Instruction Manual for HI-Series Mixer (SP100-S, SP25-S, SP30-S, SP40-S, SP60-S, SPB-80HA, SPA-80HA) Manufactured Exclusive for Robot Coupe Australia & NZ Pty Ltd. ROBOT COUPE AUSTRALIA & NZ Pty Ltd. Unit 3 / 43 Herbert Street, Artarmon NSW 2064, AUSTRALIA Tel： (02) 9478 0300 Fax：... - Page 2 CAUTION Read before you operate the machine It is important to read this manual and following the instructions before operate the machines. This mixer is designed as a safe and efficient food processing product as long as the machine is used in accordance with the instructions in this manual and is properly maintained.
-
Page 3: Overall View Of The Mixer
Overall View of the Mixer Model SP60-S A) Bowl B) Removable Bowl Guard C) Planetary Shaft D) Attachment Hub* E) Control Panel F) Gear Lever G) Additions Chute H) Bowl Lift Handle (Wheel) I) Bowl Cradle NOTE: Attachment Hub is optional. Control Panel A) Emergency Stop B) Start... -
Page 4: Installation Instructions
Installation Instructions INSTALLATION The machine is supplied factory lubricated and ready to run. It should be positioned on any solid, level and non-skid work surface that is nonflammable. Install in work area with adequate light and space. For SP25-S or Smaller Capacity Model, you may place the mixer on bench which is capable of supporting a load of mixer’s weight. -
Page 5: Operating Instructions
Installation Instructions The minimum requirement for all electrical equipment is correct operation between air temperature of +5℃ and +40℃. Electrical equipment is capable of operating correctly when the relative humidity does not exceeding 95% at a maximum temperature of +40℃. Electrical equipment is capable of operating correctly at altitude up to 1000m. - Page 6 Operating Instructions TOOL SELECTION Beater: Firm mixes such as light The beater, whisk and spiral dough hook are tools for pastry, cakes biscuits, icings the work implied by their names. Do not use the beater fillings and mashed vegetables. for dough making or the whisk for anything other than whisking, aerating or mixing light mixtures.
- Page 7 Operating Instructions THE REMOVABLE BOWL GUARD The interlocking bowl guard now is available to remove for cleaning purpose. With separated handles, it can easy take out the bowl guard and cleaning in a sink or dishwasher. Open / Closing the Bowl Guard: To open the bowl guard, holding the separated handle, and rotating clockwise.
- Page 8 Operating Instructions CONTROLS The Timer (C) is arranged to automatically stop the machine after the selected interval. An untimed position is provided for manually controlled mixing cycles. Before starting the mixer it is necessary to set the mixing duration or select the manual position – the mixer will not operate in the 0 position.
- Page 9 Operating Instructions SPEED SELECTION Before changing speeds, the mixer must always be STOPPED first. The necessary speed can then be selected before restarting the machine by pressing the Green Start Button. NOTE: The Model SPA-80HA, SPA-80A, SPB-80HA and SPB-80A will automatically shut off if the speed is changed during operation.
- Page 10 Operating Instructions BOWL SCRAPER NOTE: Bowl Scraper is an optional accessory. Please consult the local dealer for ordering. The Bowl Scraper is used in conjunction with the Beater or Wire Whip agitator. The Bowl Scraper is easily attached to the mounted bracket when needed. While the agitator is mixing the product, the scraper is continuously scraping the entire inside of the mixing bowl.
-
Page 11: Cleaning Instructions
Cleaning Instructions CARE OF YOUR MIXER CAUTION: ALWAYS DISCONNECT OR UNPLUG THE ELECTRICAL POWER FROM THE MIXER BEFORE CLEANING. The mixer is designed for simple maintenance carried out by operators. It may be necessary from time to time to apply a little Vaseline and oil to the rods on which the bowl cradle slides. If so, use a little food quality lubricant, ensuring that there is no excess oil that could contaminate the food mix. - Page 12 In terms of the rest model from SP100-S to SP60-S, please refill the lubricant inside the gearbox every 5 years. We recommended that this servicing or maintenance work must be carried out by trained technicians from a Robot Coupe appointed distributor. CAUTION: Please use either Mobil lubricant “XHP 222”...
-
Page 13: Troubleshooting
Troubleshooting FAULT FINDING FAULT CHECK POSSIBLE REASON AND ACTION REQUIRED No power to mixer Check plug socket Mixer not plugged into a live socket or not switched on Check wiring in plug Plug incorrectly wired – rewire correctly Check fuse in plug Possible faulty fuse –... -
Page 14: Capacity Chart Table
Capacity Chart Table Agitator SPA-80HA, SPA-80A, Product SP100-S SP25-S SP30-S SP40-S SP60-S SPB-80HA, SPB-80A Speed Waffle or Hot Cake Beater 5 ltrs. 9.5 ltrs. 11 ltrs. 15 ltrs. 23 ltrs. 28 ltrs. Batter Whip 2 ltrs. 4.5 ltrs. 5.5 ltrs. 8.5 ltrs. -
Page 15: Mixer Agitator/Application
MIXER AGITATOR/APPLICATION ATTACHMENT APPLICATION FOOD PRODUCTS RECOMMENDATIONS Multi purpose agitator Mashing potatoes Use 1 FLAT BEATER speed for starting Mixing cakes Medium speed for finishing Icings Maximum blending of air Whipping cream ... -
Page 16: Robot Coupe Australia & Nz Pty Ltd
ROBOT COUPE AUSTRALIA & NZ Pty Ltd. Unit 3 / 43 Herbert Street, Artarmon NSW 2064, AUSTRALIA Tel： (02) 9478 0300 Fax： (02) 9460 7972 http://www.robotcoupe.com.au e-mail： sales@robotcoupe.com.au...
