- Page 1 Safety and Reference Please read this manual carefully before operating your set and retain it for future reference. *MFL70346322* www.lg.com Copyright ⓒ 2018 LG Electronics Inc. All Rights Reserved. (1803-REV01)
- Page 2 Warning! Safety Instructions • Ventilation - Install your TV where there is proper ventilation. Do not install in a confined space such as a bookcase. - Do not install the product on a carpet or cushion. - Do not block or cover the product with cloth or other materials CAUTION while unit is plugged in.
- Page 3 • Grounding (Except for devices which are not grounded.) • Batteries - TV with a three-prong grounded AC plug must be connected to - Store the accessories (battery, etc.) in a safe location out of the a three-prong grounded AC outlet. Ensure that you connect the reach of children.
-
Page 4: Separate Purchase
Preparing Separate Purchase • If the TV is turned on for the first time after it was shipped from the Separate purchase items can be changed or modified for quality factory, initialization of the TV may take a few minutes. improvement without any notification. -
Page 5: Lifting And Moving The Tv
Lifting and moving the TV • Avoid touching the screen at all times, as this may result in damage to the screen. • Do not move the TV by holding the cable holders, as the Please note the following advice to prevent the TV from being scratched cable holders may break, and injuries and damage to the or damaged and for safe transportation regardless of its type and size. -
Page 6: Tools You Will Need
Provided item Wall mount Punching Guide Wall • When installing the wall mount, check the positions of the wooden studs using a stud finder. Then, fasten the screws on at least two Wall mounting screw separate studs before proceeding. Wall mounting anchor Ø5 x L65 Stud Wall mounting screw for wood... -
Page 7: How To Attach To Masonry Walls
How to attach to masonry walls • When mounting a TV on the wall, make sure not to install the TV by hanging the power and signal cables Please follow the below direction. on the back of the TV. 1 Use a drill bit Ø 8 mm to drill a hole for the anchor location within a • ... -
Page 8: Using The Kensington Security System
Using the kensington security Other connections system Connect your TV to external devices. For the best picture and audio quality, connect the external device and the TV with the HDMI cable. (Only OLED65W8*) Some separate cable is not provided. The Kensington security system connector is located at the rear of the Companion Box (AV Box). -
Page 9: Using Button
Using Button • If you connect a gaming device to the TV, use the cable supplied with the gaming device. • In PC mode, there may be noise associated with the resolution, You can simply operate the TV functions, using the button. vertical pattern, contrast or brightness. - Page 10 Using Magic Remote * To use the button, press and hold for more than 3 seconds. Control (POWER) Turns the TV on or off. You can turn your set-top box on or off by adding the set- top box to the universal remote control for your TV. (Depending on model) Number buttons Enters numbers.
-
Page 11: Registering Magic Remote Control
Troubleshooting Registering Magic Remote Control How to register the Magic Remote Control Cannot control the TV with the remote control. • Check the remote control sensor on the product and try again. To use the Magic Remote, first pair it with your TV. • ... - Page 12 • A blue light blinks on the front of the Companion Box (AV Box). - The TV may have a problem with the cooling fan or the temperature in the TV may be too high. Contact an authorized service center. •...
-
Page 13: Specifications
Specifications Broadcasting Specifications Digital TV Analogue TV Television system ISDB-T NTSC-M Program coverage VHF, UHF, CATV Maximum number of storable programs ISDB-T & Analogue TV : 3,000 External antenna impedance 75 Ω • The energy information provided with the product is indicated in accordance with the regulations of each country. (Depending on country) - The Energy consumption is measured in accordance with IEC 62087. -
Page 14: Open Source Software Notice Information
Open Source Software Notice Information To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please visit http://opensource. lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. - Page 15 Important Information for Information on Functions Supporting Image Quality in Preventing Image Retention Relation to Temporary Image Retention OLED is a self-emissive technology, which brings many significant benefits to image quality and performance. As with any self-emitting • OLED TV offers a function called Pixel Refresher, which helps to display, it is possible for users of OLED TVs to experience temporary prevent temporary image retention.
- Page 16 Regulatory WARNING! Never place a television set in an unstable location. A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: • Using cabinets or stands recommended by the manufacturer of the television set. •...
- Page 20 Record the model number and serial number of the TV. Refer to the label on the back cover and quote this information to your dealer when requiring any service. MODEL SERIAL NO.
