- Page 1 EIC SOLUTIONS, INC EIC SOLUTIONS, INC EIC SOLUTIONS, INC EIC SOLUTIONS, INC ..Thermoelectric Air conditioner installation and operation manual FOR 400 Btu MODEL #’S AAC-140B-4XT-EP AAC-140B-4XT-HC-EP Cooling Solutions for Mission Cooling Solutions for Mission- - - -...
- Page 2 This manual is intended for models AAC-140B-4XT-EP and AAC-140B-4XT-HC-EP only. For use in: Class I, Division 2, Groups A – D Hazardous Locations Operating temperature code: T4 Ambient temperature range: -20 to 60°C Voltage: 120V or 220V AC These thermoelectric air conditioning units are to be mounted half outside and half inside a cabinet.
-
Page 3: Table Of Contents
INSTALL THE DRIP PAN ................APPLY POWER .................... 3. OPERATION THERMOSTAT SET POINTS AND HEATING COOLING UNITS ... MAINTENANCE ..................EIC SOLUTIONS INC. EIC SOLUTIONS INC. EIC SOLUTIONS INC. EIC SOLUTIONS INC. 700 VETERANS WAY, SUITE 200 WARMINSTER, PA 18974... -
Page 4: General Information
Your EIC Solutions Thermoelectric Air Conditioner operates on this principle so there is no compressor and no expensive, ozone depleting CFC’s. EIC’s air conditioners use Thermoelectric “modules”... -
Page 5: Installation
If one of these orientations is the only possible configuration, contact the Engineering Dept. at EIC for a custom solution. Issues regarding access should be considered and minimum clearances must be maintained as outlined in Section 2.1 of this manual. 5 5 5 5 -800-497-4524 EIC SOLUTIONS, INC 215-443-5190... - Page 6 COLD SIDE HEAT SINK FINS HOT SIDE HEAT SINK FINS DP-140V DRIP PAN DRAIN TUBE VERTICAL INSTALLATION OF AAC-140B-4XT, 400 BTU UNIT WITH DP-140V VERTICAL DRIP PAN AND DRAIN TUBE FIGURE 2.1 6 6 6 6 -800-497-4524 EIC SOLUTIONS, INC 215-443-5190...
-
Page 7: Preparing The Enclosure
6. Remove the two starter screws and place a nylon washer on each and reinstall. 7. Tighten all screws. 7 7 7 7 -800-497-4524 EIC SOLUTIONS, INC 215-443-5190... - Page 8 0.175 0.175 5.250 2.800 3.000 11.250 3.000 2.800 2.800 2.800 FIG. 2.3 8 8 8 8 -800-497-4524 EIC SOLUTIONS, INC 215-443-5190...
-
Page 9: Install The Drip Pan
“hot spots”. The hot side fan will only run when the air conditioner is cooling – they are “pumping” the heat from the inside of your enclosure to the outside air. 9 9 9 9 -800-497-4524 EIC SOLUTIONS, INC 215-443-5190... -
Page 10: Operation
NEVER EXPOSE THE COLD SIDE OF THE AIR CONDITIONER (INSIDE THE ENCLOSURE) TO WATER. If you have any questions about any aspect of your EIC air conditioner, don’t hesitate to call us at the numbers listed below. -800-497-4524 EIC SOLUTIONS, INC 215-443-5190...
