3/8" AIR RATCHET
STMT78401-8
A
Serial Number
Parts Number
A
K45021
B
45015
C
K15014
D
15012
E
45013
F
K15014
G
75020
H
45055
I
K75001
J
75018
K
K66024
L
75003
C
B
E
I
D
H
F
G
K
J
Description
Q'ty
Ratchet Housing repair kit
Locking Nut
Gear repair kit
Thread Ring Gear
Washer
Cylinder repair kit
Exhaust Deflector
O-Ring
Housing repair kit
Housing grip
Air Inlet repair kit
Trigger
3/8" AIR RATCHET
L
1
1
1
1
1
1
1
1
IT IS ADVISABLE TO:
1
CAREFULLY READ THE INSTRUCTIONS BEFORE USING THE PNEUMATIC TOOLS
WEAR SAFETY GOGGLES AND HEARING PROTECTION
1
1
1
Advertisement
Table of Contents
Related Manuals for Stanley AUTOMATIVE STMT78401-8
Summary of Contents for Stanley AUTOMATIVE STMT78401-8
- Page 1 Manual size: 145W x 210H mm Spread size: 290W x 210H mm OUTSIDE 3/8" AIR RATCHET STMT78401-8 3/8" AIR RATCHET Serial Number Parts Number Description Q'ty K45021 Ratchet Housing repair kit 45015 Locking Nut K15014 Gear repair kit 15012 Thread Ring Gear 45013 Washer K15014...