-
Page 21: Network Settings
SMART TV Quick Setup Guide * Image shown may differ from your TV. * Image shown on a PC or mobile phone may vary depending on the OS(Operating System). * App icon positions may vary on the platform, depending on the software version. Network Settings 1 Press the (Home) button on the remote to... -
Page 22: Troubleshooting Network Problems
Troubleshooting Network Problems (Home) button on the remote to 1 Press the Check the AP (Router) or consult your Internet access the Home menu. Point the (Settings) service provider. Wheel (OK) icon and select by pressing the button on the remote. When X appears next to Gateway: Unplug the power cord of the AP (Router) and try to connect after 5 seconds. -
Page 23: Updating The Tv Firmware
SmartShare PC SW Installing & Setting 1 Install the SmartShare PC SW programme on your PC. 2 Go to www.lg.com. Then, select your region. 3 Select SUPPORT. Then, select Drivers & Software, SOFTWARE UPDATE or Software & Firmware. 4 Search for your model. Then, select SmartShare PC SW. 5 You can run the programme when installation is complete. - Page 24 Wi-Fi Direct Setting (Home) → (Settings) → ) (All Settings) → Network → Wi-Fi Direct WI-FI Direct If a local network is not available, you can connect a portable device directly to the Network / Picture REFRESH LIST TV using Wi-Fi Direct. Sound ꔐ...
-
Page 25: External Control Device Setup
OWNER’S MANUAL EXTERNAL CONTROL DEVICE SETUP Please read this manual carefully before operating the set and retain it for future reference. www.lg.com... -
Page 26: Key Codes
KEY CODES KEY CODES • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) CH +, PR + R/C Button List R/C Button CH -, PR - R/C Button Exit R/C Button Volume + R/C Button PIP(AD) R/C Button... - Page 27 EXTERNAL CONTROL DEVICE SETUP EXTERNAL CONTROL DEVICE SETUP • Image shown may differ from your TV. Connect the USB to Serial converter/RS-232C input jack to an external control device (such as a computer or an A/V control system) to control the product’s functions externally. Note: The type of control port on the TV can be different between model series.
- Page 28 EXTERNAL CONTROL DEVICE SETUP (TV) (PC) (TV) (PC) Phone jack Type RS-232C IN • You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and (CONTROL & SERVICE) (PC) (TV) the TV, which is specified in the manual. RS-232C IN (CONTROL &...
-
Page 29: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters • Baud rate : 9600 bps (UART) • Stop bit : 1 bit • Data length : 8 bits • Communication code : ASCII code • Parity : None • Use a crossed (reverse) cable. Command reference list (Depending on model) DATA... -
Page 30: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV. (j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu. Adjustment range in TV is 1 to 99. - Page 31 EXTERNAL CONTROL DEVICE SETUP * Commands may work differently depending on model and signal. 01. Power (Command: k a) Ack [d][ ][Set ID][ ][OK/NG][Data][x] ► To control Power *On or Off of the set. * In case of video mute on only, TV will display On Transmission[k][a][ ][Set ID][ ][Data][Cr] Screen Display(OSD).
- Page 32 EXTERNAL CONTROL DEVICE SETUP 08. Color/Colour (Command: k i) 13. Treble (Command: k r) ► To adjust the screen Color(Colour). ► To adjust treble. You can also adjust colour in the PICTURE menu. You can also adjust in the AUDIO menu. Transmission [k][i][ ][Set ID][ ][Data][Cr] Transmission [k][r][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 64...
- Page 33 EXTERNAL CONTROL DEVICE SETUP 18. Equalizer (Command : j v) * Analog Antenna/Cable ► Adjust EQ of the set. [Data 00][Data 01] Channel Data Transmission [j][v][ ][Set ID][ ][Data][Cr] Data 00 : High byte channel data Data 01 : Low byte channel data - 00 00 ~ 00 C7 (Decimal : 0 ~ 199) Data 02 : Input Source (Analog) - 00 : Antenna TV (ATV)
- Page 34 EXTERNAL CONTROL DEVICE SETUP * Analog Antenna/Cable 2. Tune to the digital antenna (ATSC) channel 30-3. Set ID = All = 00 Data 00 : Physical Channel Number Data 00 = Don’t know Physical = 00 - Antenna (ATV) : 02~45 (Decimal: 2 ~ 69) Data 01 &...
- Page 35 11 11 EXTERNAL CONTROL DEVICE SETUP 2. Tune to the BS (ISDB-BS) channel 30. 24. Input select (Command: x b) Set ID = All = 00 (Main Picture Input) Data 00 = Don’t know Physical = 00 ► To select input source for main picture. Data 01 &...
- Page 36 EXTERNAL CONTROL DEVICE SETUP * [Data 02], [Data 03] functions depend on model 3) When [Data 00] is 06, 07 and signal. 00 : Off 01 : On * If [Data 00] is 00 (3D On), [Data 03] has no meaning.
