PV225S-480-P
Operation and Maintenance Manual
PV225S 225 kW
Grid-Tied
Photovoltaic
Inverter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PV225S-480-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Xantrex PV225S-480-P

Summary of Contents for Xantrex PV225S-480-P

  • Page 1 PV225S-480-P Operation and Maintenance Manual PV225S 225 kW Grid-Tied Photovoltaic Inverter...
  • Page 3 PV225S 225 kW Grid-Tied Photovoltaic Inverter Operation and Maintenance Manual...
  • Page 4 About Xantrex Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with products from 50 watt mobile units to one MW utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and backup power applications in both grid-connected and stand-alone systems. Xantrex products include inverters, battery chargers, programmable power supplies, and variable speed drives that convert, supply, control, clean, and distribute electrical power.

  • Page 5: About This Manual

    About This Manual Purpose The purpose of this Operation and Maintenance Manual is to provide explanations and procedures for operating, maintaining, and troubleshooting the PV225S 225 kW Grid-Tied Photovoltaic Inverter. Installation instructions are available in the PV225S 225 kW Grid-tied Photovoltaic Inverter Planning and Installation Manual.

  • Page 6: Conventions Used

    Important: serious as a caution or warning. This Manual contains information for the PV225S-480-P 225 kW Grid-Tied Photovoltaic Inverter. Throughout the manual it will be referred to as the PV225S, unless otherwise noted. These notes describe things which are important for you to know, but not as...
  • Page 7 FPGA IEEE IGBT kcmil POTS UFCU Related Information You can find more information about Xantrex Technology Inc. as well as its products and services at www.xantrex.com. 152607 Converter Control Unit 2 Cubic Feet per Minute Clockwise Digital Signal Processor Field Programmable Gate Array...

  • Page 9: Important Safety Instructions

    Important Safety Instructions SAVE THESE INSTRUCTIONS - DO NOT DISCARD This manual contains important safety instructions for the PV225S that must be followed during installation and maintenance procedures. WARNING: Shock Hazard Read and keep this Operation and Maintenance Manual for future reference. Before installing the PV225S, read all instructions, cautionary markings, and all other appropriate sections of this manual.

  • Page 10: General Safety Precautions

    Safety General Safety Precautions 1. When installing the PV225S use only components recommended or sold by Xantrex. Doing otherwise may result in a risk of fire, electric shock, injury to persons, and will void the warranty. 2. Do not attempt to operate the PV225S if it has been dropped, or received more than cosmetic damage during transport or shipping.
  • Page 11 terminal or compression lug. The terminals can accommodate up to two conductors per phase. See the PV225S 225 kW Grid-tied Photovoltaic Inverter Planning and Installation Manual for the location of these terminals. 5. The AC power conductor wiring interfacing with the AC terminals in the Main Inverter Enclosure are located at TB5, TB6, and TB7.
  • Page 12 Safety Operational Safety Procedures Never work alone when servicing this equipment. A team of two is required until the equipment is properly de-energized, locked-out and tagged, and verified de- energized with a meter. Thoroughly inspect the equipment prior to energizing. Verify that no tools or equipment have inadvertently been left behind.

  • Page 13: Interconnection Standards Compliance

    De-Energize/Isolation Procedure The following procedure should be followed to de-energize the PV225S for maintenance. WARNING The terminals of the DC input may be energized if the PV arrays are energized. In addition, allow 5 minutes for all capacitors within the main enclosure to discharge after disconnecting the PV225S from AC and DC sources.

  • Page 15: Table Of Contents

    Contents Important Safety Instructions 1 Introduction Operation Features- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–2 Fixed Unity Power Factor Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–2 Peak Power Tracking - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–3 Dynamic DC Minimum Operating Voltage - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–4...
  • Page 16 Contents 2 Operation Description of System Operation- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2 Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2 Faults - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2 Operating States - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–4...
  • Page 17 3 Commissioning Commissioning Procedure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2 Starting the Commissioning Test File - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2 Serial Number - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3 Verify AC Voltage - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3...
  • Page 18 Contents A Specifications System Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–2 Environmental Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–2 Electrical Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–3 Over Voltage, Under Voltage and Frequency Ranges - - - - - - - - - - - - - - - - - - - - - - - - - - - A–3...
  • Page 19 Figures Figure 1-1 Maximum Peak Power Tracking - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–4 Figure 1-2 PV225S Major Components - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–6 Figure 1-3...
  • Page 20 Figures Figure 2-24 Connection Configuration Screen - General - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–35 Figure 2-25 Connection Configuration Screen - Telephone Fault Configuration - - - - - - - - - - - - - -2–36 Figure 2-26 Connection Configuration Screen - General - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–36 Figure 2-27 GUI Interface Screen if Connected Directly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2–37 Figure 4-1...
  • Page 21 Tables Table 2-1 Scrolling through the Read Menu Parameters - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–9 Table 2-2 Read Menu Descriptions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–11 Table 2-3 Data Logging Menu- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–14...

