- Page 1 OUTBOARD MOTOR OWNER’S MANUAL T9.8BM T8BM T6BM SUZHOU PARSUN POWER MACHINE CO., LTD.
- Page 2 Thank you for owning a PARSUN outboard motor. Thank you for your trust in our company and products. “PARSUN” outboard motors are powerful, economic and safe with advanced technology and processing technique. Please read this manual carefully before operating your outboard motor. A thorough ...
- Page 3 Record your outboard motor serial number in the spaces provided to assist you in ordering spare parts from your Parsun dealer, or for reference in case your outboard motor is stolen. 1. Outboard motor serial number location...
- Page 4 Engine serial number The engine serial number is carved on the aluminum casting of engine. Serial number as follows:...
-
Page 5: Table Of Contents
Table of contents 1. Main components and General information· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1 1.1 Main components·... - Page 6 3. Maintenance· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·27 3.1 Greasing·...
-
Page 7: Main Components And General Information
1. Main components and General information 1.1 Main components 14.Clamp screw 1.Top cowling 8. Tiller handle 15.Choke knob 2.Top cowling lock levers 9. Engine stop button/Engine 16. Gear shift lever 3.Anti-cavitation plate stop lanyard switch 4.Propeller 10.Starter handle 17.Trim rod Fuel joint 18.Fuel tank 5.Cooling water inlet... - Page 8 If your model includes a portable fuel tank, its parts are as follows: 1. Fuel tank cap 3. Air vent screw 2. Fuel joint 4. Fuel gauge WARNING The fuel tank supplied with this engine could only be used as supply of fuel for its running and must not be as a fuel storage container.
-
Page 9: General Information
1.2 General information 1.2.1 Specifications Parameter Items Data Items Data Type of engine 2-stroke L Weight (L) 27Kg Displacement 169cm Transom (S) 381mm Bore X stroke 50mm×43mm Transom (L) 508mm Gear ratio 2.08（27/13） Recommended fuel Unleaded regular gasoline Overall length 842mm Recommended engine oil 2-stroke engine oil... -
Page 10: Fueling Instructions
1.2.2 Fueling instructions Fueling instructions: Recommended gasoline: Regular unleaded gasoline, If it is not available, then premium gasoline. If knocking or pinging occurs, use a different brand of gasoline or premium unleaded fuel. If leaded gasoline is usually used, engine valves and related parts should be inspected after every 100 hours of operation. -
Page 11: Propeller Selection
“PARSUN” dealers stock a range of propellers and can advise you and install a propeller on your outboard that is best suited to your... - Page 12 application.For a greater boat load and a low engine speed, a smaller-pitch propeller is more suitable. Conversely, a large-pitch propeller is more suitable for a smaller operating load as it enables the correct engine speed to be maintained.
-
Page 13: Operation
2. Operation 2.1 Installation Mount the outboard motor on the center line (keel line) of the boat. For boats without a keel or which are asymmetrical, consult your dealer. Center line (keel line) NOTE: During water testing check the buoyancy of the boat, at rest, with its maximum load. Check that the static water level on the exhaust housing is low enough to prevent water entry into the power head, when water rises due to waves when the outboard is not running. -
Page 14: Mounting Height
permanently mounted models, your dealer or other person experienced in proper rigging should mount the motor. If you are mounting the motor yourself, you should be trained by an experienced person. For portable models, your dealer or other person experienced in proper outboard motor mounting should show you how to mount your motor. -
Page 15: Clamping The Outboard Motor
The optimum mounting height of the outboard motor is affected by the boat and motor combination and the desired use. Test runs at a different height can help determine the optimum mounting height. For further information, consult your “PARSUN” dealer or boat manufacturer. -
Page 16: Breaking In Engine
3. Secure the clamp bracket to the transom using the appropriate bolts. For details, consult your PARSUN dealer. WARNING: Avoid using bolts, nuts or washers inappropriate. After tightening, test running the engine and check their tightness. - Page 17 Gasoline and oil mixing: 25:1 Break-in period Gasoline Engine oil 0.04L 0.48L 0.56L 0.96L CAUTION: Failure to follow the break-in procedure could result in reduced engine life or even severe engine damage. 1. First 10 minutes: Run the engine at idle. 2.
-
Page 18: Pre-Operation Checks
2.3 Pre-operation checks Fuel Check to be sure you have plenty of fuel for your trip. Make sure there are no fuel leaks or gasoline fumes. Check fuel line connections to be sure they are tight. Be sure the fuel tank is positioned on a secure, flat surface, and that the fuel line is not twisted ... -
Page 19: Filling Fuel
CAUTION: Do not start the engine out of water. Overheating and serious engine damage can occur. 2.4 Filling fuel WARNING： Gasoline and its vapors are highly flammable and explosive. Keep away from sparks, cigarettes, flames, or other sources of ignition. 1. -
Page 20: Starting Engine
2.5 Starting engine 1. Loosen the air vent screw on the fuel tank cap, 2 or 3 turns. 2. Connect fuel joints securely and squeeze the primer pump with the outlet end up until you feel it become firm (if equipped the fuel joint). 3. - Page 21 Do not attach the lanyard to clothing that could tear loose. Do not route the lanyard where it could become entangled, preventing it from functioning. Avoid accidentally pulling the lanyard during normal operation. Loss of engine power means the loss of steering control. Also, without engine power, the boat could slow rapidly.
