4.4.1 Interactive mode example
4.4.1.1 'Good Read' initiated by LSR detecting media
Comments
Media placed in front of
LSR116. LSR116 sends
commands to host
notifying of media.
Host sends a command to
trigger the imager.
Imager activated and
barcode scanned.
Illumination activated as
defined in the settings.
Host decides to accept or
reject the data.
Lights activated as defined
in the 'Good Read'
settings.
No media detected for 0.5
seconds; LSR116 resets.
4.4.1.2 'Good Read' initiated by host sending trigger command
Comments
Host sends a command to
trigger the imager. This
could be due to a second
sensor.
Imager activated, it remains
activated until untriggered
or a 'Good Read/Bad Read'
command is received.
Lights activated as defined
in the settings.
Data read by imager.
Host decides to accept or
reject the data.
Lights activated as defined
in the 'Good Read' settings.
No media detected for 0.5
seconds; LSR116 resets.
Page 16 of 33
LSR Command to Host
[0x16][0x0D]TRIG:1[0x16][0x0A]
-
Data sent as configured (USB/Serial)
-
-
-
LSR Command to Host
-
-
Data sent as configured (USB/Serial)
-
-
-
Host Command to LSR
-
[0x16][0x74][0x0D]
-
'Good Read':
AISXXR0
-
-
Host Command to LSR
[0x16][0x74][0x0D]
-
-
'Good Read':
AISXXR0
-
-
