Summary of Contents for Samsung AR HPFS Series

  • Page 1 (Arabic) NIGERIA 0800-726-7864 www.samsung.com/africa_en/support ALGERIA 3004 (Toll Free) www.samsung.com/n_africa/support PAKISTAN 0800-Samsung (72678) www.samsung.com/pk/support TUNISIA 80 1000 12 www.samsung.com/n_africa/support SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/support GHANA 0800-100077 www.samsung.com/africa_en/support BOTSWANA 8007260000 www.samsung.com/support NAMIBIA 08 197 267 864 www.samsung.com/support ZAMBIA 0211  350370 www.samsung.com/support...
  • Page 2 Air conditioner User manual/Installation manual AR✴✴HPFS✴✴, AR✴✴JCFS✴✴, AR✴✴JPFS✴✴, AR✴✴KPFN✴✴, AR✴✴KPFS✴✴, AR✴✴KCFS✴✴, AR✴✴MPFN✴✴ • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this installation manual carefully and retain it for future reference. DB68-06031A-01 DB68-06031A-01_A5.indd 1...
  • Page 3: Table Of Contents

    Contents Safety Information Safety Information At a Glance Indoor Unit Overview Display Remote Control Overview Inserting batteries Remote Control Operation Operation modes • Controlling temperature • Controlling fan speed • Controlling air flow direction Power Smart Features Cooling Operation Cool mode • 2-Step cooling function Dehumidifying Operation Dry mode Heating Operation...
  • Page 4 Indoor Unit Installation Step 2.1 Disassembling the cover panel Step 2.2 Disassembling the installation plate Step 2.3 Connecting the cables (assembly cable) Step 2.4 Optional: Extending the power cable Step 2.5 Installing and connecting the drain hose Step 2.6 Optional: Extending the drain hose Step 2.7 Optional: Changing the direction of the drain hose Step 2.8 Installing and connecting the assembly pipes to the refrigerant pipes (assembly pipe) Step 2.9 Shortening or extending the refrigerant pipes (assembly pipe)
  • Page 5: Safety Information

    Because the following operating instructions cover various models, the characteristics of your air conditioner may differ slightly from those described in this manual. If you have any questions, call your nearest contact centre or find help and information online at www.samsung.com. WARNING Hazards or unsafe practices that may result in severe personal injury or death.
  • Page 6 • If the outdoor unit falls, it may result in injury, death or property damage. This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line. • Failing to do so may result in electric shock, fire, and explosion. •...
  • Page 7 If the appliance generates a strange noise, a burning smell or smoke, cut off the power supply immediately and contact the nearest service centre. • Failing to do so may result in electric shock or fire. In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the power line.
  • Page 8 • Do not use any fuse (such as cooper, steel wire, etc.) other than the standard fuse. • Failing to do so may result in electric shock, fire, problems with the product, or injury. CAUTION Do not place objects or devices under the indoor unit. •...
  • Page 9 FOR CLEANING WARNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner or alcohol to clean the appliance. • This may result in discolouration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, cut off the power supply and wait until the fan stops. •...
  • Page 10: At A Glance

    Indoor Unit Overview The actual product may differ slightly from the image depicted below. 01 Air intake 05 Room temperature sensor 02 Air filter 06 Display 03 Air flow blade (up and down) 07 Power button / Remote control receiver 04 Air flow blade (left and right) Display 01 Operation indicator...
  • Page 11: Remote Control Overview

    Remote Control Overview 01 Set temperature indicator 02 Timer option indicator 03 Operation mode indicator 04 Options indicator 05 Low battery indicator 06 Transmit indicator 07 Fan speed indicator 08 Vertical air swing indicator 09 Settings indicator 10 Power button 11 Temperature button 12 Options button 13 Timer button...
  • Page 12: Remote Control Operation

    Remote Control Operation You can use the air conditioner easily by selecting a mode and then by controlling the temperature, fan speed, and air direction. Operation modes You can change the current mode between Auto, Cool, Dry, Fan, and Heat by pressing the button.
  • Page 13 Controlling fan speed You can select the following fan speeds in each mode: Mode Available fan speeds Auto/Dry (Auto) (Auto), (Low), (Med), (High), Cool/Heat (Turbo) (Low), (Med), (High), (Turbo) Controlling air flow direction Vertical air flow Keep the vertical air flow in a constant direction by stopping the movements of the vertical air flow blade.
  • Page 14: Power Smart Features

