- Page 1 User Manual Solar Panel Kits Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA...
- Page 2 • Batteries generate hydrogen and oxygen during charging, resulting in the evolution of an explosive gas mixture. Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA...
- Page 3 • Check and maintain the battery electrolyte levels at regular intervals as per the battery manufacturer’s recommendations if flooded wet cell lead acid batteries are used. • Check and replace damaged components if necessary. Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA...
-
Page 4: Table Of Contents
Two adjacent panels in parallel (12V systems) 200W ..........13 Three adjacent panels in parallel (12V systems) 300W ..........14 Four panels in parallel (12V systems) 400W ..............15 Five adjacent panels in parallel (12V systems)500W ...........16 Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA... -
Page 5: General Information
General Information A new ACOPOWER Off-Grid Solar Kit will provide you with a clean, silent, and sustainable way of ensuring that batteries are fully charged and capable of providing a continuous supply of electricity. Each kit comes equipped with a high quality solar panel that features highly efficient silicon solar cells. -
Page 6: Z-Bracket Mounting
Z-Bracket Mounting The ACOPOWER Z-Bracket Mount System is designed to support the installation of single panel units, generally in off-grid installations. These units are ideal for installation on RV roofs and noninhabited dwellings such as sheds or garages. It is also suited as attachment to a user made structure such as a wooden frame. - Page 7 Making Brackets to Panel Frame Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA...
-
Page 8: Adjustable Angle Triangle Bracket
30°35°40°45°.This bracket is sold separately, not as a supporting product. Mounting Brackets Assemble left and right triangle supports Extend the triangle bracket and tighten the fixing bolts. Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA... - Page 9 Install solar panel fixing blocks and install photovoltaic panels. Place the photovoltaic panel on the support, and then fasten the pressing block to fix the photovoltaic panel. U-bolt mounting Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA...
-
Page 10: Battery To Charge Controller
MPPT charging controller is completed, and the screen of the MPPT charging controller will display the battery voltage information. Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA... -
Page 11: Extending The Output Wires Of The Solar Panel
The battery must first be wired to the charge controller before the solar panel is connected to the charge controller. Extending the output wires of the solar panel Fig.2. MC4 Adapter Kit Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA... -
Page 12: Solar Panel To Charge Controller
Please refer to Figure 3. This figure shows the extending of the output wires of the ACOPOWER-100W Solar Panel using the adapter kit. The polarity labeled on the panel’s leads should be the only ones to follow. When adapting the leads, mark the positive (+) cable;... - Page 13 The panel MUST be covered with a dark cloth to prevent the solar cells from producing energy; this will prevent and reduce shock hazard, which can be life threatening. Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA...
-
Page 14: Multiple Panels/Strings In Parallel
Sizing the cable incorrectly may result in melting wires and/or fire. Two adjacent panels in parallel (12V systems) 200W Figure 6 Two 100W Panels in parallel Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com Address:4120 Valley Blvd, Walnut CA 91789, USA... -
Page 15: Three Adjacent Panels In Parallel (12V Systems) 300W
(2) pairs of MC4 Y-Branch Connectors. When one or multiple panels are mounted at different locations- that is, separated by a distance, the panels need to be extended with MC4 Extension Cables (sold separately). Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com... -
Page 16: Four Panels In Parallel (12V Systems) 400W
MC4 Branch Connectors. This connection requires three (3) pairs of MC4 Y -Branch Connectors. When one or multiple panels are mounted at different locations- that is, separated by a distance, the panels must be extended with MC4 Extension Cables (sold separately). Email: Sales@ACOPower.com Call: (626) 575-7722 Web:www.acopower.com... -
Page 17: Five Adjacent Panels In Parallel (12V Systems)500W