  • Page 23: Introduction

    Introduction Chapter 1, “Introduction” contains information about the features and functions of the PV225S 225 kW Grid-Tied Photovoltaic Inverter.

  • Page 24: Operation Features

    Introduction Operation Features The PV225S 225 kW Grid-Tied Photovoltaic Inverter is a UL 1741 listed, utility interactive, three-phase power conversion system for grid-connected photovoltaic arrays with a power rating of 225 kW. Designed to be easy to install and operate, the PV225S automates start-up, shutdown, and fault detection scenarios.

  • Page 25: Peak Power Tracking

    Peak Power Tracking An advanced, field-proven, Maximum Peak Power Tracker (MPPT) algorithm integrated within the PV225S control software ensures the optimum power throughput for harvesting energy from the photovoltaic array. The peak power voltage point of a PV array can vary, primarily depending upon solar irradiance and surface temperature of the PV panels.

  • Page 26: Dynamic Dc Minimum Operating Voltage

    Introduction Optimization of the PV225S MPPT will result in an increase in energy production. The user is encouraged to study the PV array’s I-V curves and to adjust the MPPT user settable parameters accordingly. Figure 1-1 Maximum Peak Power Tracking Dynamic DC Minimum Operating Voltage The PV225S employs a unique approach to the minimum DC input voltage for operation.

  • Page 27: Safety Features

    Safety Features Anti-Island Protection A condition referred to as "Islanding" occurs when a distributed generation source (such as the PV225S Grid-tied Photovoltaic Inverter) continues to energize a portion of the utility grid after the utility experiences an interruption in service. This type of condition may compromise personnel safety, restoration of service, and equipment reliability.

  • Page 28: Physical Characteristics

    Introduction Physical Characteristics The PV225S comes in two modules comprised of six enclosures to house the electronics described above. The first module includes the Main Inverter Enclosure, Inductor Enclosure, DC Interface Enclosure, and Communications Enclosure. The second module includes the Transformer Enclosure and AC Interface Enclosure.

  • Page 29: Main Inverter Enclosure

    Main Inverter Enclosure The PV225S Main Inverter Enclosure is NEMA-3R rated and contains the power distribution panel, the converter control unit (CCU2), and the power electronics matrices. Also found within the Main Inverter Enclosure are some of the system protection devices (such as the sense and control power fuses). Power Distribution Panel This panel contains many of the Electromechanical, protective, and control power components necessary to support the operation of the PV225S.

  • Page 30: Dc Interface Enclosure

    Introduction DC Interface Enclosure The DC Interface Enclosure is NEMA-3R rated. The DC interface serves as the connection interface between the PV array and the PV225S. This enclosure is where the DC Disconnect Switch and DC contactor reside. CAUTION: Equipment Damage The fuses within the PV225S are intended for protecting the PV225S control circuitry only.

  • Page 31: Communications Enclosure

    AC Interface Enclosure Figure 1-4 AC Interface Enclosure and Transformer Enclosure Communications Enclosure The Communications Enclosure is NEMA-4 rated. It contains the hardware to enable a personal computer to connect to the unit, either directly or remotely. Hardware could include a POTS Connect Kit, a Wireless Connect Kit, or an Ethernet LAN kit, or a Direct Connect Kit.

  • Page 32: Operator Interface Controls

    Introduction Operator Interface Controls Operator interface controls are located on the front door of the main inverter enclosure. These controls include an O keypad called the Universal Frontpanel Control Unit (UFCU). Additionally there is an AC and DC Disconnect on the AC Interface Enclosure and the DC Interface Enclosure Doors.

  • Page 33: On/Off Switch

    WARNING: Shock Hazard Disengaging the main enclosure door interlock switch does NOT remove all hazardous voltages from inside the inverter. Before attempting to service the PV225S, follow the de-energize Lockout and Tag procedure on page 5–3. On/Off Switch The PV225S incorporates a maintained position O the front door of the main enclosure.

  • Page 34: Ac And Dc Disconnect Switches

    Introduction AC and DC Disconnect Switches Both AC and DC interface enclosures are equipped with lockout hasps for personnel safety. The enclosure doors should not be opened while the PV225S is operating. The switch handles and shafts provide a door interlock for both the AC and DC interface enclosures.

