SECURITY SYSTEM ONLY
REMOTE CAR STARTER ONLY
SECURITY SYSTEM AND REMOTE CAR STARTER
AUTOMATIC / MANUAL TRANSMISSION - 1-WAY REMOTES
FTX74-1W
MODEL : FTX74
FCC ID : 2ACKU-R1W03FM
IC : 12084A-R1W03FM
Manufacture : FORTIN
DESIGNED & ENGINEERED IN CANADA
DOC#: 68331 - REV:G 20170628 © 2017 ALL RIGHTS RESERVED
Model : ANT-FMH-2W
FCC ID : 2ACKU-A2W01FM
IC : 12084A-A2W01FM
Manufacture : FORTIN
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Fortin FTX74-1W

Summary of Contents for Fortin FTX74-1W

  • Page 1 MODEL : FTX74 Model : ANT-FMH-2W FCC ID : 2ACKU-R1W03FM FCC ID : 2ACKU-A2W01FM IC : 12084A-R1W03FM IC : 12084A-A2W01FM Manufacture : FORTIN Manufacture : FORTIN DESIGNED & ENGINEERED IN CANADA DOC#: 68331 - REV:G 20170628 © 2017 ALL RIGHTS RESERVED...

  • Page 2: Table Of Contents

    TABLE DES MATIÈRES TABLE OF CONTENTS TABLE OF CONTENTS ......................... 2 INTRODUCTION ..........................2 CAUTION - WARNING ......................... 3 NOTE ..............................3 INDUSTRY CANADA USER NOTICE ...................... 3 GOVERNMENT REGULATIONS ......................3 USING THE REMOTE CONTROL ......................4 REMOTE-STARTING ..........................4 REMOTE-STARTING THE VEHICLE .......................

  • Page 3: Table Of Contents Table Of Contents

    CAUTION - WARNING IT IS THE RESPONSIBILITY OF THE REMOTE CAR STARTER OPERATOR TO: • ensure that the vehicle is parked in a safe and responsible manner. • ensure that the vehicle is not remotely started indoors (garage, underground park- ing).
  • Page 4 AVIS D’INDUSTRIE CANADA AUX UTILISATEURS Le fonctionnement est sujet aux deux conditions suivantes: (1) cet appareil pourrait ne pas causer d’interférence, et (2) cet appareil devrait accepter n’importe quelle interférence, même celle qui pourrait causer un fonctionnement indésirable à l’appareil. Pour réduire la potentielle interférence radio aux autres util- isateurs, le type d’antenne et son gain devraient être choisis de telle sorte que le (EIRP) est supérieur à...

  • Page 5: Using The Remote Control

    USING THE REMOTE CONTROL The remote starter is equipped with two 4-button multi-channel remote control . TIME COMMAND DESCRIPTION PRESSED Locks all doors, arm the anti-theft system and activates the Alarm (if LOCK 0,5 SEC. installed). Press LOCK for 3 sec- onds to activate the Panic Mode Unlocks all doors, disarms the anti-theft system and deactivates...

  • Page 6: Accessory Preset

    Approximately 5 seconds later the engine will crank. Once the vehicle starts STEP the parking lights will turn on and remain on for the entire duration of the Remote-Starter runtime, or until the Remote-Starter is shut down. If the vehicle fails to start on the fi rst attempt, the Remote-Starter will wait 3 seconds before it will attempt to start the vehicle again.

  • Page 7: Driving Off

    STEP 5 Remove the key from the ignition barrel. The vehicle will remain running with the Remote-Starter. STEP 6 Exit the vehicle and close all of the doors. The Remote-Starter will stop running once all the doors are closed. METHOD 2 This method must be programmed by the installer during installation. THIS METHOD WILL ACTI- VATE THE REMOTE STARTER SEQUENCE EVERYTIME THE END USER IS LEAVING THE VEHICLE.

  • Page 8: Idle Mode (Manual Transmission)

    to reset this timer. To activate Idle Mode (automatic transmission) proceed with the following steps: STEP 1 With the key in the barrel at the ignition (ON/RUN) position and the en- gine running, press the START button until the parking lights turn on. STEP 2 Turn the key to the OFF position and remove the key from the ignition barrel.

  • Page 9: Turbo Mode (Manual Transmission)

    STEP 1 With the engine already running, press the remote START button until the parking lights come on. STEP 2 Remove the key from the ignition barrel. The vehicle will continue to run with the the Remote-Starter. STEP 3 Exit the vehicle and close all of the doors. The vehicle will continue to run after all the doors are closed.

  • Page 10: Cold Start Timer Mode

    To enter Valet Mode using the remote transmitter proceed with the following steps: STEP 1 Press and release the FUNCTION button, within 12 seconds simultaneously press and hold the LOCK and UNLOCK buttons for 1 second. STEP 2 The LED will turn ON solid and remain ON. To exit Valet Mode using the remote transmitter proceed with the following steps: STEP 1 Press and release the FUNCTION button, within 12 seconds...

  • Page 11: Remote Locking And Unlocking

    Aux 2 : Passenger side sliding door (if installed). Press and relase the FUNCTION button (the remote LED fl ashes slowly white) within 12 seconds press the UNLOCK button. Note: The function of the auxiliary outputs may vary depending on the vehicle and the installation. In most cases these outputs are not used, and in some cases they may be used to control other features such as the power windows, sunroof, or heated seats.

  • Page 12: Active Or Passive Arming

    ACTIVE OR PASSIVE ARMING Passive Mode will allow the Alarm to automatically rearm itself 60 seconds after it is disarmed if no door(s) (or trunk) are open(ed). Opening a door before the 60 seconds has expired will reset the timer but will also prevent the Alarm from locking the doors.

  • Page 13: Open Zone Notification

    NOTE 1: If the vehicle is running with the Remote-Starter and the Alarm is triggered the Remote-Starter will shut down immediately. This applies to Cold Start, Turbo and Idle Modes. However the vehicle can be Remote- Started at a later time (i.e. The Alarm will not cancel Cold Start Timer). NOTE 2: When an alarm infraction has occurred the LED on the antenna will quickly fl ash 3 times followed of a long pause.

  • Page 14: Transmitter Range

    TRANSMITTER RANGE Several factors may affect the operating range of the remote transmitter: • A weak transmitter battery. • The operating environment such as in the city and airports due to radio interference, cell phone towers, etc… • Several types of metal such as the vehicle itself, other vehicles, the windshields tint lines and large build- ings.

  • Page 15: Remote Start / Alarm Diagnostics

    REMOTE START / ALARM DIAGNOSTICS REMOTE STARTER DIAGNOSTICS ALARM DIAGNOSTICS Parking Light fl ashes (before starting) : Parking Light fl ashes (after disarm) : Ready mode disabled Door open – zone 3 Valet mode activated (The LED is on) Shock sensor – zone 4 Hood open Hood open –...
  • Page 16 Page 15 / 16...
  • Page 17 USER GUIDE Page 16 / 16...
