3 - On (Phone optimised)
Adaptive illumination is on. The illumination LEDs switch 'Off' and 'On' continuously when you
present media to the device. The LEDs cycle 'Off' and 'On' until the device reads the barcode or you
remove the media. Use the illumination commands in Table 4 to set the 'Off' and 'On' time.

Indicator control

5.4
These commands control the behaviour of the 'Good Read' and 'Bad Read' LEDs.
Table 5. Indicator LED commands
Command Description
AISGDT
'Good Read' LED indicator duration.
Each unit is equivalent to 100
milliseconds.
AISGDS 'Good Read' duration start.
Specifies when the 'Good Read'
indicator illuminates.
AISGIN
'Good Read' indication stop.
Specifies when the 'Good Read'
indicator extinguishes.
AISBDT 'Bad Read' LED indicator duration.
Each unit is equivalent to 100
milliseconds.
AISBDS
'Bad Read' duration start.
Specifies when the 'Bad Read' indicator
illuminates.
AISBIN
'Bad Read' indication stop.
Specifies when the 'Bad Read' indicator
extinguishes.
AISGSL
Switches between LED locations for the
'Good Read' indicator.
AISBSL
Switches between LED locations for the
'Bad Read' indicator.
Page 21 of 33
Default Parameters/Range
5 0–200
0 - At 'Good Read'
0
1 - At media removal
1 0 - At media removal
1 - Continues after media
removal
8 0–200
0 - At 'Bad Read'
0
1 - At media removal
1 0 - At media removal
1 - Continues after media
removal
5 0 - No lights
1 - Board green lights
2 - Board red lights
4 - Lid green lights
5 - Lid and board green
lights
8 - Lid red lights
10 - Lid and board red
lights
10 0 - No lights
1 - Board green lights
2 - Board red lights
4 - Lid green lights
5 - Lid and board green
lights
8 - Lid red lights
10 - Lid and board red
lights