  • Page 35: System Status And Fault Reporting

    System Status and Fault Reporting Basic system status and all fault conditions rising from within the PV225S are reported to the UFCU. The unit stores the time and details of all faults in non-volatile memory. The 4-line LCD will display a hexadecimal value and a brief text description of the fault.

  • Page 36: Communication Methods

    Introduction Communication Methods The PV225S communicates system status information to the user using the following methods. • The Front Panel Control Unit (UFCU) Display • PC Connection (Direct or Remote) - Xantrex Solar Graphic User Interface (GUI) Software required. Communication with a PC requires the selection of one of the following options.

  • Page 37: Pc Connection Methods

    PC Connection Methods Personal computers can be used to access the system status and programming features of the PV225S. A computer can be connected either directly or remotely. 1. Remote Connect - uses one of the three kits below. • •...

  • Page 38: Pots Access

    Introduction POTS Access Figure 1-11 illustrates the PV225S connected remotely to a personal computer. Figure 1-11 POTS Access Wireless Access Figure 1-12 illustrates the PV225S connected remotely to a personal computer using a wireless network. Figure 1-12 Wireless Access 1–16 152607...

  • Page 39: Ethernet Lan Access

    Ethernet LAN Access The PV225S can be remotely accessed through a local area network. Figure 1-13 LAN Access Direct Access Figure 1-14 illustrates the PV225S connected directly to a personal computer. Figure 1-14 Direct Access 152607 Communication Methods 1–17...

  • Page 40: Gui Software Features

    Introduction GUI Software Features Read-only Menu The GUI software provides access to the following “Read-only Menu” information. See Table 2-2, “Read Menu Descriptions” on page 2–11 for a specific list of available parameters. • Operational Values • Internal Metrics Write-Menu The GUI software provides control of the following system parameters.

  • Page 41: Operation

    Operation Chapter 2, “Operation” contains information on the basic operation of the PV225S 225 kW Grid-Tied Photovoltaic Inverter.

  • Page 42: Description Of System Operation

    Operation Description of System Operation Overview The PV225S is a fully automated grid-interactive photovoltaic inverter. System startup, system shutdown, PV power tracking, and fault detection scenarios are all governed and monitored by the CCU2 controller within the PV225S. Manual interaction or control of the inverter is necessary only in the event of a system fault.

  • Page 43: Figure 2-1 Operating States Flow Chart

    POWER UP INITIALIZING PV contactor opened. Inverter matrix off. Grid contactor open. Green LED on. Red off. DISABLE System State: Key Disable PV contactor open. Inverter State: Standby Inverter matrix off. PV State: Sleep Grid contactor open. Enable Key SLEEP System State: Shutdown for at least 10 Inverter State: Standby...

  • Page 44: Operating States

    Operation Operating States A state machine implemented within the CCU2 control software governs the operation of the PV225S with clearly defined transitions between its operating states. There are five steady-state operating states and numerous intermediate transition states. • Power Tracking •...

  • Page 45: Shutdown

    Shutdown The line interface controller is idle. The CCU2 monitors the status of the PV array and utility grid, waiting in standby until the PV array is available to produce power to the grid. Fault The PV225S has encountered a fault condition. When this happens, regardless of the PV225S state of operation, the PV225S will stop processing all power and execute an orderly system shutdown.

  • Page 46: Operator Interface

    Operation Operator Interface The purpose of the operator interface is to provide a means of communicating critical operational information to and from the unit. This communication occurs between the operator and the UFCU Keypad and LCD display or between the operator and a personal computer running the Xantrex Solar GUI software.

  • Page 47: Lcd Display - Initialization Screen

    Third Line - PV Status (ID 13) • Fourth Line - Goal State (ID 2) 152607 Operator Interface Front Panel Initialization - Screen 2 Model: PV225S XANTREX TECHNOLOGY www.xantrex.com (800) 670-0707 Standard Display System: PWR Tracking Inv: Online Pv: Online Goal : PWR Tracking 2–7...

  • Page 48: Menu Structure

    Operation Menu Structure The operator interface consists of three levels: • The R can be viewed any time the PV225S has control power. • The W configurable parameters. The W only be changed by trained service technicians. In particular are parameters relating to utility protection setpoints.

  • Page 49: Read Menu

    Menu The R • Current Operating State or Goal State • Fault Code (if applicable) • Inverter State • Line Voltage and Current • Inverter Matrix Temperature • Inverter Power • PV State • PV Voltage and Current • PV Power •...
  • Page 50 Operation Standard Display System: PWR Tracking Inv: Online Pv: Online Goal : PWR Tracking System: PWR Tracking Inv: Online Pv: Online Feb-14-2005 10:01:55 System: PWR Tracking Inv: Online Hit ENTER or "." "-" Value by ID# Figure 2-5 Scrolling through the R 2–10 From the Standard Display: 1.