- Page 22 Pull out the choke knob fully. NOTE: It is not necessary to use the choke when starting a warm engine. If the choke is left in the “START” (start) position while the engine is running, the engine will run poorly or stall. 6.
-
Page 23: Warming Up Engine
7. After the engine starts, slowly return the manual starter handle to its original position before releasing it. 8. Slowly return the throttle grip to the fully closed position. CAUTION: When the engine is cold, it needs to be warmed up. ... -
Page 24: Shifting
CAUTION: If water is not flowing out of the hole at all times while the engine is running, stop the engine and check whether the cooling water inlet on the lower case or the cooling water pilot hole is blocked. ... -
Page 25: Reverse
2. Move gear shift lever quickly and firmly from neutral to forward. 2.7.2 Reverse WARNING: When operating in reverse, go slowly. Do not open the throttle more than half. Otherwise the boat could become unstable, which could result in loss of control and an ... -
Page 26: Tiller
2.8 Tiller 1. Change direction To change direction, move the tiller handle to the left or right as necessary. 2. Change speed Turn the grip counterclockwise to increase speed and clockwise to decrease speed. 3. Throttle indicator The throttle indicator is on the throttle grip. The fuel consumption curve on the throttle indicator shows the relative amount of fuel consumed for each throttle position. -
Page 27: Stopping Engine
4. Throttle friction adjuster The throttle friction adjuster is on the tiller handle, which provides adjustable resistance to movement of the throttle grip, and can be set according to operator preference. To increase resistance, turn the adjuster clockwise. To decrease resistance, turn the adjuster counterclockwise. -
Page 28: Trimming Outboard Motor
2. Tighten the air vent screw on the fuel tank cap. 3. Disconnect the fuel line if you are using an external fuel tank. 2.10 Trimming outboard motor There are 4 or 5 holes provided in the clamp bracket to adjust the outboard motor trim angle. 1. -
Page 29: Tilting Up And Down
3. Reposition the rod in the desired hole. Make test runs with the trim set to different angles to find the position that works best for your boat and operating conditions. WARNING: Stop the engine before adjusting the trim angle. ... -
Page 30: Tilting Up
2.11.1 Tilting up 1. Place the gear shift lever in neutral (if equipped) and face the outboard motor forward. 2. Tighten the steering friction adjuster by turning it clockwise to prevent the motor from turning freely. 3. Tighten the air vent screw. Disconnect the fuel joint from the outboard motor. -
Page 31: Tilting Down
4. Hold the rear handle and tilt the engine up fully until the tilt support lever automatically locks. 2.11.2 Tilting down 1. Slightly tilt the outboard motor up. 2. Slowly tilt the outboard motor down while pulling the tilt support bar lever 1. -
Page 32: Cruising In Other Conditions
2.12 Cruising in other conditions 2.12.1 Cruising in shallow water The outboard motor can be tilted up partially to allow operation in shallow water. WARNING: The tilt lock mechanism does not work while the shallow water cruising system is being used. ... -
Page 33: Maintenance
If you or the owner is not familiar with machine servicing, this work should be done by your PARSUN dealer or other qualified mechanic. CAUTION: If replacement parts are necessary, use only genuine PARSUN parts or parts of the same type and of equivalent strength and materials. 3.1 Greasing... -
Page 34: Cleaning And Adjusting Spark Plug
Wipe off any dirt from the threads and screw in the spark plug to the correct torque. 3.3 Checking the fuel system 1. Check the fuel lines for leaks, crack, or malfunction. If a problem is found, your PARSUN dealer or other qualified mechanic should repair it immediately. -
Page 35: Inspecting Idling Speed
Correct idling speed inspection is only possible if the engine is fully warmed up. If not warmed up fully, the idle speed will measure higher than normal. If you have difficulty verifying the idle speed, or the idle speed requires adjustment, consult a PARSUN dealer or other qualified mechanic. -
Page 36: Checking Propeller
3.7 Checking propeller WARNING: Before inspecting, removing or installing the propeller, always take actions to ensure the engine will not accidentally starts, such as removing the spark plug caps from the spark plugs, placing the shift control in neutral, and removing the lanyard from the engine stop switch, etc.. -
Page 37: Removing The Propeller
2. Check the propeller shaft for damage. 3. Check the splines/shear pin for wear or damage. 4. Check for fish line tangled around the propeller shaft. 5. Check for the propeller shaft oil seal for damage. 3.7.1 Removing the propeller 1. -
Page 38: Changing Gear Oil
Be sure to use a new cotter pin and bend the ends over securely. Otherwise the propeller could come off during operation and be lost. 1. Apply a marine grease or corrosion resistant grease to the propeller shaft. 2. Install the spacer (if equipped), thrust washer, and propeller on the propeller shaft. 3. -
