3.6.2 CDC Windows driver
This method of USB installation uses the Windows CDC drivers.
For this method to operate, you must install the CDC drivers using the file, AccessISUSBCDC.inf,
which you can download from http://www.access-is.com/gettingstarted/.
The download (USB Driver for CDC Mode) includes full instructions for use.
Windows assigns a virtual COM port to the LSR116 device. You can find out the COM port number
in Device Manager. You will require the port number to configure the LSR116.
3.6.3 Custom HID
3.6.3.1 HID interface using the Access driver (Windows only)
The recommended method for using a USB LSR116 is to configure the device to operate in HID
mode. This allows the device to communicate with the Access driver.
For this method to operate, you must install first the Access driver (Access Serial Ports Service
(ASPS)). Download ASPS from http://www.access-is.com/gettingstarted/.
The download (ASPS Software) includes full instructions for use.
Ensure that you install the driver before connecting the LSR116 to the host.
3.6.3.2 HID interface without the Access driver
There is no additional driver required for this mode. Connect the USB cable from the LSR116 to a
USB port on the computer.

Test the device

3.7
Once you have connected the device and installed the relevant drivers, if applicable, you can test
the device. To do this, wave a piece of paper in front of the glass; the reader's LEDs should
illuminate. If the device fails to respond when connected to the host, refer to the Troubleshooting
section in this document.

Configuration software

3.8
Connect to, and configure, the LSR116 using your own configuration tool, a terminal emulation
program or the Access IS configuration tool, which you can download from
is.com/gettingstarted/.
Refer to page 17 for details of the commands, which you can use to configure the LSR116.

Troubleshooting

3.9
If the LSR116 does not appear to be working, refer to Table 1 to help identify and resolve the
problem. For further assistance, contact support@access-is.com.
Alternatively, use the Contact Customer Support Team page on the Access IS website.
Note: Do not attempt to disassemble the LSR116 if it does not operate correctly.
