SECURITY SYSTEM ONLY
REMOTE CAR STARTER ONLY
SECURITY SYSTEM AND REMOTE CAR STARTER
AUTOMATIC / MANUAL TRANSMISSION - 1-WAY REMOTES
FTX84-1W
Model : FTX84
FCC ID : 2ACKU-R1W02FM
IC : 12084A-R1W02FM
Manufacture : FORTIN
DESIGNED & ENGINEERED IN CANADA
DOC#: 68321 - REV:G 20170908 © 2017 ALL RIGHTS RESERVED
Model : ANT-FMH-2W
FCC ID : 2ACKU-A2W01FM
IC : 12084A-A2W01FM
Manufacture : FORTIN
User Guide
Advertisement
Table of Contents
Related Manuals for Fortin FTX84-1W
Summary of Contents for Fortin FTX84-1W
- Page 1 Model : FTX84 Model : ANT-FMH-2W FCC ID : 2ACKU-R1W02FM FCC ID : 2ACKU-A2W01FM IC : 12084A-R1W02FM IC : 12084A-A2W01FM Manufacture : FORTIN Manufacture : FORTIN DESIGNED & ENGINEERED IN CANADA DOC#: 68321 - REV:G 20170908 © 2017 ALL RIGHTS RESERVED...
-
Page 2: Table Of Contents
TABLE DES MATIÈRES TABLE OF CONTENTS TABLE OF CONTENTS ......................... 2 INTRODUCTION ..........................2 CAUTION - WARNING ......................... 3 NOTE ................................3 INDUSTRY CANADA USER NOTICE ...................... 3 AVIS D’INDUSTRIE CANADA AUX UTILISATEURS ................. 3 GOVERNMENT REGULATIONS ..................................3 USING THE REMOTE CONTROL ......................4 REMOTE-STARTING .......................... -
Page 3: Caution - Warning
CAUTION - WARNING IT IS THE RESPONSIBILITY OF THE REMOTE CAR STARTER OPERATOR TO: • ensure that the vehicle is parked in a safe and responsible manner. • ensure that the vehicle is not remotely started indoors (garage, underground parking). •... - Page 4 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with the Industry Canada Radio Standards Specifi cation RSS 210.
-
Page 5: Using The Remote Control
USING THE REMOTE CONTROL The remote starter is equipped with two 1-way 4-button multi-channel remote control. TIME COMMAND DESCRIPTION PRESSED Locks all doors, arm the anti-theft system and activates the Alarm (if LOCK 0,5 SEC. installed). Press LOCK for 3 sec- onds to activate the Panic Mode Unlocks all doors, disarms the anti-theft system and deactivates... -
Page 6: Remote-Starting
REMOTE-STARTING REMOTE-STARTING THE VEHICLE This Remote-Starter supports both manual and automatic transmission vehicles. For manual transmis- sion vehicles see the Ready Mode section. REMOTE-STARTING STEP To remote-start the vehicle press the START button for approximately 3 second. STEP The parking lights will turn on to indicate a response to the Remote-Start signal. - Page 7 METHOD 1 PROGRAMMED BY DEFAULT THIS METHOD WILL ACTIVATE THE REMOTE CAR STARTER SEQUENCE ONLY WHEN THE END USER IS USING THE REMOTE CAR STARTER REMOTE: The vehicle must be running. STEP 1 Make sure that all doors are closed and the transmission is in the NEUTRAL position.
-
Page 8: Driving Off
DRIVING OFF When the vehicle is running with the Remote-Starter, enter the vehicle and proceed with the following steps: STEP 1 Insert the key and turn it to the ignition (ON/Run) position. Warning: Do not turn the key to the START position when the engine is running. -
Page 9: Turbo Mode (Automatic Transmission)
STEP 4 Release the brake pedal. STEP 5 Press the remote START button. The parking lights will fl ash once and then remain on. STEP 6 Remove the key from the ignition barrel. The vehicle will continue to run with the the Remote-Starter. STEP 7 Exit the vehicle and close all of the doors. -
Page 10: Valet Coding Disabled (Default)
after the doors are locked. The LED will turn off only after the Remote-Starter/Alarm exit Valet Mode. VALET CODING DISABLED (DEFAULT): To activate and deactivate Valet Mode using the valet switch proceed with the following steps: STEP 1 Insert the key and turn it to the ignition (ON/RUN) position. The vehicle does not need to be started. -
Page 11: Auxiliary Use
To enable Cold Start Timer Mode proceed with the following steps. ress and release the FUNCTION button, within 12 seconds simultaneously press and and hold the LOCK and START buttons for 1 second. To disable Cold Start Timer Mode do any of the following: •... -
Page 12: Remote Door Locks
WARNING: This Remote-Starter must be installed by a trained professional. Improper modifi cations to any of the following settings could adversely affect the reliability of the Remote-Starter and/or the vehicle’s operation. Confi gurable Options: - Remote Door Locks - Active or Passive Arming - Ignition Door Locks - Security Lock - Trunk/Hatch Release... -
Page 13: Alarm
RUNTIME On gas engines the Remote-Starter can run the vehicle for either 3, 7 or 15 (default) minutes. On diesel engines the Remote-Starter can run the vehicle for either 6, 15 or 30 (default) minutes. RUNTIME RESET Once the vehicle is running with the Remote-Starter the runtime can be reset (before it expires) at any time by pressing the START button while the vehicle is Remote-Started. -
Page 14: Vehicle Locator/Panic Mode
VEHICLE LOCATOR/PANIC MODE To locate your vehicle in a busy parking lot press the LOCK button for 3 seconds to sound the horn/siren (If installed) and fl ash the parking lights. Press unlock to cancel this Mode. Note: If an Alarm pre-triggered zone is in memory, this Mode will NOT clear this zone from memory. SENSOR DEACTIVATION In cases where a sensor is too sensitive and causes false alarms, it is possible to disable some of the zones. -
Page 15: Remote Start / Alarm Diagnostics
installation centre may refuse all fees incurred by the latter service centre (if any). REMOTE START / ALARM DIAGNOSTICS REMOTE STARTER DIAGNOSTICS ALARM DIAGNOSTICS Parking Light fl ashes (before starting) : Parking Light fl ashes (after disarm) : Ready mode disabled Door open –...
