiring ..................8 Travel Lock out information (Safety) ........9...

  • Page 6: Introduction

    NCS40T • Introduction • Packing List • Thank You! (1) Control System Thank you for choosing iN-Command. We hope you will find the instructions in this owner’s manual clear and easy to follow. If you take a few minutes to look through it, you’ll learn how to use all the features of your new NCS40T for maximum enjoyment.

  • Page 7: Installation And Mounting Instruction

    NCS40T • Installation and Mounting instruction • Mounting the NCS40T It’s a good idea to read all of the instructions before beginning the installation. • Tools and Supplies You will need these tools and supplies to install your NCS40T : •...

  • Page 8: Wiring

    • Wiring #6. TRUCK POWER - (WHITE) #1 .RUNNING LIGHT OUT (BROWN L1) #5 . DC 12V ( YELLOW L2) #4 .HYD UP OUT (GREEN) #2 .RIGHT LIGHT OUT (GREEN L3) #4. EMPTY #3 .SOLDENOID POWER OUT (WHITE ) #3 .EMPTY #2 .TPMS POWER + (RED) #3.

  • Page 9: Travel Lock Out Information (Safety)

    NCS40T • Travel Lock out information (Safety) iN∙Command ® Control Systems use travel-lock-out technology to disable any functions that are deemed unsafe when the vehicle is in motion.

  • Page 10: Mobile Devices

    NCS40T • Mobile Devices iN•Command ASA Electronics, LLC The iN-Command Trailer Control System requires a mobile app to operate the system. Visit the Google Play and Apple App stores on your mobile device to download and use the iN-Command Trailer App.

  • Page 11: Pairing A Mobile Device

    NCS40T • Pairing A Mobile Device Click " Pair " button to enter discovery mode.( Long press " Pair " button for 5-8 seconds to disconnect device.) PAIR BUTTON PAIR [BLUE] POWER [RED] INDICATOR INDICATOR • iOS Pairing Instructions 1. Enable "Bluetooth" in the system settings of the mobile device. 2.
  • Page 12 NCS40T 3. The Control Module will be displayed on the mobile device list 4. The mobile device now shows that the Control Module is connected. in the format NCS40TXXXXX.

  • Page 13: Android Pairing Instructions

    NCS40T • Android Pairing Instructions 3. Press Scan to start scanning for Unpaired devices. 2. Select the "Bluetooth" tab 1. From the App Home Page select Select the device by pressing it. settings.
  • Page 14 NCS40T 4. A Bluetooth pairing request will appear on 6. The mobile device will be displayed in the "Paired devices " list on the mobile the mobile device. App. 5. Press " Pair " on the mobile device.

  • Page 15: Passcode Protection

    NCS40T • Passcode Protection A passcode is required to access the system. The first time the App is opened, the user is required to enter and confirm a new passcode. • App Configuration The iN-Command Trailer App is configurable. The user can select which functions are populated on the home page. Select the Settings icon at the bottom of the home page, then press the Configuration tab.

  • Page 16: Adding Auxiliary Function

    NCS40T • Adding Auxiliary Function The iN-Command Trailer App is configurable. The user can select which functions are populated on the home page. Select the Settings icon at the bottom of the home page, then press the Configuration tab. The default configuration is Battery, Hydraulic and Light Check.

  • Page 17: Adding Tire Pressure Monitoring System (Tpms)

    NCS40T • Adding Tire Pressure Monitoring System (TPMS) If the user has iN-Command TPMS Sensors installed on the trailer, a TPMS icon can be added to the home page to provide a quick link to the iN-Command TPMS App. In the Settings page, select the Apps tab. Once in the App page, there is a selection for tires. There is an info icon that provides a description of the TPMS function and a link to the iN-Command TPMS App on the App store, if the user currently does not have the iN-Command TPMS App installed on their device.

  • Page 18: Low Battery Voltage Alert

    NCS40T • Low Battery Voltage Alert The iN-Command Trailer App is equipped with a Low Voltage Alert. If the battery voltage drops below the setpoint for three minutes, a popup will appear notifying the user that the battery voltage is low. The Low Voltage Alert can be adjusted from 11.8V to 12.4V, or the alert can be turned off.

  • Page 19: Home

    NCS40T • Home Page Operation From the home page, you can check the battery voltage, operate the hydraulic lift, perform a light check on the trailer lights, operate the auxiliary function and check the TPMS sensors. • Battery Check To check the battery level, press the Battery icon on the home page. In the battery page, the voltage will be displayed and there is a bar graph to indicate the state of the battery.

  • Page 20: Hydraulic

    NCS40T • Hydraulic To perform the Hydraulic lift function, press the Hydraulic icon from the home page. The user will be prompeted with two Travel Lock Engaged popups. To proceed, make sure it is safe to proceed, then press Yes on the first popup. The second popup will appear, press Yes again. Once in the Hydraulic page, the Travel Lock counter will start counting down from 60 seconds.

  • Page 21: Light Check

    NCS40T • Light Check To perform the Light Check, press the Light Check icon on the home page. The user will be prompeted with two Travel Lock Engaged popups. To proceed, make sure it is safe to proceed, then press Yes on the first popup. The second popup will appear, press Yes again. Once in the Light Check page, the Travel Lock Counter will start counting down from 120 seconds.

  • Page 22: Auxiliary

    NCS40T • Auxiliary To perform an Auxiliary function, press the Auxiliary icon on the home page. The user will be prompeted with two Travel Lock Engaged popups. To proceed, make sure it is safe to proceed, then press Yes on the first popup. The second popup will appear, press Yes again. Once in the Auxiliary page, the Travel Lock timer will start counting down from 60 seconds.

  • Page 23: Tire Pressure Monitoring System (Tpms)

    NCS40T • Tire Pressure Monitoring System (TPMS) To access the iN-Command TPMS App, press the Tire icon on the home page. The TPMS App will then launch. Please see the iN-Command TPMS manual for operation instructions. To go back to the iN-Command Trailer App, press the iN-Command App icon at the top left corner of the TPMS App.

  • Page 24: Troubleshooting

    • Unplug the Dump/Solenoid Power Output connector and plug in the manual up/down hydraulic pump switch. If still not working, see hydraulic pump manual for troubleshooting. For additional troubleshooting, call ASA Electronics Technical Support at 1-800-688-3135, email info@asaelectronics.com or visit our website in-command.net.

  • Page 25: Specificatons

    NCS40T • Specificatons App Support iOS 10.0 and up, Android 6.0 and up. (1 device at a time) Button Bluetooth pairing button LEDs Power Status (boot status), Pairing Status Operation Voltage 9-18VDC Max Curuent Draw At 12 VDC / 650mA Dimension 228.3(W) x 150.8(H) x 33.0 (D) mm 8.99 (W) x 5.94 (H) x 1.30 (D) inch...

  • Page 26: Fcc Notes

    NCS40T • FCC NOTES IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 28 ©2015 ASA Electronics LLC 600-2100010-001...
