Table Of Contents; Models Available - Monogram Advantium ZSB9231NSS Installation Instructions Manual

BEFORE YOU BEGIN
Read these instructions completely and
carefully.
IMPORTANT - Save these instructions
for local inspector's use.
IMPORTANT
- Observe all governing codes and
ordinances.
Note to Installer
•
instructions with the Consume
Note to Consumer
•
with your Owner's Manual for future reference.
Skill Level
• - Installation of this appliance
requires basic mechanical and electrical skills.
• Completion Time - 1 Hour.
• Proper installation is the responsibility
of the installer. Product failure due to improper
installation is not covered under the warranty.
See Owner's Manual for warranty information.
IMPORTANT - Use this oven only for its
intended purpose. Never use the oven for warming or
heating a room. Prolonged use of the oven without
proper ventilation can be hazardous.
CAUTION
For personal safety, remove
house fuse or oven circuit breaker before beginning
installation to avoid severe or fatal shock injury.
CAUTION
For personal safety, the
mounting surface must be capable of supporting the
cabinet load, in addition to the added weight of the
oven and drawer, plus additional oven loads.
2
Safety Information
- Be sure to leave these
r.
- Keep these instructions
CONTENTS
Design Information
Models Available ............................................... 2
Product Dimensions and Clearances ................ 3
Tools and Parts Required ................................. 3
Advance Planning ............................................. 3
Installation Preparation
Electrical Requirements .................................... 4
Install Junction Box ........................................... 4
Preparing the Opening (Installation without
an accessory storage drawer) ........................ 5
Flush Mount ...................................................... 7
With Accessory Storage Drawer ....................... 8
Installation Instructions
Step 1, Remove Packaging and Parts .............. 9
Step 2, Route Conduit ..................................... 10
Step 3, Install Bottom Trim .............................. 11
Step 4, Install Mounting Screws ...................... 11
Step 5, Finalize Installation ............................. 11

MODELS AVAILABLE

ZSB9231NSS - Stainless Steel
ZSB9232NSS - Stainless Steel
31-7000080 Rev. 2
