Idea EXO15 Quick Start Manual

EXO15
2-Way Multipurpose Monitor
EXO15 is a high performance, full range 2-way passive monitor conceived for
professional environments where portable sound reinforcement is required
delivering a superior audio reproduction in a h high performance, multipurpose
format.
EXO15 HF assembly couples a 3˝ compression driver into common EXO Series
birch plywood axisymmetric horn with IDEA's proprietary design and a premium
European, dedicated-design passive crossover filter provides a smooth, natural
transition intro the MLF 15˝ woofer and summing up into a full-range superior
audio playback along the whole usable frequency range from 18 kHz down to 50
Hz.
Like all IDEA models, EXO15 is built with 15 and 18 mm birch plywood, IDEA's
Aquaforce waterproof paint coating and a high quality steel grille, creating a
rugged, durable and stylish loudspeaker. The wedged cabinet allows not only to
be used as FOH main system in small venues, bars and AV applications but also
as a stage monitor but to seamlessly fit into any wall mount fixed installation.
EXO15 integrates a bottom 36 mm pole mount socket to be configured on
BASSO Series subwoofers for portable sound reinforcement and medium
performance venues and clubs. EXO15 cabinet design features a 60° wedge
profile to be used as floor monitor and properly aimed to the performer's ears
on stage.
INSTALLATION ACCESSORIES
EXO15 is fitted with 10 threaded M8 inserts for hung permanent
installations as well as bottom 36 mm pole-mount socket that serves
for both pole mount configurations onto a BASSO Series subwoofer.
Examples showing
EXO15 in different setups
and configurations
Quick Start Guide