  • Page 51: Table 2-2 Read Menu Descriptions

    Table 2-2 R Menu Descriptions Operational Parameter Current Operating State Displays as: System: * where * can be any one of the states listed in the description for this parameter. System Goal State Displays as: Goal: * where * can be any one of the states listed in the description for this parameter.
  • Page 52 Operation Table 2-2 R Menu Descriptions Operational Parameter Phase C current Displays as: INV C amps: xxx Inverter Real Power Displays as: INV KW: Inverter Matrix Temperature Displays as: INV Temp: PV State Displays as: PV: * where * can be any one of the states listed in the description for this parameter.

  • Page 53: Figure 2-6 Read-By-Id Feature

    -by-ID The Read-by-ID feature supports the ability of the user to view any Read or Write parameter available within the menu structure. It also provides a means to view data logging and accumulated values information. See Table 2-2 for a list of the Read Menu parameters.

  • Page 54: Table 2-3 Data Logging Menu

    Operation Table 2-3 provides a list of the Data Logging Menu parameters. Table 2-3 Data Logging Menu 304 through 390 Table 2-4 provides a list of the Accumulated Values Menu parameters. Table 2-4 Accumulated Values Menu 610-619 626-629 2–14 Usage Data Log Daily Rate in Minutes ID# of 1st parameter to be logged ID# of 2nd parameter to be logged...

  • Page 55: Write Menu

    Table 2-4 Accumulated Values Menu 635-639 Menu RITE Important: the factory to the limits mandated by UL 1741. Any changes to these setpoints should be agreed upon by the local utility and the equipment owner. The W • Ground Current Max •...

  • Page 56: Table 2-5 Write Menu Parameters

    Operation Changing and Displaying W Follow the procedure below to change W To change W 1. From the standard display or anywhere in the R the W password. 2. Enter the password <5><9><4> and press the <E a) If the wrong password is entered, the display will again prompt the user b) If a mistake is made while keying in the password, the /\ or \/ keys may be 3.
  • Page 57 Table 2-5 Write Menu Parameters Parameter Description Minimum Grid This parameter sets the trigger Voltage point value for “AC voltage low” (0012) fault. If the grid voltage is Displays as: below this parameter’s value, the fault is triggered. The lower limit Min AC Volts%: of this parameter is restricted by UL requirements.
  • Page 58 Operation Table 2-5 Write Menu Parameters Parameter Description Time Delay for PV Time delay to transition from PV Wake up wake up state to PV On-line state. Once the inverter is in PV Wake Displays as: Up mode, it waits for the amount of time determine by this PV T Start: parameter before transitioning into...
  • Page 59 Table 2-5 Write Menu Parameters Parameter Description Enable Peak Power This parameter switches on and Tracker off the Power Tracker function. When the Power Tracker is on, the Displays as: inverter will regulate the bus voltage to optimize output power. PPT Enable: When the Power Tracker is off, the inverter will regulate the bus...

  • Page 60: Commanding Goal State Changes

    Operation Commanding Goal State Changes To change the Goal State: 1. From the standard display press the <M a password. The LCD will change the third line of the display to “ Hit ENTER 2. Enter the password <5><9><4> and press the <E The LCD will change the third line of the display to “...

  • Page 61: Setting The Date And Time

    Setting the Date and Time Follow the procedure below to change the date and time. To change the Date and Time: 1. From the standard display, press the <M for the password. The LCD will change the third and fourth lines of the LCD display as follows: “...

  • Page 62: Manual State Transitions

    Operation Manual State Transitions State conditions can also be transitioned manually. Refer to “Commanding Goal State Changes” on page 2–20 for instructions on commanding PV225S goal states for manual transitions. Shutdown → Matrix Test → Shutdown 1. Turn the O 2.

  • Page 63: Auto-Restart Feature

    Any State → Fault If the PV225S encounters a fault, regardless of operating state, it will transition to the Fault state. The PV225S will remain in this state until the fault condition has been remedied and cleared. The Fault Code number will appear on the first line of the LCD.

  • Page 64: Energize Procedure (Startup)

    Operation Energize Procedure (Startup) To start up the PV225S: 1. Remove any lockout devices from the Utility connection circuit breaker and PV disconnect switch. 2. Close the Utility connection circuit breaker. 3. Close the AC Disconnect Switch. 4. Close DC Disconnect Switch. 5.