    Cooling Operation The smart and powerful cooling functions of the Samsung air conditioner keep an enclosed space cool and comfortable. Cool mode Use the Cool mode to stay cool in hot weather. ► ► Select Cool. NOTE • For comfort, keep the temperature difference between the indoor and outdoor air within 5 °C in the Cool mode.
  • Page 15: Dehumidifying Operation

    Dehumidifying Operation The dehumidifying function of the Samsung air conditioner keeps an enclosed space dry and comfortable. Dry mode Use the Dry mode in rainy or humid weather. ► ► Select Dry. NOTE • The lower the set temperature is, the greater the dehumidifying capacity is.
  • Page 16: Heating Operation

    Heating Operation The heating functions of the Samsung air conditioner keep an enclosed space warm and comfortable. Heat mode Use the Heat mode to stay warm. ► ► Select Heat. NOTE • This mode is supported by heating models only: AR✴✴HP/JP/KP/MP✴✴...
  • Page 17: Quick Smart Features

    Quick Smart Features There is a variety of extra functionality provided by the Samsung air conditioner. Auto mode Use the Auto mode when you want the air conditioner to automatically control the operation. The air conditioner will provide the most comfortable atmosphere that it can.
  • Page 18 Fast function Use the Fast function to quickly cool your room. This function is the most powerful cooling function provided by the air conditioner. You can select this function in the Cool mode. ► ► ► In the Cool mode ►...
  • Page 19 Beep sound function Use the Beep sound function to turn on or off the beep sound that plays when you press a button on the remote control. ► ► ► Select Beep. 18 English DB68-06031A-01_A5.indd 18 4/18/2017 8:59:29 AM...
  • Page 20: Energy-Saving Features

    Energy-Saving Operation The smart energy-saving functions of the Samsung air conditioner reduce electricity consumption. Single user function Use the Single user function to reduce electricity consumption while staying cool. You can select this function in the Cool mode. ► In the Cool mode NOTE •...
  • Page 21 Timed on/Timed off function Use the Timed on/Timed off to turn on or off the air conditioner after the time that you set. ► (Select On or Off among On, Off, and ► (Set the on/off time.) • Press the (Timer) button to change the current function between On, Off, and (good’sleep).
  • Page 22 good’sleep function Use the good'sleep function to get a good sleep at night and to save energy. You can select this function both in the Cool and Heat modes. In the Cool or ► ► (Select among On, Off, and Heat mode ►...
  • Page 23: Cleaning And Maintenance

    Cleaning at a Glance Running Auto clean Cleaning duration (minutes) Auto (Cool), Cool, Dry Auto (Heat), Heat, Fan NOTE • When you set the Auto clean timer, Clean blinks and then disappears on the remote control display. The Timer ( ) indicator also appears on the indoor unit display.
  • Page 24 Cleaning the filter Vacuum cleaner Soft brush 30 minutes Hooks Mild detergent CAUTION • Do not scrub the air filter with a brush or other cleaning utensil. This may damage the filter. • Do not expose the air filter to direct sunlight when drying it. NOTE •...
  • Page 25: Troubleshooting

    Troubleshooting If the air conditioner operates abnormally, refer to the following chart to save time and unnecessary expenses. Problem Solution • Check the power status, then operate the air conditioner again. • Switch on the circuit breaker, plug in the power cord, then operate the air conditioner again.
  • Page 26 Problem Solution • When the Auto, Dry, or Fast mode is running or the good'sleep function I cannot change the fan is running in the Cool mode, the air conditioner controls the fan speed speed. automatically and you cannot change the fan speed. •...
  • Page 27: Installation

    • This manual explains how to install an indoor unit its life cycle, the air conditioner must be disposed with a split system with two SAMSUNG units. The of in authorised centres or returned to the retailer use of other types of units with different control so that it can be disposed of correctly and safely.
  • Page 28 • Our units must be installed in compliance with • If you have any difficulty finding installation the spaces indicated in the installation manual location as prescribed above, contact your to ensure either accessibility from both sides manufacturer for details. or ability to perform routine maintenance and •...
  • Page 29: Preparation

