Wi-Fi Connection Manual
MOBILE PRINTER
Ver. 1.00
XM7-20
http://www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XM7-20 and is the answer not in the manual?

Questions and answers

Related Manuals for BIXOLON XM7-20

Summary of Contents for BIXOLON XM7-20

  • Page 1 Wi-Fi Connection Manual MOBILE PRINTER Ver. 1.00 XM7-20 http://www.bixolon.com...

  • Page 2: Table Of Contents

    Wi-Fi Connection Manual ■ Table of Contents 1. Manual Information ......................3 2. Precautions ........................3 3. How to Connect......................4 3-1 Android Soft AP mode (default) .................. 6 3-2 iOS Soft AP mode (default) ..................7 3-3 How to change infrastructure mode ................8 4.

  • Page 3: Manual Information

    This WLAN manual provides information on the connection of wireless network with the mobile printer. We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following, product specifications and/or user manual content may be changed without prior notice.

  • Page 4: How To Connect

    Wi-Fi Connection Manual 3. How to Connect WLAN can be configured through the printer’s WLAN interface. Likewise, WLAN can also be configured though the printer’s Serial/USB interfaces. (1) Connecting Printer 1) Serial / USB cable Connect Serial/USB cable to Printer, PC device. When Serial cable use, baudrate between Device and printer should be the same.
  • Page 5 Wi-Fi Connection Manual (2) Checking Network Setting Self-test Power FEED While the printer is turned off, turn on the printer while pressing the feed button. The printer setting values will then be printed. - 5 - Ver. 1.00...

  • Page 6: Android Soft Ap Mode (Default)

    Wi-Fi Connection Manual 3-1 Android Soft AP mode (default) 1) Select “Wi-Fi”. 2) Select the printer to connect 3) Select “CONNECT”. 4) Wi-Fi communication is available - 6 - Ver. 1.00...

  • Page 7: Ios Soft Ap Mode (Default)

    Wi-Fi Connection Manual 3-2 iOS Soft AP mode (default) 1) Select “Wi-Fi”. 2) Wi-Fi ON and Select the printer to connect 3) Wi-Fi communication is available - 7 - Ver. 1.00...

  • Page 8: How To Change Infrastructure Mode

    Wi-Fi Connection Manual 3-3 How to change infrastructure mode 1) Enter the IP address of the printer in the address bar, and the following login window will pop up. Enter the ID and Password set for the printer, and then click [LOG IN] (Default User Name: admin, Password: password) 2) Select “Wireless”...
  • Page 9 Wi-Fi Connection Manual 3) Select “infrastructure”, and set SSID, WLAN Security Type. 4) Reboot the Printer. - 9 - Ver. 1.00...

  • Page 10: Factory Reset

    Wi-Fi Connection Manual 4. Factory Reset This function changes the WLAN settings of the printer to the initial factory settings. Method Select the wireless interface on the printer's LCD screen. WLAN Factory reset is available in Interface > WLAN > WLAN Factory Reset When the printer is turned off, the wireless LAN setting is applied as the factory default Factory Reset Values Printer Name...