  • Page 65: Computer Communications With The Pv225S

    Computer Communications with the PV225S The PV225S provides multiple options for communicating system status or data logging through a personal computer using the Xantrex Solar Graphic User Interface (GUI) software. The Xantrex Solar Graphic User Interface (GUI) software is a Windows™-based program that: •...

  • Page 66: Installing The Graphic User Interface (Gui) Software

    Operation Installing the Graphic User Interface (GUI) Software The following section outlines the minimum system requirements for using the GUI software and instructions for installing, configuring, and using the software. Close all programs running on the computer before proceeding with the installation.

  • Page 67: Starting Setup From A Command Prompt

    Starting Setup From a Command Prompt To start the program from a command prompt: 1. Insert the XANTREX SOLAR INVERTER GUI – INSTALLATION CD into your CDROM drive. 2. Click on START and select “RUN”. 3. Enter the drive letter assigned to your CDROM and the name of the installation program as shown in Figure 2-10.

  • Page 68: Model Specific Software Installation

    Operation Model Specific Software Installation Once the Setup program has been started, installation of the GUI software can continue. To continue with the GUI software installation: 1. After the GUI Setup Splash Screen appears (Figure 2-11), click on the button NSTALL (Figure 2-12).

  • Page 69: Figure 2-13 Gui Setup Start Window

    2. Click O Figure 2-13 GUI Setup Start Window If the directory provided in this window is acceptable for the installation, proceed to Step 4. If not, click on the C provide a new name for the desired destination directory. 3.

  • Page 70: Figure 2-15 Gui Setup Progress Indicator Window

    Operation 4. Click C The following setup progress indication window will appear. Figure 2-15 GUI Setup Progress Indicator Window 5. When completed, you will see this: Figure 2-16 GUI Setup Start Window 6. Click OK. The GUI is now installed on the computer. 2–30 ONTINUE to confirm the program group to be used.

  • Page 71: Running The Gui

    Running the GUI To run the GUI software program, log onto the computer and click the following menu items in the order shown below. 1. Window’s S ROGRAMS 2. P ANTREX 3. X ANTREX 4. X Remote/LAN Connection If no inverter is connected to the COM1 serial port of the computer, the following screen will appear: Figure 2-17 GUI Interface Screen if Connected Remotely 152607...

  • Page 72: Direct Connection

    Operation Direct Connection If the serial communication port of the inverter is connected to the COM1 serial port of the computer, the following screen will appear. Figure 2-18 GUI Interface Screen if Connected Directly 2–32 152607...

  • Page 73: Gui Configuration - Adding Inverters

    GUI Configuration - Adding Inverters Once the GUI has started, you will need to configure each Inverter icon to reflect the appropriate operational parameters for each inverter that is connected to the system. The software automatically defaults to one inverter. To program that inverter accordingly, follow the directions provided below.

  • Page 74: Figure 2-21 Operational Configuration Screen - Limits

    Operation 5. Fill out the Operational Configurations Information in the form shown in Figure 2-21 through Figure 2-23. This section has four sub-menu pages to cover the following parameters. a) Fill out Operational Limits Information requested. b) Click on the PV Sub-menu to continue. Form Tab Fill out all the required information on this...

  • Page 75: Figure 2-23 Operational Configuration Screen - Power Tracker

    e) Fill out the Power Tracking Information requested. f) Click on the Connections Form Tab to continue. Form Tab Fill out all the required information on this form. Figure 2-23 Operational Configuration Screen - Power Tracker 6. Fill out the Connection - General Information in the form in Figure 2-24. 7.

  • Page 76: Figure 2-25 Connection Configuration Screen - Telephone Fault Configuration

    Operation 8. Fill out the Connection - Telephone Fault Configuration Information in the form shown in Figure 2-25. 9. Click on the Telephone Configuration sub-menu to continue. Form Tab Fill out all the required information on this form. Figure 2-25 Connection Configuration Screen - Telephone Fault Configuration 10.

  • Page 77: Gui Help

    GUI Help The GUI software program has a built-in help program. Once the program is started, click on the H The Help interface is divided into the following sections. • Getting Started - IMPORTANT: Read this first • Setup - Tutorial for setting up the GUI and configuring an inverter •...
  • Page 78 2–38...
  • Page 79 Computer Communications with the PV225S 152607 2–39...
  • Page 80 Operation 2–40 152607...

  • Page 81: Commissioning

    Commissioning Chapter 3, “Commissioning” contains information on safely commissioning the PV225S 225 kW Grid-Tied Photovoltaic Inverter.

