- Page 1 EIC SOLUTIONS, INC Thermoelectric Air conditioner installation and operation manual FOR 1000 Btu MODEL #’S AAC-146-4XT-E AAC-146-4XT-E-HC AAC-146-XXXXX Cooling Solutions for Mission-Critical Electronics -800-497-4524 EIC SOLUTIONS, INC 215-443-5190...
-
Page 2: Table Of Contents
3. OPERATION 3.1 thermostat set points and heating cooling units ....3.2 maintenance .................... 4. APPENDIX ...................... EIC SOLUTIONS INC. 700 VETERANS WAY, SUITE 200 WARMINSTER, PA 18974 PHONE 1-215-443-5190 or 1-800-497-4524 FAX 215-443-9564 EMAIL info@eicsolutions.com VISIT US ON THE WEB AT www.eicsolutions.com. -
Page 3: General Information
Your EIC Solutions Thermoelectric Air Conditioner operates on this principle so there is no compressor and no expensive, ozone depleting CFC’s. EIC’s air conditioners use Thermoelectric “modules”... -
Page 4: Installation
Horizontally mounted 1000 Btu units always require a factory installed drip pan (part # DP-146H) to prevent dripping condensate from damaging electronic equipment. (Fig. 2.2) In either orientation, issues regarding access should be considered and minimum clearances must be maintained as outlined in Section 2.1 of this manual. -800-497-4524 EIC SOLUTIONS, INC 215-443-5190... - Page 5 COLD SIDE OF AC (INSIDE OF HEAT SINK FINS HEAT SINK FINS ENCLOSURE) DRAIN COLD SIDE FANS TUBE ENCLOSURE HORIZONTAL INSTALLATION OF 1000 BTU UNIT WITH INTERNALLY MOUNTED DP-146H DRIP PAN AND DRAIN TUBE FIGURE 2.2 -800-497-4524 EIC SOLUTIONS, INC 215-443-5190...
-
Page 6: Preparing The Enclosure
4. Set the AC unit in the hole you’ve cut in the enclosure, and using a screwdriver, carefully start the two screws you attached to the gasket to the tapped holes in the enclosure. Do not tighten these at this time. -800-497-4524 EIC SOLUTIONS, INC 215-443-5190... -
Page 7: Install The Drip Pan
Wire colors are as follows: Black or Brown – line White or Blue – line/neutral Green or Green/Yellow – ground A wiring diagram is shown in Fig. 2.4. Amperage for a 220 VAC unit is 6.9 amps. -800-497-4524 EIC SOLUTIONS, INC 215-443-5190... - Page 8 The cold side fan always runs to circulate air within your enclosure thereby eliminating any “hot spots”. The hot side fans will only run when the air conditioner is cooling – they are “pumping” the heat from the inside of your enclosure to the outside air. -800-497-4524 EIC SOLUTIONS, INC 215-443-5190...
-
Page 9: Operation
NEVER EXPOSE THE COLD SIDE OF ANY AIR CONDITIONER (INSIDE THE ENCLOSURE) TO WATER. If you have any questions about any aspect of your EIC air conditioner, don’t hesitate to call us at the numbers listed below. -800-497-4524 EIC SOLUTIONS, INC 215-443-5190... -
Page 10: Appendix
Enclosure cutout for Standard Flange models only, DO NOT use with Narrow Flange models or Extension Frame Drawing A Enclosure cutout for Narrow Flange models only, DO NOT use with standard models or Extension Frame Drawing B -800-497-4524 EIC SOLUTIONS, INC 215-443-5190... - Page 11 APPENDIX C Enclosure cutout for 1000 BTU air conditioner EXTENSION FRAME ONLY Holes to be .203” -800-497-4524 EIC SOLUTIONS, INC 215-443-5190...