Page 39: Cleaning Fuel Tank
Inspect the used oil after it has been drained. If the oil is milky, water is getting into the gear case which can cause gear damage. Consult PARSUN dealer. 4. Use a flexible or pressurized filling device, and inject the gear oil into the gear oil drain screw hole. -
Page 40: Checking And Replacing Anode
3.10 Checking and replacing anode(s) Inspect the external anodes periodically. Remove scales from the surfaces of the anodes. Consult a PARSUN dealer for replacement of external anodes. CAUTION: Do not paint anodes, as this would render them ineffective and can cause more rapid engine... -
Page 41: Checking Top Cowling
3.11 Checking top cowling Check the fitting of the top cowling by pushing it with both hands. If it is loose have it repaired by your P ARSUN dealer. -
Page 42: Maintenance Table
Frequency of maintenance operations may be adjusted according to the operating conditions, but the following table gives general guidelines. The “●” symbol indicates the check-ups which you may carry out by yourself. The “○” symbol indicates work to be carried out by your Parsun dealer. Initial Every... - Page 43 Continuation /…1 Initial Every Item Operations 10 hours 50 hours 100 hours 200 hours (1 month) (3 months) (6 months) (1 year) Idling speed ●/○ ●/○ Check/adjustment (carburetor models) ● ● Propeller and cotter pin Check/replacement ○ Shift link/shift cable Check/adjustment ○...
-
Page 44: Transporting And Storing Outboard Motor
4. Transporting and storing 4.1 Transporting The outboard motor should be trailed and stored in the normal running position. If there is insufficient road clearance in this position, then trailer the outboard motor in the tilt position using a motor support device. -
Page 45: Storing
It is advisable to have your outboard motor serviced by an authorized PARSUN dealer prior to storage. However, you, the owner, with a minimum of tools, can perform the following procedures. - Page 46 5. Fill the tank with fresh water to above the level of the anti-cavitation plate. CAUTION: If the fresh water level is below the level of the anti-cavitation plate, or if the water supply is insufficient, engine seizure may occur. 6.
- Page 47 11. Drain the fuel from the fuel tank completely. CAUTION: Portable fuel tank equipped models: Store the portable fuel tank in a dry, well-ventilated place, not in direct sunlight.
-
Page 48: Action In Emergency
2. Inspect the control system and all components for damage. 3. Whether damage is found or not, return to the nearest harbor slowly and carefully. 4. Have a PARSUN dealer inspect the outboard motor before operating it again. 5.2 Starter will not operate If the starter mechanism does not operate, the engine can be started with an emergency starter rope. - Page 49 The procedure is as follows: 1. Remove the top cowling. 2. Remove the start-in-gear protection cable. 1. Start-in-gear protection cable 3. Remove the starter cover after removing the three bolts. 4. Prepare the engine for starting. For further information, see section 2.5. 5.
-
Page 50: Treatment Of Submerged Motor
7. Give a strong pull straight out to crank and start the engine. Repeat it necessary. 5.3 Treatment of submerged motor If the outboard is submerged, immediately take it to a PARSUN dealer. Otherwise some corrosion may begin almost immediately. - Page 51 5. Take the outboard motor to a PARSUN dealer as soon as possible. CAUTION: Do not attempt to run the outboard motor until it has been completely inspected.
-
Page 52: Troubleshooting
6.Troubleshooting Trouble type Possible reason Recovery action Starter components are faulty Have serviced by your dealer Starter will not operate Shift lever is not in neutral Shift to neutral Fuel tank is empty Fill tank with clean, fresh fuel Fuel is contaminated or stale Fill tank with clean, fresh fuel Fuel filter clogged Replace with recommended type... - Page 53 Continuation /…1 Trouble type Possible reason Recovery action Fuel is contaminated or stale Fill tank with clean, fresh fuel Fuel filter clogged Clean or replace with recommended type Spark plug gap is incorrect Inspect and adjust as specified Check wires for wear or breaks. Tighten Ignition wiring damaged or poorly all loose connections.
- Page 54 Continuation /…2 Trouble type Possible reason Recovery action Motor is mounted at incorrect transom Adjust motor to proper transom height height Boat bottom is fouled with marine growth Clean boat bottom Weeds or other foreign matter are tangled Remove foreign matter and clean lower on gear housing unit Inspect spark plug(s).
- Page 55 Continuation /…3 Trouble type Possible reason Recovery action Propeller is damaged Repair or replace propeller Propeller shaft is damaged Have serviced by your dealer Weeds or other foreign matter are tangled Engine vibrates Remove and clean propeller on propeller excessively Motor mounting bolt is loose Tighten bolt Steering pivot is loose...
-
Page 56: Circuit Diagram
7. Circuit diagram green Black brown white Spark plug Engine stop switch Amplidyne winding Ignition control module & High voltage bundle S N . DESCRIPTION...