    Preparation Step 1.1 Choosing the installation CAUTION location • Comply with the length and height limits described in the figure above. Overview of installation location requirements Minimum clearances for the outdoor unit Wall 100 mm or more 125 mm 125 mm or more or more Minimum clearance in mm...
  • Page 30 Unpacking the outdoor unit When installing more than 1 outdoor unit (5cases) (Unit: mm) 1. Remove the package. 2. Remove the top cushion. 3. Pull out the unit from the bottom cushion. 1500 3000 3000 Step 1.3 Checking and preparing accessories and tools Accessories Accessories in the indoor unit package...
  • Page 31 Optional accessories Accessories in the outdoor unit package Insulated assembly pipe, Rubber leg (4) Insulated assembly pipe, Ø 9.52 mm (1) Ø 6.35 mm (1) ✴✴09✴✴ NOTE Insulated assembly pipe, Insulated assembly pipe, Ø 12.70 mm (1) Ø 15.88 mm (1) •...
  • Page 32 Step 1.4 Drilling a hole through the wall 2. Drill the hole. Before fixing the installation plate to a wall and then CAUTION fixing the indoor unit to the installation plate, a window • Be sure to drill only one hole. frame, or a gypsum board, you must determine the position of a hole (with 65 mm inner diameter) through •...
  • Page 33 Indoor Unit Installation Please scan this QR code for detail video of indoor unit installation. Step 2.1 Disassembling the cover panel 1. Remove the cap screws, then the screws. Cap screw Screw Step 2.2 Disassembling the installation Phillips screwdriver Flat-head screwdriver plate 2.
  • Page 34 Step 2.3 Connecting the cables (assembly • When performing electrical and earthing works, be sure to comply with the 'technical standards of cable) electrical installations' and the 'wiring regulations' in the local regulations. • Tighten the terminal block screw to 1.2-1.8 N•m (1.2-1.8 kgf•cm).
  • Page 35 Step 2.4 Optional: Extending the power 4. Using a crimping tool, compress the two points and flip it over and compress another two points in the same cable location. • The compression dimension should be 8.0. 1. Prepare the following tools. Tools Spec Shape...
  • Page 36 WARNING CAUTION • In case of extending the • Make sure that the indoor unit is in upright position electric wire, please DO when you pour water to check for leakage. Make sure NOT use a round-shaped that the water does not overflow onto the electrical pressing socket.
  • Page 37 Step 2.7 Optional: Changing the direction of Step 2.8 Installing and connecting the the drain hose assembly pipes to the refrigerant pipes (assembly pipe) Connect indoor and outdoor units with field-supplied Drain pan outlet copper pipes by means of flare connections. Use Rubber cap insulated seamless refrigeration grade pipe only, (Cu DHP type according to ISO1337), degreased and...
  • Page 38 1. Cut out the appropriate knock-out piece (A, B, C) Step 2.9 Shortening or extending the on the rear of the indoor unit unless you connect refrigerant pipes (assembly pipe) the pipe directly from the rear. 2. Smooth the cut edges. 3.
  • Page 39 Step 2.10 Fixing the installation plate CAUTION You can install the indoor unit on a wall, window frame, • If you need a pipe longer than specified in piping or gypsum board. codes and standards, you must add refrigerant to the pipe.
  • Page 40 When fixing the indoor unit on a gypsum board 1. Use stud finder to find out locations of the studs. 2. Fix the plate hanger on two studs. CAUTION • If you fix the indoor unit on a gypsum board, use only specified anchor bolts on reference positions.
  • Page 41 Outdoor Unit Installation Step 3.1 Fixing the outdoor unit in place Optional: Fixing the outdoor unit to a wall with a rack Soft rubber designed to cut off vibration from rack to wall (not supplied with product) Rubber leg (Unit : mm) Model ✴✴12✴C✴✴...
  • Page 42 CAUTION • When installing, make sure there is no leakage. When recovering the refrigerant, ground the compressor first before removing the connection pipe. If the refrigerant pipe is not properly connected and the compressor works with the stop valve open, Control box the pipe inhales the air and it makes the pressure Remove the screw for the...
  • Page 43 3. Open the valve of the low pressure side of manifold gauge anticlockwise. 4. Evacuate the air in the connected pipes using the vacuum pump for about 15 minutes. • Make sure that pressure gauge shows -0.1 MPa (-76 cmHg, 5 torr) after about 10 minutes. This procedure is very important to avoid a gas leak.
  • Page 44 Installation Inspection Test parts for the indoor unit Step 4.1 Performing the gas leak tests 1. Before inspecting the leakage, use a torque wrench to close the cap for the stop valve. (Comply with a tightening torque for each size of the diameter, and tighten the cap firmly to Test parts for the prevent any leakage.)
  • Page 45 When error occurs, take necessary measures by referring to the following table. For more information on necessary measures for errors, refer to the service manual. Error indicator LED Display Error Measures for the installer to take LED 1 LED 2 LED 3 Display Communication...
  • Page 46 Step 4.3 Performing final check and trial 4. Turn off the air conditioner and switch mains supply off. operation 5. Disconnect tubing. After disconnection, protect 1. Check the following: valves and tubing ends from dust. • Strength of the installation site CAUTION •...
