Idea EXO66 Quick Start Manual

EXO66
Passive Multipurpose High-Output Mini Monitor
EXO66 is a compact multipurpose passive mini monitor conceived for
those applications in which high power-density with superior quality audio
reproduction and optimum, unobtrusive integration are required.
The design goal of EXO66 is to tightly package the SPL of standard 10" in
a cabinet compact enough to be easily transported in mobile and portable
sound reinforcement applications and to be discreet and elegant in any
installation project (RAL colors available on demand), while using the
same materials and finish that are found in the Touring Sound larger
loudspeaker systems of the IDEA product portfolio.
EXO66 features a 6.5" Coaxial and a high performance 6.5" woofer, in a
very tight, compact rear-ported cabinet. This configuration delivers pristine
audio clarity at any level with minimum distortion, making the EXO66 a
pleasure to listen to, due to the excellent definition of the HF section and
the natural fast and controlled transient response of the custom 6.5" IDEA
LF woofers, which are some of the most powerful transducers of its kind
available in the market today.
Together with BASSO24t or BASSO18, EXO66 will turn into a really
versatile, powerful multipurpose combo for a variety of applications.
Entertainers, musicians and DJs benefit from the advantages of such
power-density, as much as AV rental companies, just like premium
installations and AV/Multimedia facilities find an excellent choice for
superior audio reproduction in the tiny, refined and powerful EXO66.
INSTALLATION ACCESSORIES
EXO66 is fitted with threaded M8 inserts for hung permanent
installations with UB-E66 accessories as well as a bottom 36 mm pole-
mount socket that serves for both pole mount configurations onto a
BASSO Series subwoofer.
Optional Wall-Mount Accessories
The optional U-Bracket accessories
for EXO66 allows for different wall-
mount options and precise vertical
angulations. FIt the M8 bolts,
choose the proper vertical angle
and lock the position with a M6 bolt
per side.
Quick Start Guide
Together with BASSO24t, EXO66
will turn into a really versatile,
powerful multipurpose combo
with a compact form-factor and
stylish desing.
1
