Send Commands - Access Interfacing Solutions LSR110 Product Manual

Byte 7
0 [0x02]
1 [0x04]
[0x5D] - ']'
2
[0x51] - 'Q'
3
[0x30] - '0'
4
5 [0x20]100
[0x00] [0x00]
..
...
[0x00] [0x00]
..
60
[0x73] - 's'
61
62 [0x00]
63 0
A.2

Send commands

To send commands to the LSR116, use a HID out report with the following structure:
Byte 7
0 Report ID = 253
1 Data length
2
..
Output data
(up to 62 bytes)
..
..
..
63
A.2.1 Example output report to request firmware version
This example requests the firmware version from the LSR116.
Byte 7
0 253
1 [0x0B]
2
..
[0x16][0x4D][0x0D]AISFWV1.
..
..
..
63
Page 27 of 33
6 5
0 0
6 5
6 5
Bit
4 3
0 0
Bit
4 3
Bit
4 3
2 1
0 0
2 1
2 1
Copyright © Access-IS 2020
