Summary of Contents for ACOPOWER HY-PTP-100W
- Page 1 3M Velco M4*14mm Flat-Heat cross-Screw (For the Installation of Controller) Twin Core Cable In Red and Black 1000mm/2*2.5mm² Twin Core Cable in Red and Black with MC4 Power Your Green Life! 4120 Valley Blvd Walnut, CA 91789, USA www.ACOPower.com +1-626-737 1140...
- Page 2 Open- Short- Type Module Size Max-power Power Power Circuit circuit Current Voltage Voltage Current Module 650*505*30 2*50w 2*50 17.8 2*1.81 22.3 2*3.03 (25.6*19.9*1.2 in) (33.1 lb) Power Your Green Life! 4120 Valley Blvd Walnut, CA 91789, USA www.ACOPower.com +1-626-737 1140...
- Page 3 Tip: The charge controller will not respond unless it is connected to a battery! Always connect the battery first, then load (if applicable). For lights explanation, please check the Specifications section. Power Your Green Life! 4120 Valley Blvd Walnut, CA 91789, USA www.ACOPower.com +1-626-737 1140...
- Page 4 For more information about adapters needed, please contact us. Warning: Make sure the combined current is lower than the rated current of the charge controller which is 10 amps for this model. Power Your Green Life! 4120 Valley Blvd Walnut, CA 91789, USA www.ACOPower.com +1-626-737 1140...
- Page 5 Limited Warranty shall be suspended without liability for the period of delay reasonably attributable to such causes. Register your warranty with ACOPWER, please visit: https://www.acopower.com select “Warranty Registration”. Thank you for your business and support! ACOPOWER Team technical support: support@acopower.com...