  • Page 82: Commissioning Procedure

    Commissioning Commissioning Procedure This section provides the procedure necessary to safely and correctly commission a PV225S inverter. Important: procedure. Summary To commission the PV225S: 1. Ensure the Verification Tests have been completed and have passed successfully. See the PV225S 225 kW Grid-tied Photovoltaic Inverter Planning and Installation Manual, Section 4.

  • Page 83: Serial Number

    Serial Number 1. Enter the information required by GUI in the white text boxes on the form that appears next. The converter serial number is located on a label placed on the lower-left front of the Main Inverter Enclosure door. 2.

  • Page 84: Inspect Inductor Enclosure

    Commissioning 6. Once you finish verifying PV DC voltages, go back to the GUI Commissioning Procedure and click on the check box to indicate that the task is complete. Go to the next step by clicking on the "N Inspect Inductor Enclosure 1.

  • Page 85: Establish Communications With The Gui

    7. Once you finish checking the Front Panel Display, go back to the GUI Commissioning procedure and click on the check box to indicate the task is complete. Go to the next step by clicking on the "N Establish Communications with the GUI 1.

  • Page 86: Confirm Dc Operational Parameters

    Commissioning Confirm DC Operational Parameters 1. Verify the Inverters PV Settings. 2. Make any necessary changes. 3. Record these values. 4. Once you finish these tasks, go back to the GUI Commissioning Procedure and click on the check box to indicate the task is complete. Go to the next step by clicking on the "N Confirm Power Tracker Configuration Operational Parameters 1.

  • Page 87: Operate Inverter

    Operate Inverter 1. Make sure all doors are closed and locked. 2. Using the Front Panel or the GUI, set the I PPT Max percent to 25%. 3. Place the O PV Start voltage threshold, followed by a 5-minute delay period, the PV contactor (K2) will close, followed by the Main AC contactor (K1).
  • Page 88 3–8...

  • Page 89: Troubleshooting

    Troubleshooting Chapter 4, “Troubleshooting” contains information and procedures for troubleshooting the PV225S 225 kW Grid-Tied Photovoltaic Inverter. It provides descriptions of common situations and errors that may occur and provides possible solutions for resolving fault conditions. It also provides instructions for clearing faults manually, if required.

  • Page 90: Faults And Fault Codes

    Troubleshooting Faults and Fault Codes Fault states are automatic from any state of operation. In the event of a fault condition, the PV225S will immediately stop processing power and execute an immediate orderly shutdown, open both the main AC and DC contactors, and remain in a faulted state until the fault is remedied and cleared (manually or automatically).

  • Page 91: Clearing Faults Manually

    Clearing Faults Manually Faults associated with a grid disturbance clear automatically. These faults include: • 0010 (AC Frequency Low), • 0011 (AC Frequency High), • 0012 AC Voltage Low), and • 0013 (AC Voltage High) only. Once the AC voltage and frequency return to within the acceptable range, the PV225S will clear the fault and automatically restart after a 5-minute delay.

