Summary of Contents for Frico 2210CA

  • Page 1 Original instructions PA2200C ..20 ..27 ..33 ..40 ..48 ..55 ..63 ..71 ..79 ..86 ..92...
  • Page 2 PA2200C Introduktionssidorna består huvudsakligen av bilder. För översättning av de engelska texter som används, se respektive språksidor. The introduction pages consist mainly of pictures. For translation of the English texts used, see the respective language pages. Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de engelske tekstene, se de respektive språksidene.
  • Page 3 PA2200C PA2200C 1026 / 1536 / 2026 1050 / 1560 / 2050 90,5 min 500 Cu ø15 min 500 min 500 Cu ø15 min 500 min 500 Fig. 1 Gland Gland ø17,5 ø17,5 Knock-out ø32,5 Knock-out ø25,5 Gland ø20,5 Knock-out ø17,5 Fig.
  • Page 4 PA2200C TX20 Fig. 3: Open the unit.
  • Page 5 PA2200C Minimum distance Fig. 4 30 mm 60 mm Fig. 5...
  • Page 6 PA2200C Mounting with wall brackets ø8 (3x) ø5 ø10 2 pcs PA2210 PA2215 2 pcs PA2220 3 pcs Fig. 6: Mounting with wall brackets...
  • Page 7 PA2200C Accessories PA34TR15 PA2210C, PA2215C, 1 m PA34TR20 PA2220C, 1 m PA2P15 PA2210C, PA2215C, 1 m PA2220C, 1 m PA2P20 PA2210C, PA2215C PA2PF15 PA2PF20 PA2220C PAMLK PA2200C PA2EF10 PA2210C W PA2EF15 PA2215C W PA2EF20 PA2220C W PA34TR PA2P PA2PF PAWAK PA2200C W FHDN15 PA2200C W...
  • Page 8 PA2200C Voltage motor: 230V~ Ambient, no heat - PA2200C A Type Output Airflow* Sound Sound Voltage Amperage Length Weight power* pressure* motor motor [kW] [dB(A)] [dB(A)] [mm] [kg] PA2210CA 900/1200 42/51 230V~ 0,45 1050 PA2215CA 1150/1800 40/52 230V~ 1560 PA2220CA 1800/2400 43/53 230V~...
  • Page 9 PA2200C PA2210CA / PA2215CA / PA2220CA...
  • Page 10 PA2200C PA2210CE03 / PA2210CE05 0 -10V N H1H2 N F1 F2 F3...
  • Page 11 PA2200C PA2210CE051 0 -10V N H1H2 N F1 F2 F3...
  • Page 12 PA2200C PA2215CE08 / PA2220CE10 0 -10V N H1H2 N F1 F2 F3...
  • Page 13 PA2200C PA2210CE08 / PA2215CE12 / PA2220CE16 0 -10V N H1H2 N F1 F2 F3...
  • Page 14 PA2200C PA2210CW / PA2215CW / PA2220CW 0 -10V N H1H2 N F1 F2 F3...
  • Page 15 PA2200C PA2210CE05YD / PA2215CE08YD 0 -10V N H1H2 N F1 F2 F3...
  • Page 16 PA2200C PA2220CE10YD 0 -10V N H1H2 N F1 F2 F3...
  • Page 17 PA2200C PAMLK, motor alarm card 0 -10V N H1H2 N F1 F2 F3 N F1 F2 F3...
  • Page 18 PA2200C Output charts water Supply water temperature:110 °C Water temperature: 110/80 °C Room temperature: +18 °C Room temperature: +18 °C Outlet air temperature: +35 °C* Type Airflow Output Return Water Pressure Output * Outlet Water Pressure position water temp. flow drop air temp.
  • Page 19 27,9 0,04 2400 45,2 0,22 12,8 25,4 0,07 PA2220CW 1400 38,9 0,08 27,1 0,05 ) Recommended outlet air temperature for good comfort and optimized output. ) Nominal output at given supply and return water temperature. See www.frico.se for additional calculations.
  • Page 20 PA2200C Installation and operating instructions General Instructions Mounting with wall brackets (fig. 6) 1. Mount the brackets on the wall, see fig.6A Read these instructions carefully before and dimension drawing fig.1. If the wall is installation and use. Keep this manual for uneven the brackets must be compensated future reference.
  • Page 21 Note that the unit shall be preceded by a the screws on the top of the unit and then regulating valve, see Frico valve kit. detach the bent edge at the bottom. (Fig.3) The water coil is connected on the upper 3.

  • Page 22: Maintenance

    PA2200C Maintenance Temperature control Unit with water heating See control pages. The appliance filter should be cleaned regularly to ensure the air curtain effect and Replacing motor or impeller the heat emission from the device. How often 1. Remove the front. depends on local circumstances.
  • Page 23 PA2200C Safety For units with electrical heating, also check the fol- • For all installations of electrically heated lowing: products should a residual current circuit • Power supply to electric heater coil; check breaker 300 mA for fire protection be used. fuses and circuit-breaker (if any).
  • Page 24 PA2200C Control The air curtain has an integrated control system and can be remotely controlled. 230V~ Actuator SD230 Black (remove the quick Brown connector) Blue PA2DR (accessory) External on/off Eg time switch. External potential free closure = off Factory setting dip-switches - Unit without heating Factory setting dip-switches - Unit with water or with electrical heating heating...

  • Page 25: Functional Test

    PA2200C Fan step 1/2/3 ~20 °C Heat step Electric: Half/full power Water: On/off (1 LED) On/off Control panel - Unit with electrical heating or water heating Fan step 1/2/3 On/off Control panel - Unit without heating Remote control - on/off, fan steps and heating steps Functional test Temperature control Functional test is started using the remote...
  • Page 26 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net.
