Model K 360 M
High Pressure Washer Operator Manual
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . .3
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . .4
GFCI Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Using the Accessories . . . . . . . . . . . . . . . . . . . . . . . . .5
Working with Detergents . . . . . . . . . . . . . . . . . . . . . . .6
Shut Down and Clean-Up . . . . . . . . . . . . . . . . . . . . . .7
Taking a Break . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Winterizing and Long-Term Storage . . . . . . . . . . . . . .7
Cleaning Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-9
Optional Cleaning Accessories . . . . . . . . . . . . . . . . . .9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .10-11
Specifications
Operating pressure
Water volume
Voltage
Amp draw
In USA Call:
1-800-537-4129
or visit our website:
www.karcher-usa.com
1400 PSI
1.6 GPM
120 V
14 AMPS
Part No. 5.959-683.0
Advertisement
Table of Contents
Related Manuals for Kärcher K360 M
Summary of Contents for Kärcher K360 M
-
Page 1: Table Of Contents
Model K 360 M Part No. 5.959-683.0 High Pressure Washer Operator Manual Overview ........1 Precautions . -
Page 2: Overview
Model K 360 M OVERVIEW Item Description 1. Vario spray wand 2. Dirtblaster ® wand 3. Spray wand extension 4. Package of 8 screws (not pictured) 5. Trigger gun 6. Trigger gun safety lock 7. High pressure hose 8. Mobile adapter bracket with wheel (qty. 2) 9. - Page 3 IMPORTANT PRECAUTIONS – Read First! Safety Warnings disconnect the extension cord from the receptacle before disconnecting the When using this product, basic precau- product from the extension cord. If you are tions should always be followed: using an extension cord, it should always •...
-
Page 4: Precautions
IMPORTANT PRECAUTIONS – continued Water Supply (Cold Water Only) • The water supply temperature must not • Water hose must be at least 3/4 inch exceed 104°F/40°C. in diameter. • Never use the pressure washer to draw • Flow rate of water supply must not fall in water contaminated with solvents, below 2.5 GPM (gallons per minute). -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS Step 1 Step 2 Connect the high pressure hose to the Insert the spray wand of your unit’s high pressure outlet. choice into the spray wand extension. Push in and turn clockwise to lock spray wand in place. Step 3 Step 4 Connect garden hose... -
Page 6: Gfci Instructions
GFCI INSTRUCTIONS Note: The actual appearance of the GFCI may be different from this illustration. Step 1 Step 2 Plug the Ground Press “TEST”, then Fault Circuit Interrupter (GFCI) press “RESET” to assure proper into a working outlet. connection to power. USING THE ACCESSORIES Vario spray wand The Vario spray wand allows you to adjust the cleaning pressure. -
Page 7: Working With Detergents
WORKING WITH DETERGENT Karcher Pressure washers operate at two pressures. The high pressure setting is used for cleaning, you cannot apply detergents when working at high pressure. To apply detergents you must be operating at low pressure. For best results see Cleaning Tips on pages 8 &... -
Page 8: Shut Down And Clean-Up
SHUTTING DOWN & CLEAN-UP Step 1 Step 2 Step 3 Step 4 Remove de- tergent suction tube from Turn the switch to Turn off the water Press trigger to container and insert into off position and source. release water 1 gallon of fresh water. unplug cord from pressure. -
Page 9: Cleaning Tips
CLEANING TIPS Cement Patios, Deck Cleaning Brick and Stone (with or without detergent) (with or without detergent) Pre-rinse deck and surrounding area with fresh water. If using Kärcher Deck Wash, Pre-rinse cleaning surface with fresh water. place detergent suction tube directly into If using Kärcher All Purpose Cleaner, place cleaning solution and apply to surface at low detergent suction tube directly into cleaning... -
Page 10: Optional Cleaning Accessories
CLEANING TIPS – continued Barbecue Grills, Outdoor Power Patio & Lawn Furniture Equipment & (with or without detergent) Gardening Tools Pre-rinse furniture and surrounding area with (with or without detergent) fresh water. If using Kärcher All Purpose Cleaner, place detergent suction tube direct- Pre-rinse cleaning surface with fresh water. -
Page 11: Troubleshooting
TROUBLESHOOTING Disconnect the machine from the power source before making any repair. Symptom Cause Solution Motor will not start On/Off switch is in the Turn switch to the “ON” (I) position “OFF” (O) position. Power cord is not plugged in. Plug in power cord. - Page 12 TROUBLESHOOTING – continued Symptom Cause Solution No detergent. Detergent suction tube not Check connection. properly connected to the machine. Detergent is too thick. Dilute detergent, for best results use Kärcher detergent. Filter on detergent suction Run warm water through filter tube is clogged.