  • Page 92: Fault Code Descriptions

    Troubleshooting Fault Code Descriptions Table 4-1 provides a complete description of all the fault conditions that may occur on the PV225S. Table 4-1 Fault Codes Error Code Fault Source(s) 0000 No Faults 0010 AC Frequency Low 0011 AC Frequency High 0012 AC Voltage Low 4–4...
  • Page 93 Table 4-1 Fault Codes Error Code Fault Source(s) 0013 AC Voltage High 0014 Grid Interface Failed S 0015 Grid Disconnection 0016 DC Contactor Circuit 152607 Fault Type H=Hardware Fault Description S=Software This fault indicates that the utility grid voltage is above or rose above the maximum allowed value of 110% of nominal Vac for greater than 2 seconds, or 137% of nominal Vac for...
  • Page 94 Troubleshooting Table 4-1 Fault Codes Error Code Fault Source(s) 0017 Phase Error 0020 PV Over-Current 0021 PV Over-Voltage 0023 Bus Voltage High XX31 Left Matrix Over Current 4–6 Fault Type H=Hardware Fault Description S=Software This fault indicates that the PV225S has detected an incorrect phase rotation of the incoming AC grid voltage.
  • Page 95 Table 4-1 Fault Codes Error Code Fault Source(s) XX32 Right Matrix Over Current 0033 Ground Over Current 0040 Programming Software 152607 Fault Type H=Hardware Fault Description S=Software This fault indicates that the PV225S has detected that the AC current on one or more phases of the inverter output has exceeded the maximum allowed value of 712 A...
  • Page 96 Troubleshooting Table 4-1 Fault Codes Error Code Fault Source(s) 0041 State Invalid 0042 Serial EEPROM Write Error 0043 Serial EEPROM Timeout 0044 Bad NOVRAM Memory 0045 Interrupt 2 Timeout 0047 Software Test 4–8 Fault Type H=Hardware Fault Description S=Software The state machine implemented within the CCU2 system software governs the operation of the PV225S.
  • Page 97 Table 4-1 Fault Codes Error Code Fault Source(s) 0048 Bad Memory XX50 Left Matrix Gate 152607 Fault Type H=Hardware Fault Description S=Software This fault indicates that the PV225S has detected that the SRAM DIMM on the CCU2 controller board has failed.
  • Page 98 Troubleshooting Table 4-1 Fault Codes Error Code Fault Source(s) XX51 Right Matrix Gate XX60 Left Matrix Temperature 4–10 Fault Type H=Hardware Fault Description S=Software The CCU2 controller sends digitized timing signals for gating the IGBT’s via the IPM driver board and bi- directional fiber optic communication.
  • Page 99 Table 4-1 Fault Codes Error Code Fault Source(s) XX61 Right Matrix Temperature 0070 Interlock Activated 0071 PV Switch Open 0075 Shutdown Remotely 152607 Fault Type H=Hardware Fault Description S=Software This fault indicates that the PV225S has detected that the temperature of the right IGBT matrix aluminum heatsink has exceeded the maximum allowed value of 95 °C.
  • Page 100 Troubleshooting Table 4-1 Fault Codes Error Code Fault Source(s) 0080 Left Matrix Not ON 0081 Right Matrix Not 0084 Left Matrix Not OFF S 0085 Right Matrix Not 4–12 Fault Type H=Hardware Fault Description S=Software This fault indicates that the PV225S has detected that the left IGBT matrix (FPGA) was not enabled after having sent a command for it to turn on.
  • Page 101 Table 4-1 Fault Codes Error Code Fault Source(s) F000 Shipping Software F100 Software Restarted 152607 Fault Type H=Hardware Fault Description S=Software This fault indicates that the PV225S has detected that the CCU2 controller board has shipping software installed. This software is not operational software.
  • Page 102 4–14...

  • Page 103: Preventative Maintenance

    Preventative Maintenance Chapter 5, “Preventative Maintenance” contains information and procedures for performing preventative maintenance on the PV225S 225 kW Grid-Tied Photovoltaic Inverter.

  • Page 104: Maintenance Safety

    Preventative Maintenance Maintenance Safety Prior to following any Maintenance Procedures, follow the System Shutdown and Lock-out and Tag procedure. Operational Safety Procedures Never work alone when servicing this equipment. A team of two is required until the equipment is properly de-energized, locked-out and tagged, and verified de- energized with a meter.

  • Page 105: Lockout And Tag

    Lockout and Tag Safety requirements mandate that this equipment not be serviced while energized. Power sources for the PV225S must be locked-out and tagged prior to servicing. Each energy source should have a padlock and tag installed on each energy source prior to servicing.

  • Page 106: Figure 5-1 Inverter Ac Terminal Locations In The Main Inverter Enclosure

    Preventative Maintenance Figure 5-1 Inverter AC Terminal Locations in the Main Inverter Enclosure AC Interface Enclosure TB11 TB12 AC Interface Enclosure Figure 5-2 Utility AC Terminal Connections in the AC Interface Enclosure 5–4 AC Ground Bar (TB1) to be used for the Chassis Ground Enlargement of Terminal Connectors...

  • Page 107: Figure 5-3 Pv Terminal Locations

    Maintenance Safety PV POSitive (S2-6) PV NEGative (K2-6T3) PV GrouND (TB4) Figure 5-3 PV Terminal Locations 152607 5–5...

  • Page 108: Periodic Maintenance

    Preventative Maintenance Periodic Maintenance Xantrex Technology recommends that the following preventative maintenance procedures be carried out on the PV225S. Monthly Intervals or As Required Perform the following preventative maintenance tasks on a monthly basis or as required. Aluminum Extrusion Heatsinks ❐...

  • Page 109: Six-Month Intervals

    Enclosure Seals ❐ Inspect the enclosure access panel seal. If damaged, replace with equivalent closed cell foam gasket. Call your Xantrex Technology distributor for factory replacements or specifications. Electrical Connections ❐ Inspect the condition of all wiring within and interfacing to the PV225S.
  • Page 110 5–8...

  • Page 111: Specifications

    Specifications Appendix A provides the environmental and electrical specifications for the PV225S 225 kW Grid-Tied Photovoltaic Inverter.

  • Page 112: System Specifications

    Specifications System Specifications The PV225S has been designed for photovoltaic power systems, which operate within the following specifications. CAUTION: Equipment Damage Operation of the PV225S in a manner other than specified in this manual may cause damage to the PV225S and other system components and will void the terms of the warranty.

