HD IR Speed Dome User's Manual
Version 1.0.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPFX-P4030X-IRW1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICRealtime IPFX-P4030X-IRW1

Summary of Contents for ICRealtime IPFX-P4030X-IRW1

  • Page 1 HD IR Speed Dome User’s Manual Version 1.0.1...
  • Page 2 Table of Contents FEATURES AND FUNCTIONS ................... 1 General Introduction ..............................1 Features ..................................1 1.2.1 Zoom Speed Limit ..............................1 1.2.2 OSD ..................................1 1.2.3 Preset Setup and Call ............................1 1.2.4 Auto Scan ................................1 1.2.5 Auto Touring ................................1 1.2.6 Auto Pattern ................................

  • Page 3: Table Of Contents

    CABLE CONNECTION ....................... 9 Combination Cable Connection ..........................9 System Layout ................................ 10 4.2.1 System Connection ............................. 10 4.2.2 Alarm Connection ..............................10 FAQ ........................... 11 Daily Maintenance ..............................11 Problems and Solutions ............................11 APPENDIX Ⅰ LIGHTNING PROOF AND SURGE PROTECTION ........12 APPENDIX 2 TOXIC OR HAZARDOUS MATERIALS OR ELEMENTS ......
  • Page 4 Important Safeguards and Warnings 1．Electrical safety  All installation and operation here should conform to your local electrical safety codes.  We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. ...
  • Page 5  Please keep the dustproof cap back to protect the CCD or CMOS part if the device does not work for a long time.  Do not touch CCD (CMOS) component. You can use the blower to clean the dust on the surface of the device.
  • Page 6 1 Features and Functions 1.1 General Introduction This series HD IR speed dome product is an integrated high intelligent speed dome. It adopts new configuration design and is easy for the project construction. This is a digital and intelligent product of vivid video.
  • Page 7  Camera diagnostics (mainly zoom function diagnosis)  Display dome information. 1.2.10 Day/Night Mode (B/W & Color Mode) Auto/manual switches in low illumination. There are several modes such as photoresistor, auto, manual and etc. This function needs the speed dome driver (camera) supported. 1.2.11 Auto Focus Support camera auto focus function.
  • Page 8 2 Quick Configuration Tool 2.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 2.2 Operation Double click the “ConfigTools.exe”icon, you can see an interface is shown as in Figure 2-1.
  • Page 9 Figure 2-2 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 2-3. Figure 2-3 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set.
  • Page 10 Figure 2-4 After you logged in, the configuration tool main interface is shown as below. See Figure 2-5. Figure 2-5 For detailed information and operation instruction of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD.
  • Page 11 3 Web Operation This series speed dome product supports the Web access and management via PC. Web includes several modules: live view, PTZ, setup, alarm, logout and etc. Speed dome factory default setup:  IP address: 192.168.1.108.  User name: admin ...
  • Page 12 Figure 3-2 After installation, the interface is shown as below. See Figure 3-3. Please input your user name and password. Default factory name is admin and password is admin. Select the network connection type. Note: For security reasons, please modify your password after you first login. Figure 3-3 After you logged in, you can see the main window.
  • Page 13 Figure 3-4 Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction.

  • Page 14: Cable Connection

    4 Cable Connection 4.1 Combination Cable Connection The speed dome combination cable includes network cable, audio/video cable connection port, RS485 connection port, alarm input and output port. Please refer to the label for detailed information.  Please note the IE6 does not support alarm upload function. Please use IE7 or higher version. ...

  • Page 15: System Layout

    Two alarm output channels. When there is an alarm from current  channel, system activates relay or not. ALARM Alarm output relay default setup is NO.  Note: The default setup: 1-channel alarm output, 2-channel alarm output optional. 4.2 System Layout 4.2.1 System Connection Please refer to Figure 4-1 for system connection information.

  • Page 16: Faq

    5 FAQ 5.1 Daily Maintenance Please clean dome cover regularly to get vivid image. Handle the cover with care. Use water to wash. Don’t use cloth to clean. Note: The sweat from your hand may erode plating surface, your nail may scrape dome cover resulting in blur image.

  • Page 17: Appendix Ⅰ Lightning Proof And Surge Protection

    6 Appendix Ⅰ Lightning Proof and Surge Protection This series speed dome adopts TVS lightning protection technology. It can effectively prevent damages from various pulse signals below 1500W, such as sudden lighting and surge. While maintaining your local electrical safety code, you still need to take necessary precaution measures when installing the speed dome in the outdoor environment.

  • Page 18: Appendix 2 Toxic Or Hazardous Materials Or Elements

    7 Appendix 2 Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE ○ ○ ○ ○ ○ ○ Sheet Metal ○ ○ ○ ○ ○ ○ Plastic Parts ○ ○ ○ ○ ○...
  • Page 19 Note • This manual is for reference only. Slight difference may be found in the user interface. • All the designs and software here are subject to change without prior written notice. • All trademarks and registered trademarks are the properties of their respective owners. •...
