SECTION 5
[CONTROL UNIT]
REF
ORDER
NO.
NO.
IC1
1110002750 S.IC
IC2
1110005780 S.IC
IC3
1180000420 S.IC
IC4
1140010230 S.IC
IC5
1130007370 S.IC
Q1
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q2
1590001650 S.TRANSISTOR XP4601 (TX)
Q3
1510000770 S.TRANSISTOR 2SA1586-GR (TE85R)
Q5
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q6
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q7
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q8
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q9
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q10
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q11
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q12
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q13
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q15
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q16
1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
D1
1730002280 S.ZENER
D2
1730002340 S.ZENER
D3
1750000550 S.DIODE
D4
1790001000 S.ZENER
X1
6060000610 S.CERAMIC
R1
7210002920 VARIABLE
R2
7030003440 S.RESISTOR
R3
7210002920 VARIABLE
R4
7030003440 S.RESISTOR
R5
7210002920 VARIABLE
R6
7030003440 S.RESISTOR
R7
7210002920 VARIABLE
R8
7030003440 S.RESISTOR
R9
7030003640 S.RESISTOR
R10
7030003640 S.RESISTOR
R11
7030003640 S.RESISTOR
R12
7030003640 S.RESISTOR
R13
7030003520 S.RESISTOR
R14
7030003640 S.RESISTOR
R15
7030005521 S.RESISTOR
R16
7030005501 S.RESISTOR
R17
7030005691 S.RESISTOR
R18
7030003560 S.RESISTOR
R19
7030000020 S.RESISTOR
R20
7030003520 S.RESISTOR
R21
7030003520 S.RESISTOR
R22
7030003760 S.RESISTOR
R23
7030003560 S.RESISTOR
R24
7030003520 S.RESISTOR
R25
7030003560 S.RESISTOR
R26
7030003520 S.RESISTOR
R27
7030003760 S.RESISTOR
R28
7030003520 S.RESISTOR
R29
7030003560 S.RESISTOR
R30
7030003440 S.RESISTOR
R31
7030003480 S.RESISTOR
R32
7030003600 S.RESISTOR
R35
7030003560 S.RESISTOR
R39
7030003680 S.RESISTOR
R41
7030003800 S.RESISTOR
R42
7030003440 S.RESISTOR
R43
7030003440 S.RESISTOR
R44
7030003440 S.RESISTOR
R45
7030003390 S.RESISTOR
R46
7030003440 S.RESISTOR
R47
7030003440 S.RESISTOR
R48
7030003440 S.RESISTOR
R49
7030003390 S.RESISTOR
R50
7030003440 S.RESISTOR
PARTS LIST
DESCRIPTION
TA75S01F (TE85R)
S-80945CLMC-G7F-T2
TA78L05F (TE12R)
HD6473847RH (FX-2493D)
TA75S558F (TE85L)
MA8091-M (TX)
MA8047-M (TX)
1SS355 TE-17
MA8062-L (TX)
EFOS4914E3
EVU-F2AF20B55 (560K)
ERJ3GEYJ 102 V (1 kΩ)
EVU-F2AF20B55 (560K)
ERJ3GEYJ 102 V (1 kΩ)
EVU-F2AF20B55 (560K)
ERJ3GEYJ 102 V (1 kΩ)
EVU-F2AF20B55 (560K)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERA3YKD 334V (330 kΩ)
ERA3YKD 124V (120 kΩ)
ERA3YED 123V
ERJ3GEYJ 103 V (10 kΩ)
MCR10EZHJ 1 Ω (010)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 102 V (1 kΩ)
[CONTROL UNIT]
REF
ORDER
NO.
NO.
R51
7030003440 S.RESISTOR
R52
7030003440 S.RESISTOR
R53
7030003390 S.RESISTOR
R54
7030003440 S.RESISTOR
R55
7030003440 S.RESISTOR
R56
7030003440 S.RESISTOR
R57
7030003390 S.RESISTOR
R58
7030003680 S.RESISTOR
R59
7030003680 S.RESISTOR
R60
7030003680 S.RESISTOR
R61
7030003580 S.RESISTOR
R62
7030003440 S.RESISTOR
R63
7030003520 S.RESISTOR
R64
7030003520 S.RESISTOR
R65
7030003390 S.RESISTOR
R66
7030003390 S.RESISTOR
R67
7030003380 S.RESISTOR
R71
7030003440 S.RESISTOR
R72
7030003560 S.RESISTOR
R73
7030003560 S.RESISTOR
R74
7030003560 S.RESISTOR
R75
7030003560 S.RESISTOR
R76
7030003620 S.RESISTOR
R77
7030003660 S.RESISTOR
R78
7030003520 S.RESISTOR
R79
7030003520 S.RESISTOR
R80
7030003530 S.RESISTOR
R81
7030003600 S.RESISTOR
R82
7030003600 S.RESISTOR
R83
7030003580 S.RESISTOR
R85
7030003760 S.RESISTOR
R88
7030003500 S.RESISTOR
C1
4030006880 S.CERAMIC
C2
4030006880 S.CERAMIC
C3
4030006880 S.CERAMIC
C4
4030006880 S.CERAMIC
C5
4030007130 S.CERAMIC
C6
4030007090 S.CERAMIC
C7
4030007130 S.CERAMIC
C8
4030007130 S.CERAMIC
C10
4030007130 S.CERAMIC
C12
4030011600 S.CERAMIC
C13
4030006860 S.CERAMIC
C14
4030006860 S.CERAMIC
C15
4030006860 S.CERAMIC
C16
4030006860 S.CERAMIC
C18
4030006860 S.CERAMIC
C19
4030006860 S.CERAMIC
C20
4510004640 S.ELECTROLYTIC ECEV1CA470SP
C22
4030006860 S.CERAMIC
C23
4030012600 S.CERAMIC
C24
4510004630 S.ELECTROLYTIC ECEV1CA100SR
C25
4030006860 S.CERAMIC
C26
4030006900 S.CERAMIC
C27
4030006860 S.CERAMIC
C28
4510004630 S.ELECTROLYTIC ECEV1CA100SR
C29
4030006860 S.CERAMIC
C30
4030007090 S.CERAMIC
C31
4030007090 S.CERAMIC
C32
4030006860 S.CERAMIC
C33
4030006860 S.CERAMIC
C34
4030006900 S.CERAMIC
C35
4030011600 S.CERAMIC
C36
4030011600 S.CERAMIC
C37
4030011600 S.CERAMIC
C39
4030011600 S.CERAMIC
C40
4030011600 S.CERAMIC
C41
4030011600 S.CERAMIC
C42
4030006860 S.CERAMIC
C43
4030006860 S.CERAMIC
C44
4030006860 S.CERAMIC
C45
4030006860 S.CERAMIC
C46
4030008910 S.CERAMIC
C47
4030008910 S.CERAMIC
5 - 1
DESCRIPTION
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 562 V (5.6 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 101J-T
C1608 CH 1H 470J-T
C1608 CH 1H 101J-T
C1608 CH 1H 101J-T
C1608 CH 1H 101J-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C2012 JB 1A 105M-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 393K-T
C1608 JB 1H 393K-T
S.=Surface mount