  • Page 113: Electrical Specifications

    50% < Vac < 88% 88% < Vac < 110% 110% < Vac < 137% 137% < Vac f < rated -0.7 f > rated +0.5 152607 PV225S-480-P 480 Vac (422 to 528 Vac) 271 A 60 Hz (59.3 to 60.5 Hz) 225 kW...

  • Page 114: Wire Gauge And Torque Requirements

    Specifications Wire Gauge and Torque Requirements Table A-4 provides acceptable wire gauges, bolt sizes, and torque values for AC terminal connections. Table A-4 AC Terminal Wire Gauge, Bolt Size, and Torque Values AC Terminal Acceptable Wire Size Range Connections 500 MCM to #4 AWG (1 stud per pole) (Chassis Ground) TB12 500 MCM to #4 AWG (1 stud per pole)

  • Page 115: Figure A-1 Electrical Diagram (Sample

    Appendix A Schematics Figure A-1 Electrical Diagram (sample) 152607...

  • Page 116: Figure A-2 Pv225S Schematic For Main Power Distribution (152812 A1

    2004 XANTREX TECHNOLOGY INC.. THIS DOCUMENT IS THE PROPERTY OF XANTREX TECHNOLOGY INC., AND SHALL NOT BE REPRODUCED, COPIED, OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF EQUIPMENT, WITHOUT THE EXPRESS WRITTEN PERMISSION OF: XANTREX TECHNOLOGY INC.

  • Page 117: Figure A-3 Pv225S Schematic For Control Power Distribution (152812 A2

    Appendix A 3RD ANGLE PROJECTION Figure A-3 PV225S Schematic for Control Power Distribution (152812 A2) 152607 Schematics REVISIONS: SEE SHEET 1 TITLE: SCHEMATIC, SYSTEM, PV225S-480-P SIZE DWG No. REV. DIMENSIONS ARE IN 152812 INCHES UNLESS OTHERWISE SHOWN SCALE:...

  • Page 118: Figure A-4 Pv225S Schematic For Converter Control Unit (152812 A3

    Schematics 3RD ANGLE PROJECTION Figure A-4 PV225S Schematic for Converter Control Unit (152812 A3) Appendix A REVISIONS: SEE SHEET 1 TITLE: SCHEMATIC, SYSTEM, PV225S-480-P SIZE DWG No. REV. DIMENSIONS ARE IN 152812 INCHES UNLESS OTHERWISE SHOWN SCALE: 152607...

  • Page 119: Warranty And Product Information

    1. What does this warranty cover and how long does it last? This Limited Warranty is provided by Xantrex Technology Inc. (“Xantrex”) and covers defects in workmanship and materials in your PV Series Inverter. This warranty lasts for a Warranty Period of 5 years from the date of purchase at point of sale to you, the original end user customer.
  • Page 120 PV Series Inverter is not intended for use in connection with life support systems and Xantrex makes no warranty or representation in connection with any use of the product for such purposes. Xantrex Technology Inc. 161-G South Vasco Road Livermore, CA 94551 WA–2...

  • Page 121: Product Registration

    To ensure the fastest possible service, please ensure your system information submitted to Xantrex. Please fill the required information in and send a copy of this page to Xantrex Technology Inc. along with a copy of the GUI Commissioning File.
  • Page 122 WA–4...

  • Page 123: Index

    Index 1–8 AC Interface Enclosure 1–18 Accumulated Values 1–5 Anti-Island Protection 2–23 Auto-restart Feature 2–26 Autorun 4–3 Clearing Faults Manually 2–27 Command Prompt 3–2 Commissioning 1–9 Communication Enclosure 2–25 Communications 1–18 Configurable Parameters 1–10 Controls 1–7 Converter Control Unit (CCU2) 1–18 Data Log Acquisition 1–13...
  • Page 124 Index 1–7 Power Distribution Panel 1–7 Power Electronics Matrix 1–5 PV Ground Fault Detection Remote Monitor and Control Features 2–31 Remote/LAN Connection 2–31 Running the GUI 1–2 Self-protection features 2–24 Shutdown A–2 Specifications A–3 Electrical A–2 Environmental Over Voltage, Under Voltage and Frequency Ranges A–3 2–24 Startup...
  • Page 126 Xantrex Technology Inc. 1 800 670 0707 Tel toll free NA 1 360 925 5097 Tel direct 1 800 994 7828 Fax toll free NA 1 360 925 5143 Fax direct customerservice@xantrex.com www.xantrex.com 152607 PC Printed in USA...

Table of Contents
